Schneider XY2CH13250 Latching Emergency Stop Rope Pull Switch: Specifications, Selection Guide and Installation Overview

If you have landed on this page with a catalog number already in hand — pulled from a machine schematic, a replacement parts list, or a safety system drawing — you are at the right place. The Schneider XY2CH13250 is a latching emergency stop rope pull switch from the Telemecanique XY2CH series, rated IP65 per IEC 60529, with a fixed 1 NC + 1 NO contact configuration and a booted pushbutton reset. The question most buyers are trying to answer is not what it is, but whether this exact variant — orientation, cable reach, contact logic, environmental rating — matches their machine layout before the purchase order is submitted.

If you have already confirmed this is the correct part, check current pricing and availability for the XY2CH13250 at LeadTime.ca — ships worldwide.

Who Should Buy the XY2CH13250 — and Who Shouldn't

This switch is the right choice when all of the following apply to your application:

  • Your cable pull distance and routing geometry match the rope length of this specific variant
  • Your control circuit expects a standard 1 NC + 1 NO input — no pilot light required in the switch body itself
  • Your installation environment requires at minimum IP65 protection against dust and low-pressure water jets
  • You have confirmed the mounting orientation (RH or LH side pull) fits your guard frame or machine structure
  • Your safety circuit complies with CE-marked equipment requirements and is compatible with IEC 61508 safety circuit design

If your application requires a pilot light for visual feedback at the switch body, or if your contact configuration differs from 1 NC + 1 NO, a different variant in the XY2CH family is the correct choice. See the variant comparison table below before ordering.

On this page:

What the XY2CH13250 Does in a Live Safety Circuit

The XY2CH13250 is a mechanically latching emergency stop device that activates when an operator pulls a cable. Unlike a standard push-button e-stop that must be reached directly, a rope pull switch can be mounted along a machine guard, conveyor frame, or cell perimeter — giving operators at any point along that run the ability to halt all hazardous motion immediately. When the rope is pulled, the switch engages and holds in the stopped position. It does not self-reset. The machine stays halted until an operator physically pushes the booted button on the switch body back to its normal position and clears any faults on the safety controller. That latching behavior is the defining safety characteristic: power cannot be restored by simply releasing the rope.

The 1 NC + 1 NO contact arrangement is the industry-standard configuration for emergency stop circuits per IEC 61508 safety circuit design practice. The normally closed contact drops out when the switch is pulled, removing power from the safety relay or PLC safety module. The normally open contact provides confirmation feedback. No external signal converters or logic modifications are needed to integrate this contact arrangement into most modern safety PLCs or relay-based safety controllers. The IP65 rating per IEC 60529 confirms full dust ingress protection and resistance to low-pressure water jets from any direction — making the XY2CH13250 suitable for washdown areas, food processing lines, and dusty industrial environments without additional housing.

Where the XY2CH13250 Sits in Your Control System

The XY2CH13250 sits at the field device layer of a safety circuit — between the physical hazard zone and the safety controller that manages machine stop functions.

  • Safety PLC or safety relay controller receives contact signals from the XY2CH13250 NC output
  • XY2CH13250 is mounted on the machine guard frame or conveyor perimeter at the point of operator access
  • Cable/rope is routed from the switch body along the guard or frame to reach all operator positions within the protected zone
  • When pulled, the NC contact opens and the safety controller initiates a controlled stop of all hazardous motion in the cell
  • Manual reset at the switch body (booted pushbutton) followed by fault clear on the safety controller is required before restart

Typical Applications and Deployment Scenarios

The XY2CH13250 is specified most often on multi-station assembly lines where operators work at different points along the line and any one of them must be able to halt operations instantly without crossing to a fixed push-button station. The rope pull mechanism eliminates the need to position a separate e-stop at every work station.

Packaging machinery is another primary deployment — form-fill-seal lines, case packers, and palletizers where guards run the full length of the machine and a single rope pull switch covers the entire perimeter. Material handling and conveyor systems are similarly well-suited, since the cable can be routed along the full conveyor run to provide emergency stop access from any point along its length.

