Schneider Electric VW3A1112 — Altivar Door Mount Kit Review

By Abdullah Zahid
13 min read
Schneider Electric VW3A1112 door mounting kit for Altivar graphic terminal, IP65 rated, installed on industrial enclosure door

Schneider Electric VW3A1112 Door Mounting Kit for Altivar Graphic Keypad — Specs, Compatibility, and Installation Overview

If you are specifying a remote operator interface for an Altivar VFD installation inside a sealed industrial enclosure, the Schneider Electric VW3A1112 is the factory-validated answer — a complete door mounting kit that places a graphic terminal on the enclosure door while maintaining IP65 and UL Type 12 protection. The kit connects via RJ45 and supports cable runs up to 10 meters, covering the five current Altivar platforms: ATV340, ATV320, ATV900, ATV600, and Easy 610. If your VFD is on that list and you need a sealed door-mounted display interface, this is the correct part.

If you have already confirmed compatibility, check current pricing and availability for the VW3A1112 at LeadTime.ca — ships worldwide.

Who Should Buy the VW3A1112 — and Who Shouldn't

The VW3A1112 is right for controls engineers and integrators who need a sealed, compliant, off-the-shelf door mounting solution for a graphic display terminal on an Altivar-family VFD installation. Buy this kit if all of the following apply:

  • Your VFD is one of these five Altivar models: ATV340, ATV320, ATV900, ATV600, or Altivar Easy 610
  • You require IP65 and UL Type 12 rated enclosure protection maintained at the terminal mounting point
  • You are mounting the graphic terminal on the enclosure door, not a wall or pedestal
  • Your cable run from the VFD communication port to the door terminal does not exceed 10 meters (or you are prepared to order the VW3A1104Rxx remote cordset separately)
  • You are ordering the graphic display terminal separately — this kit is mounting and wiring hardware only

If your drive is a non-Altivar Schneider platform, if you need wall or pedestal mounting, or if you do not need a graphic display at all, this kit is not the right choice. Contact the LeadTime.ca team to identify the correct accessory for your specific configuration.

On this page:

What the VW3A1112 Does in a Real Installation

The VW3A1112 is not a display or a controller — it is the mechanical and electrical bridge that lets a graphic terminal live on the outside of a sealed enclosure door while the Altivar VFD stays protected inside. Without this kit, adding a remote keypad to a sealed cabinet typically means custom cutouts, ad-hoc sealing, and the real risk of voiding your IP rating. The VW3A1112 eliminates all of that. The assembly includes a steel and plastic mounting plate, tightening tool, fixing hardware, anti-rotation pin and nut, RJ45 connectors for both the terminal and the remote cordset, a cover plate that maintains the IP65 seal when no terminal is connected, and a grounding connector for earth continuity — everything in one factory-assembled kit.

The graphic display terminal itself is ordered separately. The VW3A1112 provides the rated enclosure interface for it. Power to the terminal is delivered through the VFD via the RJ45 connection, so no separate power wiring to the door mount is required. The result is a clean, compliant operator interface that gives maintenance technicians and operators real-time VFD data without opening the enclosure.

Where the VW3A1112 Sits in Your Control System

The VW3A1112 sits at the human-machine interface layer of an Altivar VFD installation — it is the physical point where the drive's graphic communication port reaches the enclosure surface. Here is the typical component chain:

  • Altivar VFD (ATV340, ATV320, ATV900, ATV600, or Easy 610) mounted inside a sealed industrial enclosure
  • RJ45 cordset routed from the VFD's graphic terminal communication port to the door mounting assembly — up to 10 meters using the VW3A1104Rxx remote cordset
  • VW3A1112 mounting assembly sealed into the enclosure door, maintaining IP65 at the door penetration
  • Altivar-compatible graphic display terminal (ordered separately) secured to the mounting plate on the door exterior
  • Operator interacts with the terminal for speed monitoring, parameter adjustment, commissioning, and fault diagnostics without enclosure access

Typical Applications and Deployment Scenarios

In food and beverage processing and pharmaceutical manufacturing, IP65 enclosure integrity is non-negotiable. The VW3A1112 is the standard solution for adding operator display access to Altivar-driven conveyors, pumps, and mixers without compromising the hygienic protection of the control cabinet.

In automotive assembly and packaging lines, the kit is commonly used for commissioning and troubleshooting access — placing the graphic terminal at machine entrance height so technicians can run diagnostics and adjust parameters without reaching inside the panel or using a laptop.

