Schneider RM17TE00 Harmony 3-Phase Supply Control Relay: Specs, Pricing & Selection Guide

If you are a controls engineer or panel builder searching for a compact, hardwired phase monitoring relay to protect three-phase motor loads from phase loss, sequence faults, or voltage asymmetry, the Schneider RM17TE00 is one of the most frequently specified solutions in the Harmony RM17 family. It monitors all three phases simultaneously across a 183–528 VAC input range — covering 208, 240, 277, 380, 400, 415, and 480 VAC without any SKU variant swaps — and delivers a single SPDT output contact rated 5A at 250 VAC to interlock motor starters or contactors the moment a fault is detected. At just 0.69 inches wide on a 35mm DIN rail, it fits tight panels where a PLC-based protection function simply is not justified.

If you have already confirmed this is the right part, check current pricing and availability at LeadTime.ca — ships worldwide.

Who Should Buy the RM17TE00 — and Who Should Not

The Schneider RM17TE00 is the right choice for engineers and technicians who need self-contained, hardwired three-phase fault detection without PLC programming overhead. It is a fit if all of the following apply to your application:

  • Your incoming supply is confirmed three-phase AC — not single-phase or DC
  • Your supply voltage falls within the 183–528 VAC band (208, 240, 277, 380, 400, 415, or 480 VAC all qualify)
  • Your switched load does not exceed 5A at 250 VAC (1250 VA maximum switching capacity)
  • Your panel uses 35mm DIN rail and screw-terminal wiring (M2 connectors, 0.5–1.5 mm² wire gauge)
  • You need simultaneous detection of phase sequence, phase failure, and phase imbalance in a single device
  • A 1500 ms reset time is acceptable for your motor protection scheme

If your load current exceeds 5A, you need Modbus or network connectivity, or your supply is single-phase or above 528 VAC, the RM17TE00 is not the correct part. See the variant comparison table below for alternatives within the Harmony RM17 family and beyond.

On this page:

What the RM17TE00 Actually Does in a Motor Protection Circuit

The Schneider RM17TE00 is a DIN rail-mounted three-phase supply control relay from the Harmony RM17 series — part of Schneider Electric's Zelio Control brand line. Its single job is to watch all three phases of an incoming AC supply simultaneously and open its output contact the moment something goes wrong. That output contact — a single SPDT (1 Form C) device rated 5A at 250 VAC with a 1250 VA switching capacity — is typically wired in series with a motor contactor's enable coil, so any detected fault immediately de-energizes the motor before damage can occur.

What makes this relay worth specifying over a generic phase monitor is the breadth of its detection logic. The RM17TE00 covers phase sequence (wrong rotation direction), phase failure (complete loss of any one of the three phases to below 10% of nominal voltage), phase imbalance or voltage asymmetry between phases, and both undervoltage and overvoltage window violations — all in one 17.5 mm wide device. The LED indicator on the front face gives real-time status: green when all three phases are healthy, red on any fault condition. No data logging, no software, no network — just a hardwired protection layer that activates within 1500 milliseconds of detecting a fault and supports up to 360 operating cycles per hour under full load, making it genuinely suitable for motor-duty applications with frequent start-stop cycles.

The relay's input supply range of 183–528 VAC covers every standard North American three-phase voltage class — 208, 240, 277, 380, 400, 415, and 480 VAC — without requiring different SKUs for different voltage applications. This single-SKU global coverage, confirmed across multiple authorized distributor specification sheets, means a panel builder or system integrator can standardize on one part number across facilities running different supply voltages worldwide.

Typical System Architecture: Where the RM17TE00 Sits in the Signal Chain

The RM17TE00 sits downstream of the main disconnect and upstream of the motor starter or contactor, acting as a protective gate that validates the incoming three-phase supply before allowing motor equipment to run.

