Schneider LC1D115M7 — 115 A TeSys D Contactor Buyer Guide
Schneider LC1D115M7 — TeSys D Contactor Specs, Pricing and Selection Guide for 115 A Motor Control at 440 V AC
Controls engineers and procurement specialists searching for a 115 A three-pole industrial contactor with a 220 V AC coil are typically at one of two points: verifying the LC1D115M7 against an existing specification, or selecting the right TeSys D frame size for a new motor control application. The Schneider LC1D115M7 is a three-pole AC-3 rated contactor from the TeSys D platform, carrying a 115 A rating at 440 V AC and a 220 V AC 50/60 Hz coil — making it the correct choice for motors in the 30 to 80 kW range when the control supply is confirmed. The single most critical pre-order check is coil voltage: if your facility runs 24 V DC or 380 V AC control circuits, this model is not compatible.
If you have already confirmed this is the right part, check current pricing and availability for the LC1D115M7 at LeadTime.ca — ships worldwide.
Who Should Buy the LC1D115M7 — and Who Should Not
The LC1D115M7 is the right contactor when all five of the following conditions are met:
- Your control circuit supplies 220 V AC at 50 or 60 Hz — not 24 V DC, 380 V AC, or any other voltage
- Motor full-load amperage does not exceed 115 A at the operating voltage (440 V AC or equivalent)
- The application is AC-3 duty — motor starting with inductive load, not resistive heating (AC-1) or plugging (AC-4)
- The main circuit requires three poles with a standard 1 NO and 1 NC mechanically linked auxiliary contact
- DIN rail mounting is available in the enclosure and the TeSys D platform is acceptable
If your motor FLA exceeds 115 A at operating voltage, or your coil supply is 24 V DC, this is not the correct model. The LC1D150M7 or LC1D185M7 addresses higher current requirements, and alternative TeSys D coil variants address different control voltages.
On this page:
- What the LC1D115M7 Actually Does in a Motor Control System
- Typical System Architecture for the LC1D115M7
- Where the LC1D115M7 Is Deployed: Industries and Use Cases
- LC1D115M7 Specifications: What the Purchase Decision Depends On
- LC1D115M7 vs. Other TeSys D Frame Sizes: Which One Do You Actually Need?
- Expert Verdict: Is the LC1D115M7 Worth Ordering for Your Project?
- What Engineers Need to Know Before Ordering the LC1D115M7
- Wiring and Installation Overview
- Wrong-Part Prevention Checklist Before You Order
- Frequently Asked Questions
- Why Order the LC1D115M7 From LeadTime.ca
- At-a-Glance Summary
What the LC1D115M7 Actually Does in a Motor Control System
The LC1D115M7 is an electromechanical industrial contactor — the main switching element that opens and closes the power circuit to a three-phase motor on command. Rated for AC-3 duty at 115 A and 440 V AC, it covers the motor power range most commonly encountered in mid-size industrial facilities: pumps, fans, compressors, and conveyors from 30 kW at 220 V AC up to 80 kW at 660-690 V AC. The three main poles are rated normally open, meaning the motor circuit is de-energized until the 220 V AC coil is energized and the magnetic plunger pulls the contacts closed.
The TeSys D platform is Schneider Electric's flagship medium-duty contactor line. It covers a broad range of inductive motor applications across 11 contactor ratings, which means the LC1D115M7 is not an isolated part — it belongs to a standardized family where overload relays, auxiliary contact blocks, and soft-start bypass kits are designed to coordinate. For facilities already standardized on TeSys D, this translates directly to reduced spare parts inventory complexity and predictable replacement sourcing.
The mechanically linked 1 NO and 1 NC auxiliary contact is included as standard per IEC 60947-5-1. This matters at the BOM level: motor run indication, emergency stop interlock, and fault signaling circuits can be driven directly from the auxiliary contact without adding plug-in relay blocks. The contactor is rated for 8 million mechanical operations at no-load, and at the maximum operating rate of 2400 cycles per hour at 60°C ambient, that represents over 3333 hours of continuous operation before reaching rated mean mechanical life — a specification drawn directly from the official Schneider Electric datasheet.
