Schneider LUB32 Power Base — 32A TeSys U Specs & Buying Guide

By Abdullah Zahid
14 min read
Schneider LUB32 non-reversing TeSys Ultra 32A 690V motor starter power base for industrial three-phase motor control

Schneider LUB32 Non-Reversing Power Base, TeSys Ultra, 3P, 1NO + 1NC, 32A, 690V — Complete Specifications, Pricing, and Selection Guide for Industrial Motor Control

Controls engineers and MRO buyers searching for the Schneider LUB32 power base specifications are typically at a clear decision point: they have a three-phase motor up to 32A, they are working within the TeSys U platform, and they need to confirm this is the right SKU before placing the order. The LUB32 is the power-switching half of a modular motor starter — a 32A, 230V–690V non-reversing power base with 3 normally open power contacts, 1NO + 1NC auxiliary contacts, a 50kA breaking capacity at 400V, and a 15-million-cycle mechanical life rating. It is not a complete starter on its own, and that distinction matters before anything else.

If you have already confirmed the LUB32 is the correct part for your application, check current pricing and availability at LeadTime.ca — we ship worldwide.

Who Should Buy the LUB32 — and Who Shouldn't

The Schneider LUB32 is the right choice for engineers and buyers who can confirm all of the following:

  • Motor full-load current does not exceed 32A and cable ampacity is sized accordingly.
  • Three-phase supply voltage at the facility falls within the 230V–690V AC range.
  • The motor application is non-reversing — forward operation and stop only, with no forward/reverse duty required.
  • Screw-clamp terminal connections are acceptable for the installation's cable and lug configuration.
  • An external overload relay or motor protection device will be installed in series — the LUB32 does not include overload protection, and IEC 60947-6-2 mandates it.
  • A compatible LUC control unit will be ordered separately to complete the TeSys U starter assembly.

If your motor exceeds 32A, consider the LUB63 or LUB115. If forward/reverse operation is required, the LUR32 reversing power base is the correct selection — not the LUB32.

On this page:

What the LUB32 Does in a TeSys U Motor Starter System

The Schneider LUB32 is the power distribution and load-switching component of a TeSys U modular motor starter. It is responsible for receiving three-phase supply power, switching it to the motor on command, and providing auxiliary contacts for interlocking and feedback signals. What it does not do is provide the operator interface, control logic, or overload protection — those functions belong to the LUC control unit and an external overload relay respectively.

The LUB32 carries three normally open power contacts that close to connect the motor to the supply. A separate 1NO + 1NC auxiliary contact pair allows panel builders to wire interlock circuits or feedback signals to PLCs and safety relays. The screw-clamp terminals (M6 and M8 lugs) accept properly sized cable lugs for 32A service. With a breaking capacity of 50kA at 400V, the unit handles the fault-interruption demands of industrial environments where upstream protection devices may not catch fault currents before they reach the starter level.

The rated 15-million mechanical cycle life is not a marketing figure — it is a formal specification that positions the LUB32 for high-frequency start/stop applications in manufacturing, pump stations, and material handling where contactors are operated many times per shift. The electrical life at rated current is 3,000,000 cycles, which governs replacement intervals in truly demanding duty profiles.

Typical System Architecture for a TeSys U Starter

The LUB32 sits between the upstream protective device and the motor load, functioning as the controlled switching element that opens and closes the motor circuit on command from the LUC control unit mounted above it.

  • Upstream: Three-phase circuit breaker or fused disconnect providing branch circuit protection for the 230V–690V supply.
  • External overload relay (mandatory): Installed in series with the motor circuit, between the LUB32 output terminals and the motor — provides thermal protection per IEC 60947-6-2.
  • LUB32 power base: Switches three-phase motor load; provides 1NO + 1NC auxiliary contacts for interlock and feedback wiring.
  • LUC control unit (ordered separately): Plugs into the top of the LUB32; provides operator push-button interface, control logic, and auxiliary switching for the complete starter assembly.
  • Downstream: Three-phase induction motor up to 32A full-load current, connected to output terminals T1, T2, T3 via the overload relay.

Typical Applications and Deployment Scenarios

The LUB32 is specified most frequently in fixed-speed, single-direction motor control applications where a proven modular platform and broad certification coverage simplify both the build and the compliance documentation. Its ATEX certification makes it one of the few power bases at this current rating that can be deployed in hazardous-area installations without requiring a separately certified housing.

In manufacturing environments — automotive assembly, food and beverage processing, chemical handling, and metals production — the LUB32 appears in conveyor drive panels, mixer control cabinets, and material handling systems where motors run in one direction continuously or cyclically. The modular architecture means a panel builder can stock a single power base variant and swap control units depending on the operator interface required for each machine.

