Schneider Electric XB4BA31 Harmony 22mm non-illuminated green spring return pushbutton for industrial control panel

Schneider Electric XB4BA31 Harmony XB4 Non-Illuminated Pushbutton, 22 mm, 1NO, Spring Return, Green — Full Specifications, Voltage Ratings, and Ordering Guide

When a panel builder or controls engineer searches for the Schneider Electric XB4BA31, the decision is almost always already made at the product-family level — what remains is confirming the contact configuration, voltage rating, and mounting geometry before committing the purchase order. This is a 22 mm non-illuminated green pushbutton with a single normally open contact, spring return action, and a NEMA 4/4X/13, IP66 environmental seal built into the zamak collar. It handles 6A at 120V AC down to 1.2A at 600V AC and is rated for 10,000,000 mechanical switching cycles. The specifications are tight, the fit requirements are specific, and ordering the wrong variant costs two to four weeks on your build schedule.

If you have already confirmed this is the correct part, check current pricing and availability for the Schneider Electric XB4BA31 at LeadTime.ca — ships worldwide.

Who Should Buy the Schneider Electric XB4BA31 — and Who Should Not

The XB4BA31 is the right choice for engineers and panel builders who need a proven, standards-certified 22 mm momentary pushbutton with industrial-grade environmental protection. This product is right for you if all of the following apply:

  • Your circuit wiring diagram specifies a 1NO (normally open) contact — not 1NC, not changeover
  • Your panel cutout is exactly 22 mm diameter; a 24 mm hole from a legacy selector switch will not seal correctly
  • Your circuit voltage falls within the rated range: 6A at 120V AC, 3A at 240V AC, 1.5A at 480V AC, 1.2A at 600V AC, or 0.55A at 125V DC
  • Spring return (momentary) operation is required — the button resets automatically on release; latching or maintained contact is not available in this model
  • Your installation environment calls for NEMA 4, 4X, or 13 / IP66 sealing — washdown, corrosion resistance, or outdoor exposure
  • A non-illuminated flush green button head meets your facility color standard and panel aesthetic

If you need an illuminated button, specify the XB4BW variant or add a separate ZB4 pilot light. If your circuit requires latching or maintained contact operation, the XB4BA24 is the correct model. If your load current exceeds the ratings above at your operating voltage, you are outside the XB4 family envelope and should evaluate industrial-duty selector switches or contactor-based alternatives.

On this page:

What the XB4BA31 Does in a Real Control System

The Schneider Electric XB4BA31 is a manual input device — the physical interface between an operator and a control circuit. When an operator presses the green button, the single normally open contact closes momentarily, passing a signal or completing a power path for the duration of the press. When the operator releases the button, the spring return mechanism automatically restores the button to the neutral position and opens the contact. The circuit sees nothing. This makes the XB4BA31 the correct choice for start commands, pulse triggers, momentary coil energization, and any logic where the control system should only see a brief, intentional actuation — not a sustained state.

The product belongs to the Harmony XB4 platform, a 22 mm modular pushbutton family used across automotive manufacturing, food processing, CNC machining, and heavy equipment enclosures. The platform's significance for procurement is practical: components within the Harmony XB4 family share the same 22 mm mounting footprint, which means the XB4BA31 can replace or substitute within the platform without panel recutting or redesign — a real cost reduction on multi-button console upgrades. The zamak fixing collar provides corrosion resistance that puts this button into outdoor, marine, and washdown environments without additional enclosure protection. Silver-alloy (AgNi) contacts deliver reliable low-resistance switching across the full 10,000,000 mechanical cycle rating, which translates to a decade or more of service in 24/7 production environments before a replacement cycle is warranted.

Where the XB4BA31 Sits in Your System Architecture

The XB4BA31 is a field-level input device positioned between the operator and the control layer — it sits at the front edge of the signal chain, upstream of everything else in the automation stack.