  • Incoming three-phase supply (208–480 VAC) → Main disconnect or feeder breaker
  • Feeder breaker output → RM17TE00 input terminals (L1, L2, L3) for phase monitoring
  • RM17TE00 SPDT output contact → Motor contactor enable coil (normally closed configuration de-energizes contactor on fault)
  • Motor contactor output contacts → Motor terminals (three-phase load)
  • Optional: RM17TE00 combined with overload relay and soft-starter for layered motor protection upstream of the contactor

Typical Applications and Industries

The RM17TE00 sees its heaviest use in facilities where three-phase motor loads run continuously and where a single-phase loss event would cause equipment damage or production stoppage. Food and beverage processing plants rely on it to protect pump motors driving CIP systems and conveyors. Water and wastewater treatment facilities use it on submersible pump feeders in remote buildings where no PLC is present. HVAC and refrigeration installers specify it to protect compressor motors from phase imbalance common in commercial buildings with older distribution systems.

In metalworking and machine tool shops, the RM17TE00 is frequently installed on CNC spindle feeder circuits and coolant pump lines where phase sequence errors after maintenance can spin motors in the wrong direction. Pulp and paper operations use it on agitator and conveyor drives where a phase loss would not immediately trip an overload but would overheat motor windings over time. Automotive assembly lines install it at multi-motor production stations where one relay protects the entire station's three-phase supply rather than each individual motor.

System integrators building motor-protection panels for backup generator installations find particular value in the RM17TE00's phase imbalance detection, since generator output during load transfer frequently produces voltage asymmetry beyond the typical +/- 10% threshold before stabilizing — allowing the relay to prevent motor spin-up under fault conditions during generator commissioning or transfer events.

Application Typical Deployment
Motor pump protection (remote building) Single RM17TE00 on feeder circuit; SPDT contact wired to pump contactor coil; no PLC required
Compressor feeder (hardwired control) Relay installed downstream of feeder breaker; protects compressor motor from single-phase loss and sequence faults
VFD or soft-starter pre-run validation RM17TE00 monitors VFD input supply; SPDT contact prevents drive enable until all three phases are confirmed healthy
Backup generator / microgrid transfer Relay detects voltage asymmetry and phase sequence errors during generator load transfer; prevents premature motor start
Multi-motor production station One relay on common three-phase bus halts entire station on phase fault; prevents partial operation and cascading damage
HVAC / refrigeration compressor protection Installed on compressor feeder in commercial building; monitors for imbalance caused by aging distribution infrastructure

Purchase-Decision Specifications at a Glance

Specification Value Notes
Input Supply Voltage Range 183–528 VAC, 3-phase, 50/60 Hz Covers 208, 240, 277, 380, 400, 415, 480 VAC — single SKU for all standard classes
Contact Configuration 1 SPDT (1 Form C / 1 changeover) Single output contact; used to interlock motor contactor or alarm circuit
Contact Current Rating 5A at 250 VAC Maximum 1250 VA switching capacity; do not exceed for load switching
Rated Coil Voltage 250 VAC / VDC Both AC and DC coil operation supported per spec sheet
Reset Time 1500 ms (typical) Delay from fault detection to contact action; suitable for motor-duty applications
Operating Rate 360 cycles per hour at full load Motor-duty rated; supports frequent start-stop cycling
Mounting Standard 35mm DIN rail Industry-standard mounting; 0.69 inches (17.5 mm) wide
Terminal Type Screw-terminal (M2, 0.5–1.5 mm² wire gauge) No spring-clamp; standard industrial panel wiring
Operating Temperature -40 to 158°F (-40 to 70°C) Full industrial temperature range; suitable for unheated enclosures
Certifications UL E173076, CSA 248382, CE, RoHS, EN/IEC 60255-6, C-Tick North American, European, and Australian compliance confirmed

Full technical specifications are available on the product page at LeadTime.ca.

RM17TE00 vs. RM17TF, RM17TC, and Competitor Relays: Which One Do You Actually Need?

The most common ordering error in the Harmony RM17 family is confusing the RM17TE00 with the RM17TF or RM17TC variants. These are not interchangeable without a wiring schematic revision. The table below clarifies the key differences and when to choose each alternative.