Water and wastewater treatment facilities use the LUB32 for pump station motor control, where non-reversing duty is standard and where the DNV, BV, and GL marine certifications carry secondary value for coastal or offshore utility installations. In HVAC applications, the unit suits fan and pump drives running at fixed speed without reversing requirements.

MRO buyers and maintenance teams specify the LUB32 as a direct replacement in existing TeSys U installations where a power base has reached end of electrical life or has failed under fault conditions. The modular design allows the power base to be replaced without disturbing the control unit wiring.

Application Typical Deployment
Conveyor drive control Fixed-speed, non-reversing motor control in manufacturing and logistics facilities
Pump station motor starter Water treatment, irrigation, and wastewater — single direction duty, frequent cycling
Hazardous-area motor start ATEX-certified enclosures in chemical and petrochemical plants with flammable gas or dust
OEM machine panel build Mixing equipment, material handling, and packaging machinery requiring modular starter architecture
MRO replacement in TeSys U systems Direct swap of failed power base in existing TeSys U installations to maintain platform consistency
Marine and offshore motor control DNV, BV, GL-certified installations in marine power distribution panels

LUB32 Key Electrical Specifications

Specification Value
Rated Current 32A
Supply Voltage Range 230V–690V AC
Frequency Range 40–60 Hz
Number of Poles 3 (three-phase)
Power Contacts 3 NO (normally open)
Auxiliary Contacts 1 NO + 1 NC
Breaking Capacity (Icu) @ 400V 50 kA
Mechanical Life 15,000,000 cycles
Terminal Type Screw clamps (M6 and M8 lugs)
Certifications UL, CSA, ATEX, BV, DNV, GL, GOST, CCC

Full technical specifications are available on the product page at LeadTime.ca.

LUB32 vs. LUB63 vs. LUB115 vs. LUR32 — Which Power Base Do You Actually Need?

Current rating and direction of rotation are the two variables that determine which TeSys U power base belongs in your panel. The LUB32 is correct only when motor full-load current is at or below 32A and the application is non-reversing. Any deviation from those two conditions requires a different model.

Feature LUB32 LUB63 LUB115 LUR32 (Reversing) LUR63 (Reversing)
Rated Current 32A 63A 115A 32A 63A
Max Voltage 690V 690V 690V 690V 690V
Reversing Capable No No No Yes Yes
Auxiliary Contacts 1NO+1NC 1NO+1NC 1NO+1NC 1NO+1NC 1NO+1NC
Breaking Capacity @ 400V 50 kA 100 kA 150 kA 50 kA 100 kA
Mechanical Life (cycles) 15M 15M 15M 15M 15M
ATEX Rated Yes Yes Yes Yes Yes
Terminal Type Screw Screw Screw Screw Screw

If your motor full-load current exceeds 32A, the LUB63 or LUB115 is the correct selection. If the application requires forward/reverse operation — hoists, ball mills, reversible pumps, or any bidirectional duty — the LUR32 is the correct choice, not the LUB32. Check current availability and confirm your variant at LeadTime.ca before placing the order.

Expert Verdict: Is the LUB32 the Right Power Base for Your Project?

The Schneider LUB32 is a well-proven, standards-compliant power base for fixed-speed three-phase motor control in the 32A bracket. Its 15-million mechanical cycle life, 50kA breaking capacity at 400V, and certification portfolio spanning UL, CSA, ATEX, BV, DNV, and GL make it a predictable choice for plant engineers who need a component that will perform across a wide range of facilities, voltages, and regulatory environments without demanding special handling. The modular TeSys U architecture is a genuine operational advantage for OEMs and integrators: one power base variant pairs with multiple LUC control unit configurations, which reduces spare parts inventory and simplifies field replacements across a fleet of machines.

The LUB32 has real limits that buyers must acknowledge before specifying it. It is a non-reversing device — there is no workaround for reversing duty, and selecting this model for a forward/reverse application means a complete replacement once the error is discovered in the field. Motors above 32A full-load current require the LUB63 or LUB115; undersizing the power base is a reliability and safety failure. The LUB32 also ships without overload protection of any kind — this is not an oversight or a cost-cutting measure, it is the modular architecture by design, and IEC 60947-6-2 is explicit that external protection is mandatory. Buyers who find the modular approach inconvenient or who are locked into a competitor hardware ecosystem (Siemens SIRIUS, ABB PSR) should evaluate whether platform switching makes sense for their application, understanding that these alternatives are not plug-and-play replacements and require full starter assembly redesign.