Typical System Architecture for the LC1D115M7
The LC1D115M7 sits between the motor branch circuit protection device and the motor terminal box, controlled by the coil circuit which connects to the facility's 220 V AC control supply or transformer secondary. A typical deployment looks like this:
- Motor branch circuit fuses or circuit breaker upstream — provides short-circuit protection coordinated with the contactor's 1100 A breaking capacity at 440 V
- LC1D115M7 contactor main contacts — switches the three-phase 440 V AC power circuit to the motor on coil energization
- Overload relay downstream of the contactor — provides thermal protection against sustained overcurrent; must be selected to match motor FLA
- 220 V AC control supply connected to coil terminals — energized through push-button, PLC output, or soft-start trigger circuit
- Auxiliary contacts wired back to PLC input or indicator circuit — provides motor run feedback, interlock signal, or fault annunciation
Where the LC1D115M7 Is Deployed: Industries and Use Cases
The most common deployment for the LC1D115M7 is three-phase pump motor control in water treatment, food and beverage processing, and manufacturing facilities. At 440 V AC and 115 A AC-3 duty, it covers the direct-online starting of pumps in the 30 to 59 kW range at typical North American industrial voltages without oversizing to a more expensive or physically larger contactor frame.
Compressor and air handler applications in industrial HVAC and refrigeration represent the second significant use case. These are typically high-cycle applications where mechanical durability matters — the 8 million mechanical operations rating provides confidence for installations where the contactor may start and stop multiple times per hour across multi-year service periods.
Conveyor and material handling systems in manufacturing, mining, and pulp and paper operations also rely on this rating range. The integrated 1 NO and 1 NC auxiliary contacts support the interlock circuits common in conveyor systems without requiring additional relay hardware.
The LC1D115M7 is also used as the main switching element in magnetic motor starter assemblies, where it is paired with a TeSys D overload relay to form a complete motor protection and control unit. In load-shedding and emergency shutdown circuits, the auxiliary contact provides the status feedback needed for distributed power management systems.
| Application | Typical Deployment |
|---|---|
| Pump motor control (30-80 kW) | Direct-online starting, water treatment and process facilities, 440 V AC three-phase |
| Compressor duty, HVAC and refrigeration | High-cycle switching, industrial chillers and air handling units |
| Conveyor and material handling | Motor switching with auxiliary interlock, manufacturing and mining |
| Magnetic motor starter assembly | Paired with overload relay for complete motor protection in panel builds |
| Load shedding and emergency shutdown | Auxiliary contact wired to PLC or SCADA for status feedback |
| Soft-start bypass circuit | Contactor closes in parallel with soft-start unit after motor reaches speed |
LC1D115M7 Specifications: What the Purchase Decision Depends On
| Parameter | Specification |
|---|---|
| Rated Current — AC-3 (Motor Duty) | 115 A at 440 V AC |
| Rated Current — AC-1 (Non-Inductive) | 200 A |
| Motor Power Range (AC-3) | 30 kW at 220-230 V / 59 kW at 415-440 V / 75 kW at 500 V / 80 kW at 660-690 V |
| Coil Voltage | 220 V AC 50/60 Hz |
| Coil Pickup Voltage Window | 0.8 to 1.15 Uc (176 to 253 V AC) |
| Contact Configuration | 3 poles (3 NO) main + 1 NO + 1 NC auxiliary (mechanically linked) |
| Phase-to-Phase Rated Voltage | 1000 V AC |
| Impulse Voltage (Uimp) | 8 kV |
| Mechanical Durability | 8 million operations (no-load) |
| Mounting Style | DIN rail compatible |
Full technical specifications are available on the product page at LeadTime.ca.