Model Manufacturer Key Difference vs. RM17TE00 Choose When
RM17TE00 Schneider Electric Baseline: 1 SPDT output, 183–528 VAC input, 35mm DIN rail, screw terminal Standard 3-phase hardwired protection; most motor-protection panel applications
RM17TF Schneider Electric 3-position logic (fork output); different contact configuration — NOT a drop-in swap Applications requiring fork-style output logic; verify contact diagram before ordering
RM17TC Schneider Electric Compact variant; smaller footprint and different physical dimensions Ultra-tight panel spaces where the standard RM17TE00 width cannot be accommodated
Siemens 3RN1011 Siemens Broader voltage range (75–264 VAC); larger housing; similar price bracket Applications outside 183–528 VAC band or where Siemens ecosystem is already standardized
Eaton EPS9 Eaton/Moeller Simpler logic (phase loss detection only, no asymmetry); lower price point Budget-constrained applications where phase imbalance detection is not required
Rockwell CompactGuard Rockwell Automation Module-based; requires ControlLogix chassis; network-capable Facilities with full ControlLogix infrastructure needing integrated network monitoring

If your application requires a different contact configuration or a load current above 5A, the RM17TF or an external contactor approach is the correct path — check current availability of the RM17TE00 at LeadTime.ca and contact the team if you need help confirming the right variant for your schematic.

Expert Verdict: Is the RM17TE00 Worth Buying?

The Schneider RM17TE00 is the right choice for a specific and well-defined buyer: maintenance teams and panel builders who need a self-contained, code-compliant three-phase monitoring solution that installs in minutes on a 35mm DIN rail and requires zero software commissioning. Its 183–528 VAC input range makes it genuinely universal across North American and international three-phase voltage classes without ordering a different SKU. The 360 cycles-per-hour operating rate and 1500 ms reset time make it legitimate for motor-duty protection on frequent start-stop applications — not just alarm signaling. For facilities without PLC infrastructure, or for system integrators who need a clean, documented relay logic solution rather than a software function block, this relay delivers exactly what it promises.

It has real limits, and buyers should be honest with themselves about them. The 5A contact rating at 250 VAC caps the direct switching load at 1250 VA — you are not switching large loads through this contact, you are interlocking a contactor coil or a control circuit. If you need switching current above 5A, you need a different device. If you need Modbus, PROFINET, or any form of network monitoring, the RM17TE00 has no path there — it is a hardwired relay, full stop. And it carries no internal circuit breaker; external upstream protection is mandatory and non-negotiable for code compliance. Buyers comparing it to the RM17TF should note that the contact configuration is fundamentally different — the fork output on the RM17TF is not a substitute without a wiring revision.

On the procurement side, the RM17TE00 is a mature, continuously produced part in the Harmony RM17 series with consistent stocking at authorized Schneider Electric distributors. Typical lead times through stocking distributors run 1–5 business days. Buying through an authorized channel versus a generic marketplace matters here: you get verified stock condition, accurate current datasheets, and technical support from staff who can answer commissioning questions — not just pick and ship. For a mission-critical motor protection component, that support layer is worth the modest premium over surplus or secondary-market pricing. View current pricing and availability for the RM17TE00 at LeadTime.ca — the team ships worldwide and can confirm lead time before you commit to a build schedule.

For volume pricing or to confirm lead time before committing to a build, contact the LeadTime.ca team directly — we ship worldwide.

What Engineers Need to Know Before Ordering the RM17TE00

The RM17TE00 is what the industry calls a solved component — a mature, stable product that has been deployed in hundreds of thousands of industrial installations worldwide under the Zelio Control and Harmony RM17 brand lines. Because it is viewed as standard hardware rather than a complex device requiring public troubleshooting threads, community forum activity on this specific model is limited. Engineers who run into application questions tend to resolve them directly with their Schneider Electric distributor rather than posting publicly. That is actually a signal about the product's maturity — not a gap in documentation.

What that means practically for buyers is that the most important knowledge is pre-order, not post-installation. The wrong-part mistakes that occur with the RM17TE00 almost always happen before the relay reaches the panel — wrong variant ordered (RM17TF or RM17TC instead of RM17TE00), supply voltage outside the 183–528 VAC band not caught in time, or load current exceeding the 5A contact rating discovered only when trying to wire a larger contactor coil. The brief from verified distributor sources is consistent: measure your actual phase-to-phase voltages at the panel before ordering, confirm your controlled load is within the 5A switching ceiling, and verify the screw-terminal M2 connection style matches your wiring practice.

