Schneider Electric BMXFCW303 preformed cordset with 40-pin FCN locking connector and color-coded flying leads for Modicon M340 I/O module

Schneider Electric BMXFCW303 Preformed Cordset: Complete Specifications, Compatibility and Ordering Guide for Modicon M340 and X80 Systems

If you are specifying a 40-pin I/O cordset for a Modicon M340 or Modicon X80 build and have landed on the Schneider Electric BMXFCW303, you are likely at the part-number verification stage — confirming cable length, connector type, and platform compatibility before issuing the purchase order. The BMXFCW303 is a 3-meter preformed cordset with a factory-terminated 40-pin FCN female locking connector on one end and two bundles of 20 color-coded flying leads on the other, designed specifically to connect high-density discrete I/O modules to field devices without manual individual wire termination.

If you have already confirmed this is the correct part for your system, check current pricing and availability for the BMXFCW303 at LeadTime.ca — ships worldwide.

Who Should Buy the BMXFCW303 — and Who Should Not

The BMXFCW303 is the right cordset for controls engineers and systems integrators who need a factory-terminated, plug-and-play interface between a Modicon M340 or X80 discrete I/O module and field wiring where the cable run is exactly 3 meters.

  • Your I/O module datasheet specifies a 40-pin FCN connector — not DB25, DB37, or any other type
  • Your controller platform is confirmed as Modicon M340 or Modicon X80 — not M241, M251, or any legacy Quantum or TSX generation
  • The physical distance from your cabinet I/O slot to your field termination point is accommodated by a 3-meter cable
  • Your field installation accepts individual color-coded flying leads terminated to terminal blocks, ring lugs, or crimp connectors
  • You require the locking spring latch mechanism to prevent accidental connector pull-out in service
  • You are connecting to high-density digital input or output modules with 40-pin connector configurations

If your required cable length is not 3 meters, your platform is M241 or M251, or you need flying leads pre-terminated to specific crimp connectors before delivery, the BMXFCW303 is not the correct selection — consult the Schneider Modicon M340 cordset product family for the appropriate alternative SKU, or contact LeadTime.ca to identify the correct variant.

On this page:

What the BMXFCW303 Actually Does in a Running System

The Schneider Electric BMXFCW303 is a preformed cordset assembly — catalog category: I/O Module Cordset — that bridges the physical gap between a Modicon M340 or Modicon X80 high-density discrete I/O module and the field wiring that connects to sensors, solenoids, and other field devices. The product official name is Cordset, Modicon M340, 40-way terminal, two end flying leads, 3m, and that descriptor tells you exactly what you are buying: a fixed-length, factory-assembled cable that eliminates the need to manually terminate 40 individual wires to a raw connector in the field.

One end of the BMXFCW303 presents a 40-pin FCN female connector with a spring latch locking mechanism. This connector seats directly into the compatible slot on the I/O module and locks with an audible click, preventing field disconnection. The opposite end divides into two bundles of 20 color-coded flying leads — individual stripped wires that the installer terminates at the field device side using standard industrial termination methods such as terminal blocks or crimp connectors. The color coding is factory-applied and aligns with standard wiring conventions, reducing the chance of miswiring during commissioning and speeding up any future troubleshooting or modification work.

The factory-terminated connector end is the key value proposition here. Pre-termination to FCN 40-pin standard means every pin is correctly positioned and secured before the cable ever reaches your panel shop or machine cabinet. Schneider Electric's product documentation explicitly positions this pre-formed configuration as an error-reduction feature compared to hand-terminating individual wires to a raw connector — a distinction that matters when you are building repeatable OEM machine lines or commissioning high-density I/O panels under time pressure.

Where the BMXFCW303 Sits in Your System Architecture

The BMXFCW303 occupies the physical connection layer between the I/O module mounted on the Modicon M340 backplane and the field wiring that runs to devices on the machine or process. It is not a communications cable — it is the signal interface at the module connector slot.