  • Operator action (physical button press) closes the 1NO contact inside the XB4BA31
  • The closed contact completes a circuit path back through the panel wiring to a PLC digital input card, safety relay, or motor starter coil
  • The PLC or relay reads the input state change and executes the corresponding logic — start, stop, pulse, interlock release
  • Downstream actuators (motor starters, solenoid valves, indicator lights) respond to the logic output, not directly to the pushbutton
  • The XB4BA31's IP66-sealed housing protects the contact assembly from the panel environment while the integral O-ring maintains enclosure integrity at the panel face cutout

Industries and Typical Applications for the XB4BA31

Automotive manufacturing is one of the highest-volume deployment environments for the XB4BA31. Machine press start and stop circuits, assembly line manual input stations, and fixture release buttons all call for a momentary 1NO contact with NEMA 4X sealing to survive coolant mist and high-humidity press areas. The 10,000,000 mechanical cycle rating supports multi-shift production over a ten-plus year equipment lifecycle without scheduled replacement.

Food and beverage processing facilities specify the XB4BA31 for its IP66 washdown protection. In wet processing areas where high-pressure hose-downs are routine, the integral O-ring seal and zamak collar eliminate the need for additional button protection enclosures. The high-pressure washer test rating — confirmed at 1015.26 psi at 131°F — means the button survives the same cleaning protocols as the stainless steel processing equipment around it.

Textile and paper production environments require buttons that tolerate extreme actuation frequency. Emergency stop circuits on textile looms, web break response buttons, and operator call signals can accumulate millions of cycles in a single production year. The XB4BA31's rated mechanical durability positions it as a long-service component in these environments, reducing the maintenance overhead of scheduled button replacement programs.

Outdoor and coastal industrial installations — marine diesel enclosures, offshore equipment panels, outdoor gateway cabinets — rely on the XB4BA31's NEMA 4X rating and zamak collar for salt-air corrosion resistance. Combined with stainless steel hardware, the button survives prolonged coastal exposure conditions that would corrode standard plated steel hardware within one to two seasons.

Application Typical Deployment
Automotive press control panel Manual start/stop, 120V AC circuit, NEMA 4X required for coolant environment
Food processing line console IP66 washdown button, 240V AC, screw terminals for thermal cycling reliability
Textile loom emergency stop circuit Spring return 1NO triggering safety relay shutdown, 10M-cycle rating for continuous production
CNC machine tool operator station 24/7 high-frequency manual input, 480V AC rated circuit, flush green profile
Outdoor marine or coastal enclosure NEMA 4X corrosion-resistant zamak collar with stainless hardware, salt-air exposure
Utility substation coordination panel 600V AC circuit, 1.2A contact rating, momentary input to protection relay

Contact Ratings, Mechanical Specs, and Key Technical Data

Parameter Specification
Contact Configuration 1NO (Single Normally Open)
AC Contact Ratings 6A @ 120V AC / 3A @ 240V AC / 1.5A @ 480V AC / 1.2A @ 600V AC
DC Contact Rating 0.55A @ 125V DC
Rated Insulation Voltage 600 VAC per EN/IEC 60947-1
Rated Impulse Withstand Voltage 6 kV per EN/IEC 60947-1
Mechanical Durability 10,000,000 switching cycles
Operating Temperature Range -40°F to +158°F (-40°C to +70°C)
Environmental Rating NEMA 4, 4X, 13 / IP66
Mounting Hole Diameter 22 mm ±0.1 mm tolerance
Certifications UL Listed (File E164353), CSA Certified (File LR44087 Class 321103), CE Marked

Full technical specifications are available on the product page at LeadTime.ca.

XB4BA31 vs. XB4BA24 and Alternatives: Which Model Do You Actually Need?