LC1D115M7 vs. Other TeSys D Frame Sizes: Which One Do You Actually Need?
| Model | Rated Current (AC-3) | Motor Power at 440 V (kW) | Coil (M7 Variant) | Best For |
|---|---|---|---|---|
| LC1D09M7 | 9 A | 4 kW | 220 V AC | Small motors, fractional kW applications |
| LC1D25M7 | 25 A | 11 kW | 220 V AC | Light-duty pumps and fans, panel builder stocking |
| LC1D115M7 | 115 A | 59 kW | 220 V AC | Mid-size industrial motors, compressors, conveyors |
| LC1D150M7 | 150 A | 75 kW+ | 220 V AC | Motors where FLA exceeds 115 A at 440 V |
| LC1D185M7 | 185 A | 90 kW+ | 220 V AC | Heavy industrial drives and large compressor duty |
If your motor full-load amperage at 440 V is above 115 A, the LC1D150M7 is the correct next frame up — do not attempt to run a 120 A FLA motor on the LC1D115M7. Check current availability at LeadTime.ca and confirm your frame size before ordering.
Expert Verdict: Is the LC1D115M7 Worth Ordering for Your Project?
The LC1D115M7 is the right contactor for plant electrical engineers and panel builders running motors in the 30 to 80 kW range with a 220 V AC control supply confirmed. At 59 kW motor duty at 415-440 V and an AC-1 rating of 200 A for non-inductive loads, it covers the majority of mid-size industrial motor applications without requiring the larger, more expensive LC1D150 frame. The TeSys D platform brings genuine procurement advantages: broad distributor stocking, well-documented compatibility with standard overload relays and soft-start equipment, and a 8 million mechanical operations rating that supports high-cycle applications over multi-year service life. For facilities already standardized on this platform, it simplifies spare parts inventory and reduces engineering time on component selection.
There are three real limits to acknowledge. First, the coil voltage is fixed at 220 V AC 50/60 Hz — if your facility uses 24 V DC coil control (common in modern PLC-driven panels), this model will not operate without an intermediate transformer or relay. Second, once motor FLA at the operating voltage approaches or exceeds 115 A, the LC1D150M7 is the correct choice — there is no safe margin to stretch the rated current. Third, this contactor has no built-in suppressor module, no integrated diagnostics, and no IoT connectivity. For OEMs or facilities requiring advanced monitoring or silent-operation contactors, a different product family is needed.
From a procurement standpoint, the LC1D115M7 is a standard, widely stocked component through authorized distributors worldwide, which means lead times are generally shorter than for specialty or larger-frame parts. Ordering through a specialist industrial distributor rather than a generic channel matters here because the single most preventable failure mode — receiving the wrong coil voltage — is caught at the order review stage, not after the part arrives on site. Review current pricing and availability for the LC1D115M7 at LeadTime.ca, where the team can confirm coil voltage compatibility and coordinate overload relay selection before shipment.
For volume pricing or to confirm lead time before committing to a build, contact the LeadTime.ca team directly — we ship worldwide.
What Engineers Need to Know Before Ordering the LC1D115M7
Community discussions specific to the LC1D115M7 are sparse — buyers tend to discuss the TeSys D product family broadly rather than individual catalog numbers. What emerges clearly from technical documentation and distributor Q&A is a consistent pattern of pre-order questions that, when answered correctly, prevent the most costly mistakes. The checklist below reflects the real questions that specialist distributors field before shipping this part. Treat it as the pre-order verification sequence, not optional background reading.
The dominant pre-order mistake across this class of industrial contactor is coil voltage mismatch. Modern panel builds increasingly standardize on 24 V DC control for PLC compatibility, and engineers sometimes carry that assumption into contactor selection without checking the specific catalog suffix. The M7 suffix on LC1D115M7 designates the 220 V AC 50/60 Hz coil — a detail that sits in the catalog number itself but is easily overlooked under time pressure. A wrong coil voltage does not cause the contactor to fail gracefully; it either does not pick up at all or, in the case of a significantly overvoltage coil, can cause immediate coil damage.