Engineers who have commissioned similar Harmony RM17 series relays consistently flag two field realities worth knowing. First, the factory threshold settings are appropriate for the vast majority of 208–480 VAC installations — adjusting the voltage window narrower than +/- 8% of nominal without a documented reason leads to nuisance trips on supply fluctuations that are completely normal for the facility's distribution system. Second, the coil voltage requirement of 250 VAC catches technicians accustomed to 24 VAC control circuits — if your panel runs 24 VAC control voltage, you need a step-down transformer upstream of the relay coil, or the relay will not respond at all. Both of these are straightforward to address at the design stage and are the kind of application-specific guidance that a specialist distributor like LeadTime.ca can confirm when you request a quote.

Wiring and Installation Overview

The RM17TE00 mounts on a 35mm DIN rail and connects via screw terminals (M2, 0.5–1.5 mm² wire gauge). Before beginning any installation, verify de-energization with a multimeter on all three phases. Key wiring requirements:

  • Connect incoming three-phase supply to L1, L2, L3 input terminals; torque screw terminals firmly to prevent loosening under panel vibration
  • Connect the relay coil (marked ~ or AC) to a 250 VAC control supply — confirm voltage at coil terminals with a voltmeter before energizing; 24 VAC control circuits require a step-down transformer
  • Wire the SPDT output contact (Common, Normally Open, Normally Closed) to the motor contactor enable coil — typical configuration uses the Normally Closed terminal so that any fault or loss of power de-energizes the contactor
  • Ensure external upstream circuit protection is installed before the relay input; the RM17TE00 has no internal circuit breaker
  • After wiring, apply power and confirm the LED indicator shows green for a healthy three-phase supply before placing the controlled equipment in service

For full wiring diagrams and connection procedures, refer to the official Schneider Electric datasheet for the RM17TE00.

Commissioning and Threshold Adjustment Overview

Configuration of the RM17TE00 requires no software — all adjustments are made via potentiometer knobs on the relay front face. Key commissioning steps:

  • With three-phase supply applied and LED showing green, verify that all three phase voltages are within the expected range using a multimeter at the relay input terminals before adjusting any thresholds
  • Factory default threshold settings are appropriate for standard 208–480 VAC installations; do not adjust unless there is a documented application reason
  • If threshold adjustment is required, never set the voltage window narrower than +/- 8% of nominal voltage — tighter settings will cause nuisance trips on normal supply fluctuations
  • Test phase sequence detection by temporarily swapping two incoming phase wires; LED should change to red, confirming sequence logic is active; restore wires and confirm LED returns to green
  • Test phase failure detection by temporarily interrupting one phase; relay should trip to red within approximately 1500 ms; restore the phase and confirm LED returns to green

For complete commissioning procedures and threshold adjustment tables, consult the official RM17TE00 datasheet from Schneider Electric.

Wrong-Part Prevention Checklist

Before finalizing your order for the Schneider RM17TE00, run through the following six checks — these are the most common pre-purchase errors that result in a relay that cannot be installed without redesign or re-ordering:

  1. Confirm your incoming power supply is 3-phase AC (not single-phase or DC)
  2. Verify supply voltage falls within 183-528 VAC range (most common: 208, 240, 277, 380, 400, 415, 480)
  3. Check that your load current does not exceed 5A at 250 VAC (if higher, escalate to heavier relay)
  4. Ensure your panel has 35mm DIN rail available (not 15mm rail or no rail)
  5. Confirm screw-terminal connection is acceptable (not requiring spring-clamp style)
  6. Verify you are NOT requiring an integrated circuit breaker (RM17TE00 has no internal breaker; external protection required)

If all six checks pass, the RM17TE00 is confirmed for your application. View current stock and pricing at LeadTime.ca — or contact the team if you need help verifying a detail before ordering.

Frequently Asked Questions

Does the RM17TE00 monitor all three phases independently, or does it only detect total phase loss?