Model Button Size Contact Type Operation IP Rating NEMA Rating Key Difference
XB4BA31 22 mm 1NO Spring Return (Momentary) IP66 4/4X/13 Standard Harmony platform; most common in panel shops; non-illuminated green
XB4BA24 22 mm 1NO Latching (Maintained) IP66 4/4X/13 Button stays engaged until released; for toggle-function circuits
XB4BW (series) 22 mm 1NO Spring Return IP66 4/4X/13 Illuminated button head; integral LED or lamp; for operator feedback circuits
3SB32 (Siemens) 22 mm 1NO Spring Return IP66 4X Similar industrial duty; slightly larger button head; alternate platform
HW1B-M420 (IDEC) 22 mm 1NO Spring Return IP66 4/13 Compact profile; fewer standard color options than Harmony XB4
M22-D-G (Eaton) 30 mm 1NO Spring Return IP66 4/4X/13 Larger button head for gloved-operator environments; higher cost tier

If your circuit requires maintained contact operation or you need an illuminated button head for operator feedback, this is not the correct model — visit the product page at LeadTime.ca and contact the team for guidance on the correct XB4 variant for your specification.

Expert Verdict: Is the XB4BA31 Worth Specifying?

The Schneider Electric XB4BA31 is the correct choice for panel builders and system integrators who need a proven, maintenance-light 22 mm momentary pushbutton backed by UL, CSA, and CE certification in a single SKU. Its buyer profile is specific: engineers standardizing on the Harmony platform across multi-facility automotive or food processing operations, control builders upgrading aging pushbutton stocks without panel recutting, and facilities engineers selecting washdown-rated buttons for outdoor or marine enclosures where corrosion resistance is non-negotiable. The 10,000,000 mechanical cycle rating and IP66 sealing eliminate routine replacement cycles in high-frequency production environments — that is a tangible total-cost-of-ownership advantage in continuous manufacturing. The UL File E164353 and CSA File LR44087 credentials cover North American installations and accelerate approval cycles for OEM builders exporting panels across the US, Canada, and EU markets simultaneously.

The XB4BA31 has real limits that matter at specification time. It carries no illumination capability — if operator feedback via an integrated indicator light is required, the XB4BW series or a separate ZB4 pilot light is the correct path. The spring return action is fixed and cannot be field-converted to latching; if a maintained-contact toggle function is needed, the XB4BA24 is the right model and ordering the XB4BA31 in error costs a full re-order cycle. For operators working in gloved environments or applications where a larger button target surface reduces mis-actuation risk, the Eaton M22-D-G at 30 mm offers a meaningfully larger button head. For buyers needing custom colors beyond the standard green, red, yellow, and blue stocked in the Harmony XB4 catalog, special order timelines apply and that constraint should be flagged early in the design review process.

From a procurement standpoint, the XB4BA31 is a standard catalog item with consistent availability through authorized distributors globally. Lead times for in-stock orders are typically same or next business day; backorder situations generally resolve within two to four weeks depending on regional demand cycles. The risk of installation errors — over-torquing the zamak collar, mismatching voltage-dependent current ratings, or ordering 1NO when a circuit requires 1NC — far exceeds any sourcing risk when buying through a specialist distributor who can validate your specification before the order ships. That pre-order review is where LeadTime.ca adds measurable value beyond unit price. Check current availability and pricing for the XB4BA31 at LeadTime.ca — ships worldwide from a single order.

For volume pricing, build schedule lead time confirmation, or multi-site procurement coordination, contact the LeadTime.ca team directly — we ship worldwide and can confirm regional stock before you commit to a build schedule.

What Engineers Need to Know Before Ordering the XB4BA31

The Harmony XB4 platform, including the XB4BA31, generates very little forum traffic or community complaint — which is itself informative. When a foundational industrial component works reliably across millions of installations without notable failure modes, engineers do not post about it. The XB4BA31 is exactly that kind of product: a mature, commodity-grade control component that meets its specification quietly. The absence of troubleshooting threads on forums like PLCTalk, PLCS.net, or the Schneider Electric Support Community is a signal of product maturity, not a gap in documentation.