Press and stamping machine applications use the XY2CH13250 mounted on the guard frame to allow operators to halt the press from any position around the work cell. Injection molding cells and robotic work cells use it as a perimeter safety device, particularly where AGV paths or robot envelopes create extended hazard zones that a fixed push-button cannot fully protect.

Application Typical Deployment
Multi-station assembly line Mounted on line guard; rope routed along full operator side for multi-point access
Packaging machinery (form-fill-seal, case packer) Guard perimeter mount; single switch covers full machine length
Conveyor and material handling systems Cable routed along conveyor frame; operators stop motion from any station
Press and stamping machines Guard frame mount; immediate halt accessible from any position around the cell
Injection molding and robotic work cells Perimeter safety device covering AGV paths or extended robot envelopes
Food processing lines IP65 washdown-rated mount in wet or high-dust processing environments

Key Specifications and Variant Comparison

Parameter Value / Details
Manufacturer Schneider Electric (Telemecanique brand)
Model Number XY2CH13250
Product Type Latching emergency stop rope pull switch
Activation Method Cable pull (mechanical)
Contact Configuration 1 NC + 1 NO
Pilot Light None (booted pushbutton version)
IP Rating IP65 per IEC 60529
Latching Behavior Holds position after pull until manual reset
Mounting Orientation RH (right-hand) or LH (left-hand) side
Standard Compliance CE marking; compatible with IEC 61508 safety circuits

Full technical specifications are available on the product page at LeadTime.ca.

The XY2CH family includes variants that differ on three axes: pilot light presence, mounting side, and cable pull distance. Use the table below to confirm you are ordering the correct variant for your system.

Variant Contact Type Pilot Light Side Application Notes
XY2CH13250 (this model) 1 NC + 1 NO No RH / LH Standard emergency stop for direct PLC safety module integration; no visual indicator at switch body
XY2CH13250 with pilot light variant 1 NC + 1 NO Yes RH / LH Adds visual feedback at switch body; specify this variant when operators need local indication that the stop is engaged
XY2CH family (other cable length variants) 1 NC + 1 NO Varies RH / LH Verify cable pull distance against your machine layout before specifying; cable length is fixed per variant

If your application requires a pilot light at the switch body for local visual confirmation, the XY2CH13250 is not the correct variant — check the current variant lineup and availability at LeadTime.ca to confirm the right model for your system.

Expert Verdict: Is the XY2CH13250 the Right Switch for Your System?

The XY2CH13250 is the right choice for machine builders and plant engineers who need a proven, compact rope pull emergency stop with direct PLC safety module compatibility and IP65 protection. Its fixed 1 NC + 1 NO contact arrangement integrates into most modern safety relay and safety PLC inputs without additional signal converters — a meaningful advantage when you are working to a tight panel build schedule. The latching mechanism is not a convenience feature; it is a safety requirement. The switch holds the stopped state until a deliberate manual reset is performed, which eliminates the risk of inadvertent restart after a rope pull event. For applications across packaging lines, conveyor systems, assembly stations, and robotic cell perimeters, this is a well-matched, field-proven device from a recognized industrial safety product line. The IP65 rating per IEC 60529 covers dust and low-pressure washdown without additional enclosures, which removes a common specification risk in food processing and chemical handling environments.

Where the XY2CH13250 has real limits is equally clear. If your safety system design calls for a pilot light at the switch body to give operators local visual confirmation that the stop is engaged, this model is not the correct choice — you need a variant within the XY2CH family that includes the integrated indicator. If your downstream control logic requires a contact configuration other than 1 NC + 1 NO, this model's fixed arrangement will not accommodate that without external logic changes. And for any fixed-location emergency stop application where cable routing is impractical or unnecessary, a standard push-button e-stop is a simpler and more appropriate solution. The booted pushbutton reset profile on the XY2CH13250 also warrants a physical clearance check on installations with tight frame geometry.

From a procurement standpoint, the XY2CH13250 sits in a product category — safety-rated emergency stop switches from a major automation brand — that generally sees reasonable stock levels and short lead times through specialist industrial distributors. That said, orientation variants (RH vs. LH) are not always stocked interchangeably at every location, and ordering the wrong side is the most common and most costly installation mistake in this product family. A specialist distributor can confirm which orientation is in stock, advise on cable length variants for your specific machine geometry, and provide technical support if questions arise during commissioning. Check current availability and pricing for the XY2CH13250 at LeadTime.ca — we ship worldwide and carry the Telemecanique XY2CH series for buyers in North America and internationally.