The second pattern is current margin underestimation. A motor running at 110 A FLA at 440 V looks safe against the 115 A AC-3 rating, but motor inrush current during direct-online starting can reach five to seven times FLA. The contactor's AC-3 rating accounts for this by design, but applying a 10 to 15 percent FLA margin before selecting the frame size is standard practice. If the motor FLA is 110 A or above at 440 V, the LC1D150M7 is the professionally correct recommendation. Specialist distributors who understand TeSys D sizing will flag this automatically — generic channels will not.
Wiring and Installation Overview
- Mount the contactor on a standard 35 mm DIN rail, confirm the rail has sufficient clear space for the contactor width, and verify all panel power is isolated before beginning installation
- Connect main power contacts to the three-pole terminals (line side and load side), using flexible or solid cable within the 1-2.5 mm² range supported by the screw terminals — do not exceed this range or force larger conductors
- Wire the 220 V AC 50/60 Hz coil supply to the coil terminals, sourced from a control transformer or dedicated AC supply routed through the control circuit switching element (push-button, PLC output, or soft-start trigger)
- Connect the mechanically linked 1 NO and 1 NC auxiliary contacts to the indicator, interlock, or PLC input circuit as per the control schematic — these are low-current signaling contacts, not power contacts
- Before applying power, verify all terminal screws are tightened, inspect for loose insulation debris inside the panel, and confirm the coil circuit voltage is within the 0.8 to 1.15 Uc pickup window (176 to 253 V AC) before energizing
Full wiring diagrams and installation procedures are available in the Schneider Electric TeSys D installation manual. Engineers requiring step-by-step commissioning procedures should consult manufacturer documentation directly.
Wrong-Part Prevention Checklist Before You Order
Confirm each item below before submitting your purchase order. These are the seven parameters that, when missed, result in wrong-part shipments, commissioning delays, and avoidable rework costs.
- COIL VOLTAGE: Confirm 220 V AC 50/60 Hz is available in the control circuit. Many plants use 24 V DC — this model will not work with DC.
- RATED CURRENT: Verify motor full-load amperage does not exceed 115 A at the operating voltage (440 V AC). If FLA > 115 A, order next larger frame.
- DUTY CYCLE: Confirm this is for AC-3 (motor starting with locked rotor or running duty). For AC-1 (resistive) or AC-4 (plugging), different performance applies.
- CONTACT CONFIGURATION: This model has 3 main poles + 1 NO + 1 NC auxiliary. Verify your circuit does not require 4 poles or different auxiliary count.
- IMPULSE VOLTAGE: Confirm transient voltage protection rating (8 kV) is acceptable for your system. Some harsh environments require ratings review.
- MOUNTING: Confirm DIN rail space and mounting bracket availability.
- CABLE SIZING: Screw terminals accept 1-2.5 mm² flexible cable. Do not attempt to force larger cable; the contactor may be damaged.
If any item on this checklist cannot be confirmed before ordering, contact the LeadTime.ca team — the technical team can help verify coil voltage, current margin, and duty cycle requirements before your order is placed.
Frequently Asked Questions
Can I use this contactor with a 24 V DC coil supply from my PLC output?
No. The LC1D115M7 has a 220 V AC 50/60 Hz coil. Applying 24 V DC to this coil will result in no pickup — the contactor will not close. If your control circuit is 24 V DC, you need a TeSys D variant with the correct DC coil designation. Confirm your coil supply voltage before ordering; this is the single most common ordering mistake on this model.
What overload relay should I pair with the LC1D115M7 for a complete motor starter?