What does surface at the product family level is a consistent pattern of installation and ordering errors that have nothing to do with the hardware itself. Technicians cracking or stripping the rear zamak collar during installation — typically when using an impact wrench or an uncalibrated torque tool — is a recurring report. The tightening torque specification of 0.8 to 1.2 N-m is tight by design; one facility manager reported a measurable scrap rate on an initial 100-unit installation run until the installation team was retrained on the correct torque value. A calibrated torque wrench is not optional in critical or IP66-rated installations. The second pattern is contact-type confusion: engineers receiving latching XB4BA24 variants when spring-return XB4BA31 units were intended, traced entirely to specification errors at order time rather than fulfillment mistakes. And the voltage-derating table catches buyers every time it is not consulted — one electrician reported contact failure in the field after applying 6A loading on a 240V circuit, having taken the 6A figure from the datasheet without noting it applies only at 120V AC.

This is why specialist distributor review before order placement matters for a product like the XB4BA31. The hardware is reliable. The specification process is where failures occur. LeadTime.ca's technical team can validate your contact configuration, verify your voltage-current combination against the rating table, and confirm your panel cutout tolerance before the order ships — eliminating the two-to-four-week re-order delay that comes from discovering a specification mismatch during panel assembly. When community documentation is thin and manufacturer datasheets are dense, that pre-order conversation is the most cost-effective quality check available.

Wiring and Panel Mounting: What to Verify Before Installation

  • Screw clamp terminals accept 14 to 20 AWG wire; verify your conductor gauge falls within this range before stripping wire — oversized conductors will not seat correctly and create a false-torque condition
  • Terminal tightening torque is 0.8 to 1.2 N-m using a Phillips/Pozidriv #1 cross-head screwdriver or a flat 4 mm / 5.5 mm driver; over-tightening damages internal spring contacts and over-torquing the zamak collar causes cracking — use a calibrated torque wrench for critical or IP66-rated installations
  • Panel cutout must be exactly 22 mm diameter with ±0.1 mm tolerance; insert the XB4BA31 from the front, push straight in until the zamak collar contacts the panel face, then hand-tighten the rear collar nut before applying final wrench torque
  • Mounting depth behind panel is 2.05 inches; verify no interference with backside components, conduit runs, or DIN rail before installation — this dimension is fixed and cannot be reduced
  • Before applying power, verify the integral O-ring seal is intact and fully seated against the panel face; a damaged or displaced O-ring invalidates the IP66 rating and allows water ingress in washdown environments

Wrong-Part Prevention: Six Checks Before You Place the Order

The following checklist addresses the six most common specification errors reported with the XB4BA31. Work through each item against your panel design documentation before submitting a purchase order.

  1. Confirm contact type: This is 1NO only. If you need both open and closed contacts, do NOT order this model; specify 1NO+1NC instead
  2. Check circuit voltage: Match the amperage rating (120V=6A, 240V=3A, 480V=1.5A, 600V=1.2A); do not exceed
  3. Verify mounting hole size: Exactly 22 mm panel cutout required; do not assume it is the same as your 24 mm selector switch hole
  4. Confirm operation type: This is spring-return (momentary). If you need latching/maintained contact, cancel order and choose latching variant
  5. Confirm color: This is green. If you need red (stop), yellow (warning), or blue (other), select correct color code before ordering
  6. Verify button profile: This is flush (not raised or recessed). Confirm your panel design specification before ordering

If any item on this checklist raises a question before you order, contact the LeadTime.ca team for specification confirmation — it is faster than a re-order cycle.

Frequently Asked Questions

Does the XB4BA31 include an integrated indicator light, or do I need a separate pilot device?

The XB4BA31 is a non-illuminated model — there is no LED, lamp, or indicator function built into the green button head. If operator feedback via an illuminated button is required for your circuit, specify the XB4BW series variant instead, or add a separate ZB4 pilot light alongside this pushbutton. The Harmony XB4 platform supports modular pilot light additions without panel recutting due to the standardized 22 mm footprint.

What happens if I exceed the contact current rating at my circuit voltage — does the button fail immediately or degrade over time?

Exceeding the voltage-dependent current rating causes accelerated contact arcing on each switching cycle, which progressively fouls the silver-alloy (AgNi) contact surface. The button does not fail immediately; instead, contact resistance rises over time as arc deposits accumulate, causing intermittent or unreliable circuit closure. Premature failure typically occurs well before the rated 10,000,000 mechanical cycles are reached — often in the range of 100,000 to 500,000 cycles under sustained overload conditions. Always cross-reference your circuit voltage against the full rating table: 6A at 120V AC, 3A at 240V AC, 1.5A at 480V AC, 1.2A at 600V AC, and 0.55A at 125V DC.