From a procurement standpoint, the LUB32 is a stocked industrial component with availability through authorized distributors globally, but lead times can vary — particularly for ATEX-certified configurations in hazardous-area projects where compliance documentation adds to order complexity. Ordering through a specialist industrial distributor rather than a generic channel matters here: you get verified stock status, realistic delivery commitments, and pre-sales support to confirm that both the LUB32 and the required LUC control unit are on the same purchase order before anything ships. View current pricing and availability for the LUB32 at LeadTime.ca — we stock and ship industrial automation components worldwide.

For volume pricing, project-quantity commitments, or to confirm lead time before locking in a build schedule, contact the LeadTime.ca team directly — we ship worldwide and can provide accurate sourcing timelines for both the power base and compatible control units.

What Engineers Need to Know Before Ordering the LUB32

Because community forum data on the Schneider LUB32 is sparse — this is a specialized B2B industrial component that engineers typically specify confidently without public troubleshooting threads — the most valuable pre-purchase guidance comes directly from the technical documentation and from the ordering mistakes that distributor sales teams encounter repeatedly. The absence of forum complaints is itself a signal: the TeSys U platform is mature, the LUB32 behaves predictably, and most problems arise not from the component itself but from specification errors made before the order is placed.

The three ordering mistakes that appear consistently in distributor pre-sales conversations are: ordering the LUB32 without simultaneously ordering the LUC control unit (the power base arrives and the buyer realizes there is no operator interface or control logic — a project-halting omission); selecting LUB32 for an application that requires reversing duty because the distinction between LUB (non-reversing) and LUR (reversing) model codes is easy to overlook; and omitting the external overload relay from the bill of materials on the assumption that the power base or control unit provides motor protection. None of these mistakes are discovered until commissioning, and all of them result in delays that a five-minute pre-order verification would have prevented.

When community guidance is not available, the right move is to work with a distributor who understands the TeSys U architecture well enough to catch these gaps before the purchase order closes. LeadTime.ca's team can confirm that your order includes both the LUB32 and a compatible LUC control unit, verify that the 32A rating matches your motor nameplate, and flag reversing-duty requirements before the wrong SKU ships. That pre-sales check is the practical substitute for community validation when forum data does not exist.

Wiring and Installation Overview

The following overview covers the key requirements and verification steps for installing the LUB32. Full wiring procedures, terminal torque values, and wire gauge specifications are available in the Schneider Electric product datasheet and IEC 60947-6-2 documentation — consult those sources for step-by-step installation guidance.

  • Turn off and verify the main supply circuit breaker is de-energized before making any terminal connections to the LUB32 supply input (L1, L2, L3) or motor output terminals (T1, T2, T3).
  • Supply input cables must be fitted with properly sized ring or open cable lugs compatible with the M6 and M8 screw-clamp terminals; verify wire gauge against the 32A thermal current rating and applicable local electrical code.
  • Motor output terminals must route through the external overload relay before connecting to motor terminals U1, V1, W1 — never connect LUB32 output directly to the motor without overload protection in series.
  • The LUC control unit is inserted into the mounting cavity on top of the LUB32 by aligning the plug connectors; verify the assembly sits flush with no misaligned pins before applying power.
  • Auxiliary contacts (1NO + 1NC) are available for interlock or feedback wiring to PLCs, safety relays, or indicator circuits; confirm auxiliary circuit voltage and current ratings against the connected device specifications before wiring.

Wrong-Part Prevention Checklist Before You Order

Review each point against your project requirements before submitting a purchase order for the Schneider LUB32. This checklist is drawn directly from specification constraints and the most common ordering errors encountered in TeSys U deployments.

  1. Confirm motor nameplate full-load current does not exceed 32A (or select higher rated base).
  2. Verify three-phase supply voltage is between 230V and 690V; if lower (e.g., 208V single-phase), confirm compatibility with local standards.
  3. Check if motor must start and stop only (non-reversing)—if forward/reverse is required, select LUR base, NOT LUB32.
  4. Confirm external overload relay or motor protection device will be installed; power base alone does NOT provide overload protection.
  5. Verify screw-clamp terminal compatibility with available cable glands and wire gauges for the 32A rating.
  6. Confirm LUC control unit (not included) is ordered separately and compatible with TeSys U platform.

If any item on this checklist cannot be confirmed before ordering, contact the LeadTime.ca team for pre-sales technical support — we can help verify the correct SKU for your application before the order ships.

Frequently Asked Questions

What is the difference between the LUB32 and the LUR32, and how do I know which one my application needs?