The LC1D115M7 is designed to work within the TeSys D platform, which includes compatible overload relays rated to coordinate with the 115 A contactor frame. The overload relay must be selected to match the motor's full-load amperage, not the contactor's rated current. Consult the Schneider Electric TeSys D selection guide or contact your distributor to confirm the correct overload relay catalog number for your specific motor FLA.
Does the LC1D115M7 include a built-in surge suppressor for the coil?
No. The LC1D115M7 coil is specified as without a built-in suppressor module. If transient suppression is required for the coil circuit — for example, to protect PLC outputs or sensitive control components — an external varistor or RC network must be added. This is a standard installation consideration when using AC coil contactors in PLC-controlled systems.
My motor FLA is 112 A at 440 V — is the LC1D115M7 safely rated for this application?
At 112 A FLA with a 115 A AC-3 rated contactor, the margin is narrow. Standard engineering practice is to apply a 10 to 15 percent FLA margin when selecting a contactor frame size. A 112 A FLA motor approaches or exceeds this margin on a 115 A contactor, particularly in direct-online starting where inrush can reach five to seven times FLA. In this case, the LC1D150M7 is the professionally correct selection. Confirm your actual motor nameplate FLA and operating voltage before finalizing the order.
Is the LC1D115M7 suitable for switching resistive heating loads at 115 A?
The LC1D115M7 is rated AC-3 (motor starting with inductive load). For resistive heating loads, the relevant duty classification is AC-1, where the rated current is 200 A — not 115 A. This means using the contactor on a resistive load at 115 A is within the AC-1 limit, but the application design should confirm this explicitly. Do not select this model based solely on its AC-3 motor rating for non-motor applications without verifying the AC-1 or other applicable duty class rating.
What does the short-circuit breaking capacity of 1100 A at 440 V mean for fuse coordination?
The 1100 A short-circuit breaking capacity at 440 V defines the maximum fault current the contactor's contacts can interrupt in a fault condition. This figure is used in coordination studies to verify that the upstream fuse or circuit breaker will clear the fault before the contactor contacts are damaged. In most industrial motor branch circuits within this rating range, standard branch circuit fuses will clear well below 1100 A, making this contactor suitable for typical industrial installations without special fuse coordination requirements.
Why Order the LC1D115M7 From LeadTime.ca
- LeadTime.ca ships worldwide — no geographic restriction on sourcing or order fulfillment
- Specialist industrial distributor with technical review at order stage — coil voltage and current margin verification before shipment, not after
- Access to TeSys D platform accessories, overload relays, and auxiliary contact blocks for complete motor starter builds
- Volume pricing available for panel builders and procurement teams — contact for current pricing on multi-unit orders
- Fast response on availability and lead time confirmation for time-sensitive projects and emergency replacements
- View LC1D115M7 pricing and availability at LeadTime.ca
- Contact LeadTime.ca for a quote or technical consultation
At-a-Glance Summary: LC1D115M7 Key Facts
- Three-pole AC-3 industrial contactor rated 115 A at 440 V AC, part of Schneider Electric's TeSys D platform
- Motor power range: 30 kW at 220-230 V AC up to 80 kW at 660-690 V AC under AC-3 duty
- Coil voltage: 220 V AC 50/60 Hz only — pickup window 0.8 to 1.15 Uc (176 to 253 V AC)
- Contact configuration: 3 main poles (3 NO) plus 1 NO and 1 NC mechanically linked auxiliary contacts per IEC 60947-5-1
- Mechanical durability: 8 million operations at no-load; maximum operating rate 2400 cycles/hour at 60°C ambient
- Impulse voltage (Uimp): 8 kV; short-circuit breaking capacity 1100 A at 440 V per IEC 60947
- No built-in coil suppressor module — external suppression required for sensitive control circuits
- DIN rail compatible; screw terminals accept 1-2.5 mm² flexible or solid cable
- Requires external overload relay and branch circuit protection for complete motor starter compliance
- Standard, widely stocked TeSys D platform part — available through authorized distributors worldwide including LeadTime.ca