For retrofit installations on existing hardwired Altivar control cabinets, the VW3A1112 provides a clean upgrade path. Rather than rewiring the cabinet or adding a separate HMI panel, integrators mount the kit on the existing door and connect via the VFD's RJ45 port, keeping the project scope contained.

In water and wastewater treatment and chemical production, where sealed enclosures are required in wash-down or corrosive environments, the UL Type 12 compliance of this kit satisfies North American installation standards without additional engineering review.

Application Typical Deployment
Food and beverage processing IP65 door-mounted terminal on VFD enclosure for conveyor or pump speed monitoring in wash-down areas
Pharmaceutical manufacturing Sealed operator interface on Altivar ATV900 or ATV600 drives in cleanroom-adjacent utility panels
Automotive assembly Commissioning and diagnostics terminal on ATV340 or ATV320 driven axis panels at machine front
Water and wastewater treatment UL Type 12 compliant door terminal on pump drive cabinets in outdoor or wet utility buildings
Retrofit control cabinet upgrade Graphic terminal added to existing hardwired Altivar panel without enclosure redesign or rewiring
Multi-VFD facility standardization Single mounting kit model deployed across ATV320, ATV340, and ATV900 installations for consistent BOM

Key Specifications and Compliance Data

Attribute Specification
Degree of Protection IP65
UL Type Rating Type 12
Overall Height 6.8 inches (17.3 cm)
Overall Width 9.1 inches (23.1 cm)
Overall Depth 12.8 inches (32.5 cm)
Gross Weight 1.28 lbs (127 grams)
Terminal Interface RJ45 connector (proprietary Altivar system)
Maximum Cable Run Up to 10 meters (with VW3A1104Rxx cordset)
Material Steel and plastic
RoHS Compliance Yes (verify with distributor)

Full technical specifications are available on the product page at LeadTime.ca.

Altivar Compatibility — Which VFDs This Kit Actually Supports

Compatibility is the single most important variable when ordering the VW3A1112. The kit is designed exclusively for the Altivar VFD family. It is not interchangeable with other Schneider Electric drive platforms, and it does not support third-party variable speed drives of any kind.

VFD Model Product Family Compatible with VW3A1112
Altivar Machine ATV340 Altivar Machine Yes
Altivar Machine ATV320 Altivar Machine Yes
Altivar Process ATV900 Altivar Process Yes
Altivar Process ATV600 Altivar Process Yes
Altivar Easy 610 Altivar Easy Yes
Other Schneider Electric VFD families Non-Altivar No
Non-Schneider variable speed drives — No

If your Altivar VFD model is confirmed on the compatible list above, the VW3A1112 is a direct fit — check current stock and availability at LeadTime.ca.

Expert Verdict: Is the VW3A1112 the Right Kit for Your Project?

For controls engineers and system integrators who are already committed to the Altivar platform, the VW3A1112 is the most practical choice for remote graphic terminal mounting available. It solves a specific, real-world problem — getting a sealed operator interface onto an enclosure door without custom fabrication, without IP rating compromises, and without engineering a one-off solution for each project. The dual IP65 and UL Type 12 rating is factory-validated across five Altivar VFD families, meaning procurement teams can standardize on a single accessory SKU across ATV340, ATV320, ATV900, ATV600, and Easy 610 installations. That kind of BOM simplification has real value over multiple projects and multiple sites. The complete kit — mounting plate, cover plate, RJ45 connectors, seal strips, grounding connector, anti-rotation pin, and tightening tool — ships as one assembly, eliminating the sourcing and assembly time of a custom-built alternative.

The limits of this kit are well-defined and worth stating plainly. It is a door-mount solution only — if your operator interface design calls for wall mounting or pedestal mounting, you need a different kit. It does not include the graphic display terminal itself; that is a separate line item. And it has zero value outside the Altivar VFD ecosystem. If your facility runs a mix of Altivar and non-Altivar Schneider drives, do not assume this kit transfers across platforms. For installations where no graphic display is operationally required, or where hardwired fixed-display operation is sufficient, this kit is an unnecessary cost.

From a procurement standpoint, the VW3A1112 is normally stocked at major authorized distributors, with typical lead times in the range of 1 to 5 business days when inventory is available — though regional stock levels vary and should be confirmed before committing to a project schedule. Ordering through a specialist industrial distributor rather than a general-purpose channel matters here because compatibility verification and cordset cross-referencing (particularly the VW3A1104Rxx remote cordset for longer cable runs) benefit from technical support that generalist channels cannot reliably provide. View the VW3A1112 product page at LeadTime.ca to confirm current availability and pricing before finalizing your order.