The LUB32 is a non-reversing power base — it controls forward operation and stop only. The LUR32 is the reversing variant, capable of switching motor direction by controlling two sets of contactors in opposing phase sequences. If your motor application requires both forward and reverse rotation — hoists, bidirectional conveyors, reversible pumps, or ball mills — the LUR32 is the correct selection. If the motor only needs to start and stop in one direction, the LUB32 is appropriate. The model code distinction (LUB vs. LUR) is the single most important check before ordering.

Does the LUB32 include overload protection, or do I need to source a separate overload relay?

The LUB32 does not include overload protection. It is a power-switching device only. An external overload relay or motor protection device must be installed in series with the motor circuit — this is a mandatory requirement under IEC 60947-6-2 and is not optional regardless of application. Thermal overload relays such as those in the Schneider LRE or LRD series are commonly used with TeSys U starters, but compatibility with your motor rating and cable sizing must be verified separately before ordering.

Can the LUB32 be used with a single-phase supply, or is it three-phase only?

The LUB32 is a three-phase power base with 3 normally open power contacts and is rated for three-phase AC supply between 230V and 690V at 40–60 Hz. Single-phase applications are outside the standard design intent of this product. If your facility operates on single-phase supply, verify compatibility with Schneider Electric technical support and applicable local electrical standards before specifying the LUB32.

What LUC control unit do I pair with the LUB32, and are control units interchangeable across power base sizes?

The LUB32 requires a compatible LUC control unit from the TeSys U series to form a complete motor starter. LUC control units are not included with the power base and must be ordered separately. The modular architecture of TeSys U allows a single LUC control unit type to be used across different LUB power base ratings (LUB32, LUB63, LUB115), which is one of the platform's primary advantages for OEMs and panel builders managing multiple motor sizes. Verify the specific LUC model designation against your control requirements — logic type, push-button configuration, and auxiliary output needs — using Schneider Electric's product documentation.

What happens if my motor's full-load current is slightly above 32A — can I derate or use the LUB32 anyway?

No. The 32A rated current is the thermal and switching limit for the LUB32. Operating above this rating risks premature contact wear, reduced breaking capacity, and potential failure under overload or fault conditions. If motor full-load current exceeds 32A, the correct selection is the LUB63 (63A rated) or LUB115 (115A rated) power base. There is no derating provision for operating the LUB32 above its nameplate current rating.

Is the LUB32 suitable for hazardous-area installations, and what certification applies?

Yes. The LUB32 carries ATEX certification, which qualifies it for use in potentially explosive atmospheres where flammable gases or combustible dust may be present. It also holds BV, DNV, and GL certifications for marine and offshore environments. If your application is in a classified hazardous area, verify the specific ATEX category and equipment group requirements for your zone against the Schneider Electric ATEX documentation for the LUB32 before installation, and confirm that the complete assembled starter (including the LUC control unit and overload relay) is certified for the hazardous area classification in your facility.

Why Order the LUB32 Through LeadTime.ca

  • LeadTime.ca ships industrial automation components worldwide — no regional restrictions on sourcing or delivery.
  • Pre-sales technical support available to confirm correct SKU selection, verify variant compatibility (LUB32 vs. LUR32, power base vs. complete starter), and flag missing components before the order ships.
  • Accurate lead-time commitments for both standard and ATEX-certified configurations — not estimated website figures.
  • Volume pricing available for OEM builds, panel shop orders, and MRO procurement programs — contact for project-quantity quotes.
  • Hard-to-source industrial components and compatible accessories (LUC control units, overload relays) sourced from verified supply channels.

At-a-Glance Summary

  • Schneider LUB32: non-reversing power base, TeSys Ultra platform, 32A rated current, 230V–690V AC supply range.
  • Three normally open power contacts for motor connection; 1NO + 1NC auxiliary contacts for interlock and feedback wiring.
  • Breaking capacity: 50kA at 400V — suitable for industrial environments with elevated fault levels.
  • Mechanical life: 15,000,000 cycles; electrical life at rated current: 3,000,000 cycles.
  • Screw-clamp terminals (M6 and M8 lugs); dimensions 145 x 45 x 126 mm; weight approximately 0.9 kg.
  • Certifications: UL, CSA, ATEX, BV, DNV, GL, GOST, CCC — globally compliant for hazardous-area, marine, and North American installations.
  • Not a complete starter: LUC control unit must be ordered separately. External overload relay is mandatory per IEC 60947-6-2.
  • Non-reversing only: forward/reverse applications require LUR32 variant. Motors above 32A require LUB63 or LUB115.
  • IP20 general rating; IP40 at front panel connection zone.
  • Pricing available on the product page; contact LeadTime.ca for volume and project-quantity pricing.