For volume pricing or to confirm lead time before committing to a build schedule, contact the LeadTime.ca team directly — we ship worldwide.

What Engineers Need to Know Before Ordering the XY2CH13250

Because community discussion data for this specific model is limited in publicly indexed forums, the most reliable intelligence available comes from the device's own technical constraints and the ordering patterns that consistently produce installation problems. The XY2CH13250 is a straightforward device with a well-defined specification envelope — but the gap between a correct order and a costly installation delay is almost always one of three things: orientation, cable reach, or contact logic mismatch.

Orientation is the issue that generates the most rework. The RH and LH designations refer to which side of the switch body the cable exits relative to the operator facing the machine guard. These are not interchangeable in the field without remounting and re-routing the cable. Engineers who have worked with rope pull switches consistently report that the mistake is made at the specification stage — not during installation — because the machine drawing was read without confirming the actual operator position relative to the guard frame. The fix is simple: physically walk the machine layout (or review the 3D model) and mark the pull direction before the PO is written.

Contact logic confusion is less common but more technically consequential. The XY2CH13250 provides 1 NC + 1 NO contacts. This is the standard configuration for most safety relay and safety PLC inputs. However, some applications — particularly those using dual-channel safety circuits or monitoring relays that expect two NC contacts — cannot use this model without circuit modification. Confirm the input specification of your safety controller before ordering. If your safety module requires dual NC inputs, a different contact arrangement is needed. The XY2CH13250 is not the wrong device for most applications, but it is the wrong device for that specific circuit architecture. Checking the safety module datasheet against the switch contact configuration takes less than five minutes and eliminates a potentially serious commissioning issue. LeadTime.ca's team can assist in confirming compatibility when the application details are provided — reach out before ordering if there is any uncertainty.

Wiring and Installation Overview

The following is a high-level installation overview. Full wiring diagrams and detailed commissioning procedures are contained in the Telemecanique XY2CH series technical manual. Always refer to manufacturer documentation and your machine's electrical schematics before beginning installation.

  • Confirm RH or LH orientation matches your machine frame geometry and mark it on the work order before beginning — remounting after cable routing is already in place is time-consuming and avoidable
  • Mount the XY2CH13250 on the machine guard or frame using the provided hardware; verify the cable exit direction aligns with the rope routing path and that minimum bend radius is maintained throughout the cable run
  • Connect the NC contact to the emergency stop input of your safety relay or safety PLC module; connect the NO contact for confirmation feedback as required by your circuit diagram — verify terminal assignments against the Telemecanique datasheet before making connections
  • With the machine powered down, perform a full pull test: the switch must engage (latch in the pulled position) and contacts must change state; verify with a multimeter before any powered testing
  • After confirming mechanical and electrical function under power-down conditions, perform a supervised operational test to verify the safety controller initiates a controlled stop on cable pull and that manual reset of the booted button plus fault clear on the controller is required before restart

Compatible System Expansion and Accessories

The XY2CH13250 is designed for integration with Telemecanique and Schneider Electric safety system components, as well as any third-party safety controller that accepts a standard 1 NC + 1 NO discrete input. The following related components from the XY2CH and broader Telemecanique safety product line are typically specified alongside this switch:

  • XY2CH series rope pull switch variants — additional mounting positions, pilot light versions, and alternate cable length variants for extended machine runs
  • Schneider Electric safety relays and safety PLC modules — accept the 1 NC + 1 NO input directly for category 3 or category 4 safety circuit architectures per IEC 61508
  • Telemecanique rope and cable accessories — for extending cable runs beyond the factory-supplied length, subject to compliance with safety standard requirements for the specific machine application

Wrong-Part Prevention Checklist

Before submitting your purchase order for the XY2CH13250, verify each of the following. This checklist reflects the most common ordering and installation errors for rope pull emergency stop switches in this product family.