For volume pricing or to verify lead time before committing to a build schedule, contact the LeadTime.ca team directly — we ship worldwide.

What Engineers Need to Know Before Ordering the VW3A1112

Community discussion specific to the VW3A1112 is sparse online, which is common for specialized VFD accessories that work correctly when selected properly and generate no field discussion when they do. In the absence of a large body of forum commentary, the most useful guidance comes from the documented ordering and installation mistakes that distributors and technical teams see repeatedly with this class of accessory — and from the compatibility verification steps that experienced integrators treat as non-negotiable before any accessory procurement cycle.

The most consistent ordering error is VFD family mismatch. Controls engineers specifying the VW3A1112 without confirming the exact Altivar model number — assuming any Schneider VFD will work — end up with an incompatible mounting interface and a return cycle that delays the project. The kit's compatibility is exclusive to ATV340, ATV320, ATV900, ATV600, and Easy 610. Any other Schneider drive platform requires a different accessory. A second recurring mistake is failing to account for cable run length before installation. The VW3A1112 supports up to 10 meters via the RJ45 connection, but the remote cordset (VW3A1104Rxx) must be ordered separately. Integrators who do not measure the distance from the VFD communication port to the door mounting location before ordering discover the gap only at installation, stalling the job.

A third mistake that causes field problems is mishandling the IP65 gasket and cover plate. These are functional components, not packaging. Discarding the seal strips or failing to seat the gasket properly around the mounting plate perimeter directly compromises the IP65 rating — resulting in moisture and dust ingress that can cause enclosure damage and electrical failure over time. If no terminal is being connected immediately, the cover plate must be installed to maintain the rated seal. When specialist distributor support is available at the point of purchase — as it is through LeadTime.ca — these are the compatibility and installation questions that get answered before the order ships, not after the parts arrive on site.

Installation Overview — Mounting and Connection

The following is an orientation to the installation process. Engineers requiring full step-by-step procedures should reference Schneider Electric's official product documentation for the VW3A1112.

  • Before mounting, confirm the enclosure door is flat, can accommodate the 9.1 inch width and 6.8 inch height of the kit, and has sufficient internal cavity depth for the mounting plate assembly at approximately 1.28 lbs
  • Prepare the door cutout per the kit layout, then secure the mounting plate using the included fixing nuts and anti-rotation pin; verify the assembly is level before final tightening
  • Route the RJ45 cordset from the Altivar VFD's graphic terminal communication port to the door assembly — for runs approaching or exceeding standard length, the VW3A1104Rxx cordset (up to 10 meters) must be in place before the terminal is connected
  • Seat the seal strips around the mounting plate perimeter and verify gasket integrity; if no terminal is being mounted at this stage, install the cover plate to maintain the IP65 rating
  • With the VFD powered down, connect the grounding connector from the mounting plate to the enclosure frame ground, then connect the graphic terminal via RJ45, power up the VFD, and verify terminal communication is established before full system startup

Compatible Accessories and What to Order Alongside

The VW3A1112 is a mounting kit only. Depending on your installation, the following accessories should be evaluated at the same time as your kit order to avoid a second procurement cycle mid-project.

  • VW3A1104Rxx Remote Mounting Cordset — extends the RJ45 cable run from the VFD to the door terminal, supporting distances up to 10 meters; must be ordered separately and is required for any installation where the VFD is not immediately adjacent to the door mounting location
  • Altivar-Compatible Graphic Display Terminal — the keypad interface that mounts into the VW3A1112 assembly; model selection depends on your Altivar VFD variant and required display functionality; ordered separately from the mounting kit
  • Cover Plate (included in kit) — maintains IP65 seal at the door mounting point when no terminal is connected; verify this component is present in your kit shipment before installation begins

Wrong-Part Prevention Checklist

Before placing your order for the VW3A1112, work through each of the following verification points. A single mismatch at any step means this is not the correct part for your application.

  1. Verify your VFD is part of the Altivar family (ATV340, ATV320, Easy 610, ATV900, ATV600) — if it is a different Schneider VFD line, this kit will not fit.
  2. Confirm you need a door-mounted graphic terminal, not a built-in display or separate stand-alone terminal.
  3. Check that your enclosure door can support the mounting assembly weight (typically 1.28 lbs) and internal cavity depth.
  4. Verify you have or can obtain a compatible graphic display terminal (kit is mounting only; terminal ordered separately).
  5. Confirm IP65 rating is required for your application; if lower rating acceptable, verify mounting method alternatives.
  6. Check if a remote cordset (VW3A1104Rxx) is needed for your cable run length (up to 10 meters supported per kit documentation).