The RM17TE00 monitors all three phases simultaneously and detects multiple fault types independently: complete phase failure (any one of the three phases dropping below 10% of nominal), phase sequence errors (wrong rotation direction), and phase imbalance or voltage asymmetry between phases. It also provides adjustable undervoltage and overvoltage window detection. This multi-function detection is the primary reason it is specified over simpler phase-loss-only devices like the Eaton EPS9.

Does the RM17TE00 have an internal circuit breaker, or do I need to add external protection?

The RM17TE00 has no internal circuit breaker. External upstream circuit protection is mandatory and required for code compliance — this is one of the six wrong-part prevention checks and is the most frequently missed requirement during panel design. Install a properly rated breaker or fuse upstream of the relay input terminals before energizing.

What actually happens when one phase is lost — how fast does the relay respond?

When any single phase drops below 10% of nominal voltage, the relay detects the fault and opens its output contact after the 1500 ms reset time. This de-energizes whatever is wired to the SPDT contact — typically a motor contactor coil — stopping the motor before extended single-phase operation can overheat the windings. At 360 operating cycles per hour, the relay is rated to handle this response cycle repeatedly in motor-duty start-stop applications.

Can I use the RM17TE00 with a VFD, and if so, on which side of the drive?

Yes, but only on the input (supply) side of the VFD. The RM17TE00 monitors the incoming three-phase supply feeding the VFD and prevents the drive from starting if a phase fault is present. It is not suitable for monitoring the VFD's output terminals, because VFD output waveforms are not standard three-phase AC and will cause erratic relay behavior.

Is the RM17TE00 a direct replacement for an RM17TE (without the 00 suffix), and are the terminals pin-compatible?

The RM17TE00 is the current catalog number in the Harmony RM17 series. If you are migrating from a legacy installation with an RM17TE unit, verify terminal pin-for-pin compatibility against both units' datasheets before ordering production quantities. Do not assume suffix variations are interchangeable without checking the contact configuration diagram — the RM17TF, for example, has a different contact logic and is not a drop-in replacement.

Does the RM17TE00 require a PLC or any external programming to operate?

No. The RM17TE00 is entirely self-contained. All detection logic is pre-engineered into the relay hardware. Configuration is limited to analog potentiometer adjustments on the front face for voltage window thresholds — no software, no PLC, no external controller required. This is one of its primary advantages for legacy hardwired control systems and remote installations without automation infrastructure.

Why Order the RM17TE00 from LeadTime.ca

  • Worldwide shipping — no geographic restrictions on where LeadTime.ca can fulfill orders
  • Authorized distributor sourcing — confirmed stock condition, current datasheets, and warranty coverage on every unit
  • Technical team available to verify model number, variant, and application fit before you commit to an order
  • Volume pricing available — contact for current tier pricing on multi-unit orders
  • Fast response on lead time confirmation — critical for panel builds with firm commissioning dates

Closing Summary: RM17TE00 at a Glance

  • Three-phase AC monitoring relay from Schneider Electric's Harmony RM17 / Zelio Control series
  • Input supply range: 183–528 VAC, 3-phase, 50/60 Hz — covers 208, 240, 277, 380, 400, 415, and 480 VAC in a single SKU
  • Output: 1 SPDT contact rated 5A at 250 VAC, 1250 VA switching capacity
  • Detects phase failure, phase sequence errors, phase imbalance, undervoltage, and overvoltage
  • Reset time: 1500 ms; operating rate: 360 cycles per hour at full load
  • Mounting: 35mm DIN rail; width: 0.69 inches (17.5 mm); screw-terminal wiring (M2, 0.5–1.5 mm²)
  • Operating temperature: -40 to 158°F (-40 to 70°C)
  • Certifications: UL E173076, CSA 248382, CE, RoHS, EN/IEC 60255-6, C-Tick
  • No internal circuit breaker — external upstream protection required
  • No network connectivity — hardwired-only; no Modbus, no PROFINET
  • Coil voltage: 250 VAC/VDC — 24 VAC control circuits require a step-down transformer
  • Typical stocking lead time through authorized distributors: 1–5 business days