  1. Confirm cable pull reach matches your machine layout (distance from guard/location to operator area)
  2. Verify RH or LH orientation is correct for your frame geometry
  3. Check that downstream control system expects 1 NC + 1 NO contact logic (no pilot light required)
  4. Ensure IP65 rating matches your environmental conditions (washdown, dust, temperature range)
  5. Verify installation mounting type (surface or embedded in frame) is compatible with your equipment
  6. Confirm no regional certification gaps (CE, UL, CSA) for your market and application

If any of the above items cannot be confirmed before ordering, contact the LeadTime.ca team for application support — providing your machine type, mounting geometry, and safety controller model will allow us to confirm the correct variant before the PO is placed.

Frequently Asked Questions

Does the XY2CH13250 self-reset after a rope pull, or does it require manual intervention to restart the machine?

The XY2CH13250 is a latching switch — it holds in the activated (stopped) position after a rope pull and does not self-reset. An operator must physically push the booted button on the switch body back to its normal position, and any faults on the safety controller must be cleared before the machine can restart. This latching behavior is a core safety requirement and cannot be bypassed.

Can I use the XY2CH13250 with a dual-channel safety input module that requires two NC contacts?

No. The XY2CH13250 provides a fixed 1 NC + 1 NO contact configuration. Dual-channel safety circuits that require two independent NC contacts cannot use this switch without external circuit modifications. Confirm your safety controller's input channel requirement against the 1 NC + 1 NO specification before ordering — if dual NC inputs are needed, a different switch variant or external signal conditioning will be required.

How do I determine whether I need the RH or LH orientation variant?

Stand at the operator position facing the machine guard where the switch will be mounted. If the rope runs to your left, you need the LH (left-hand) orientation. If it runs to your right, you need the RH (right-hand) orientation. Confirm this by reviewing the machine layout drawing and marking the pull direction before placing the order — this is the most common source of ordering errors for rope pull switches in the XY2CH family.

Is the IP65 rating sufficient for food processing washdown environments?

IP65 per IEC 60529 provides full protection against dust ingress and resistance to low-pressure water jets from any direction. This rating is appropriate for most food processing washdown applications. If your process uses high-pressure washdown jets or chemical cleaning agents directly on the switch body, verify that the IP65 rating and materials of construction meet your specific process requirements — the manufacturer datasheet and your plant hygiene standards are the authoritative references for that determination.

What is the reset procedure after an emergency stop event, and is there a key-release option?

After an emergency stop event, allow all hazardous machine motion to cease completely. Manually push the booted button on the XY2CH13250 body back to its normal (non-activated) position to release the latch. Then clear any faults on the PLC or safety controller before initiating machine restart. The XY2CH13250 uses a booted pushbutton reset — it does not incorporate a key-release mechanism. If key-release reset is a requirement for your safety design, verify the correct variant within the XY2CH family before ordering.

Why Order Through LeadTime.ca

  • LeadTime.ca ships the Telemecanique XY2CH series worldwide — not limited to any single country or region
  • Specialist distributor support means orientation and cable length variants can be confirmed before the PO is placed, reducing the risk of receiving the wrong part
  • Volume pricing is available for OEM and machine builder orders — contact for current terms
  • Hard-to-find variants and expedited sourcing are available for urgent replacement and maintenance situations

XY2CH13250 At-a-Glance Summary

  • Product: Schneider XY2CH13250 — latching emergency stop rope pull switch, Telemecanique XY2CH series
  • Contact configuration: 1 NC + 1 NO — direct input to most safety relays and safety PLC modules per IEC 61508
  • IP rating: IP65 per IEC 60529 — full dust protection and low-pressure water jet resistance from any direction
  • Reset method: Manual booted pushbutton reset — switch holds latched position until operator resets it at the switch body
  • Pilot light: None — if visual indication is required at the switch body, specify the pilot light variant from the XY2CH family
  • Mounting orientation: RH or LH side pull — confirm orientation against machine layout before ordering; this is the most common ordering error
  • Compliance: CE marking; compatible with IEC 61508 safety circuit design standards
  • Primary deployment: Multi-station assembly lines, packaging machinery, conveyors, press and stamping machines, robotic and AGV cell perimeters
  • Pricing and availability: Contact LeadTime.ca or check the product page for current pricing — ships worldwide