If any of these points raises a question about your specific installation, contact the LeadTime.ca team before ordering — we can cross-reference your VFD model and confirm the correct accessory package.

Frequently Asked Questions

Does the VW3A1112 include the graphic display terminal, or is that a separate purchase?

The VW3A1112 is a mounting and wiring kit only — it does not include the graphic display terminal. The keypad interface must be ordered separately. The kit provides the mounting plate, RJ45 connectors, seals, cover plate, grounding connector, and all mechanical hardware required to install and seal the terminal on the enclosure door.

Will the VW3A1112 work with my ATV630 or ATV312 drive?

No. The VW3A1112 is compatible exclusively with the ATV340, ATV320, ATV900, ATV600, and Altivar Easy 610. If your drive is an ATV630, ATV312, or any other Schneider Electric VFD outside these five models, this kit will not provide the correct mounting interface. Verify your exact VFD model number before ordering.

What happens if my cable run from the VFD to the door is longer than standard — do I need an additional part?

Yes. The VW3A1112 supports cable runs up to 10 meters when used with the VW3A1104Rxx remote mounting cordset, which must be ordered separately. Measure the distance from your Altivar VFD's graphic terminal communication port to the door mounting location before finalizing your order, and add the appropriate cordset length if your run is marginal or exceeds the standard reach.

How is the IP65 rating maintained when the graphic terminal is mounted through the enclosure door?

The VW3A1112 kit includes seal strips that are installed around the mounting plate perimeter at the door interface, and a cover plate that maintains the IP65 seal when no terminal is connected. Proper installation of these components is what preserves the IP65 and UL Type 12 ratings. If the gasket is damaged, improperly seated, or discarded during installation, the rated protection is lost. Always verify seal integrity before system startup.

Is the VW3A1112 stocked, or does it require a lead time commitment?

The VW3A1112 is normally stocked at major authorized industrial distributors, with typical availability in the 1 to 5 business day range when inventory is confirmed. Regional stock levels vary. For time-sensitive projects, confirm current availability with your distributor before committing to an installation schedule — check live availability at LeadTime.ca.

Can I use the VW3A1112 for wall mounting or pedestal mounting instead of door mounting?

No. The VW3A1112 is specifically designed for flat enclosure door mounting. If your installation requires the graphic terminal on a wall surface, a swing arm, or a pedestal, a different mounting kit is required. Consult your distributor or Schneider Electric technical support to identify the correct accessory for your mounting configuration.

Why Order from LeadTime.ca

  • Global shipping — LeadTime.ca ships the VW3A1112 and compatible accessories worldwide, not limited to any single country or region
  • Specialist sourcing — we stock Altivar accessories including mounting kits and cordsets, reducing the risk of split orders and missed compatibility checks
  • Technical cross-reference support — before your order ships, we can verify VFD model compatibility and confirm whether the VW3A1104Rxx cordset is required for your cable run
  • Volume and project pricing available — contact us for multi-unit or multi-site procurement requirements
  • Fast response — reach our team directly for lead time confirmation before committing to a build schedule

At-a-Glance Summary

  • Model: Schneider Electric VW3A1112 — door mounting kit for Altivar graphic terminal, IP65 rated
  • Protection ratings: IP65 degree of protection and UL Type 12 — both maintained at door interface when correctly installed
  • Dimensions: 9.1 inches wide × 6.8 inches tall × 12.8 inches deep; weight 1.28 lbs (127 grams)
  • Compatible VFDs: ATV340, ATV320, ATV900, ATV600, Altivar Easy 610 — no other Schneider or third-party drives supported
  • Maximum cable run: Up to 10 meters using VW3A1104Rxx remote cordset (ordered separately)
  • Terminal interface: RJ45 connector — power to terminal delivered through VFD via RJ45, no separate terminal power wiring required
  • Kit includes: Mounting plate, cover plate, tightening tool, fixing hardware, anti-rotation pin and nut, RJ45 connectors, seal strips, grounding connector
  • Graphic display terminal: Not included — ordered separately
  • Stock status: Normally stocked at major authorized distributors; typical lead time 1 to 5 business days subject to regional inventory
  • Pricing: Available on the product page at LeadTime.ca — contact for volume or project pricing