Can the XB4BA31 be used in a DC control circuit, or is it AC-rated only?

The XB4BA31 supports both AC and DC circuits. The DC rating is 0.55A at 125V DC, applying the AC15/DC13 contact utilization category per IEC 60947-4-1. Do not use this button as a power-switching device in DC circuits; it is appropriate for PLC signal-level DC inputs and control relay coil circuits within the rated current. DC applications above the rated current will cause contact arcing and premature wear.

Is the XB4BA31 a direct panel swap for a 24 mm selector switch without recutting the hole?

No. The XB4BA31 requires an exactly 22 mm diameter mounting hole with ±0.1 mm tolerance. A 24 mm panel cutout — standard for many 3-position selector switches — is too large for the 22 mm collar to seal against. Forcing the XB4BA31 into an oversized hole results in a loose installation, loss of IP66 seal integrity, and potential water ingress in washdown applications. Physically measure the existing cutout with a digital caliper before ordering; if the hole is 24 mm, you need a different product family or a panel with a new 22 mm cutout.

What torque specification applies to the mounting collar, and is a torque wrench required?

The terminal screw clamp tightening torque is 0.8 to 1.2 N-m per EN 60947-1, applied using a Phillips/Pozidriv #1 or flat 4 mm / 5.5 mm screwdriver. For the zamak mounting collar itself, hand-tighten first and then apply final torque with a wrench — the zamak alloy will crack if over-torqued with an impact tool. A calibrated torque wrench is recommended best practice for critical IP66-rated installations and for any high-volume installation run where consistent sealing integrity matters across a full panel assembly.

Does the XB4BA31 spring-return mechanism wear out before the contact does in high-cycle applications?

The 10,000,000 mechanical cycle rating covers the complete button assembly including the spring return mechanism, not the contact alone. The silver-alloy (AgNi) contacts and the return spring are rated together to this durability figure under normal operating conditions. In textile loom, automotive press, and CNC applications running 24/7 production cycles, this translates to a service life measured in years before any maintenance-driven replacement is warranted — provided the button is operated within its rated current and voltage parameters.

Why Order the XB4BA31 Through LeadTime.ca

  • Global shipping from a single source — no need to manage cross-border orders, customs brokerage, or regional distributor fragmentation across multiple facilities or project sites
  • Pre-order specification review available — the team can validate your contact type, voltage rating, and mounting geometry before the order ships, eliminating the most common causes of re-order delays
  • Volume pricing and multi-unit project quotes available on request — contact the team for panel builds requiring 10 or more units across multiple SKUs
  • Hard-to-locate and short-lead-time sourcing for standard catalog items like the XB4BA31 when regional distributor stock is depleted during peak facility upgrade cycles

At-a-Glance Summary

  • Contact configuration: 1NO (normally open) only — spring return, momentary action
  • AC ratings: 6A at 120V / 3A at 240V / 1.5A at 480V / 1.2A at 600V; DC rating: 0.55A at 125V
  • Mechanical durability: 10,000,000 switching cycles
  • Environmental protection: NEMA 4, 4X, 13 / IP66 — washdown rated, high-pressure water tested to 1015.26 psi at 131°F
  • Operating temperature: -40°F to +158°F (-40°C to +70°C)
  • Mounting hole: exactly 22 mm ±0.1 mm — not compatible with 24 mm selector switch cutouts
  • Physical dimensions: 1.85 in H x 1.18 in W x 2.05 in D
  • Terminal torque: 0.8 to 1.2 N-m; wire range 14 to 20 AWG
  • Certifications: UL Listed File E164353, CSA Certified File LR44087 Class 321103, CE Marked
  • Button: non-illuminated, flush profile, green — no internal lamp or LED
  • Latching variant: XB4BA24; illuminated variant: XB4BW series — both require separate order