  • Modicon M340 CPU on backplane communicates with discrete I/O modules installed in adjacent backplane slots
  • The discrete I/O module presents a 40-pin FCN connector slot on its faceplate — this is where the BMXFCW303 plugs in
  • The BMXFCW303 3-meter cable routes from the cabinet through cable tray or conduit toward field devices
  • The two bundles of 20 color-coded flying leads fan out at the field end and terminate to field device junction points — terminal blocks, sensor connectors, solenoid valve terminals
  • Field devices (digital inputs: proximity sensors, limit switches, pushbuttons; digital outputs: solenoids, relays, indicator lights) connect at the flying lead termination points

Typical Applications and Deployment Scenarios for the BMXFCW303

In discrete manufacturing environments — packaging machinery, automotive sub-tier assembly, conveyor systems — the BMXFCW303 is used to connect M340 I/O modules to sensor arrays and solenoid valve banks during system commissioning. OEM machine builders standardize on preformed cordsets precisely because they reduce cabinet build time and ensure consistent wiring across multiple identical machines leaving the production line.

In process control applications such as pharmaceutical batch monitoring or chemical plant control, the color-coded flying leads simplify both initial documentation and future troubleshooting. Maintenance teams performing an annual shutdown swap can replace an aged BMXFCW303 without touching PLC configuration or re-identifying 40 individual wires — the color coding carries over from the previous installation as long as the control system wiring diagram is on file.

Systems integrators who support multiple Modicon M340 installations across a customer base typically stock the BMXFCW303 as a spare part for rapid field replacement. A pre-terminated cordset means a technician can restore I/O connectivity without re-terminating 40 wires under field conditions, reducing mean time to repair significantly. This spare-parts stocking pattern is also common among plant electrical managers at water and wastewater treatment facilities where Modicon M340 is deployed for pump station and process control.

For Modicon X80 I/O platform users, Schneider Electric confirms the BMXFCW303 is compatible, which extends the useful specification range of this part beyond M340-only builds. This dual-platform compatibility means integrators working across both M340 and X80 installations can consolidate their cordset stocking to a single SKU where module connector types align.

Application Typical Deployment
Discrete manufacturing — packaging M340 I/O module to solenoid valve bank and sensor array on packaging line
OEM machine builder Pre-wired cordset installed in proprietary machine control cabinet for repeatable builds
Pharmaceutical batch control Remote I/O connectivity for batch monitoring signals in M340-controlled process skid
Water and wastewater treatment Pump station digital I/O connectivity via M340 with rapid-swap spare cordset on site
System expansion and retrofit Adding I/O modules to existing Modicon M340 installation during planned capacity upgrade
Maintenance quick-swap Replacing aged cordset during annual shutdown without re-terminating individual wires

BMXFCW303 Specifications and How It Compares to Alternatives

Specification Value
Product Category Preformed Cordset — I/O Module Signal Cable
Connector Type 40-pin FCN female, spring latch locking
Cable Length 3 meters (fixed)
Signal Pairs / Leads 40 total — two bundles of 20 color-coded flying leads
Termination — Connector End Factory preformed to FCN 40-pin standard
Termination — Field End Individual color-coded flying leads (stripped) for field termination
Locking Mechanism Spring latch — audible engagement confirmation
Compatible Platforms Modicon M340 and Modicon X80 I/O Platform
Module Types Supported High-density discrete digital input and output modules with 40-pin FCN connector
Not Compatible With Modicon M241, M251, Compact, legacy Quantum, TSX platforms

Full technical specifications are available on the product page at LeadTime.ca.

Model Cable Length Connector Type Best Use Case
BMXFCW303 3 meters 40-pin FCN female, locking Standard cabinet-to-field-device runs on M340 / X80 systems
BMXFCW203 Shorter variant (verify with datasheet) 40-pin FCN (verify connector count) Compact cabinet installations with shorter cable runs
Custom / Hand-Terminated Cordset Any length Custom to requirement Non-standard distances or specialty termination needs — 3-4 week lead time, higher cost
FCN 40-pin Connector Only (no leads) Not applicable 40-pin FCN Budget installations where field wiring team terminates all 40 wires manually

If your cable run does not fit the 3-meter fixed length of the BMXFCW303, or if your module uses a different pin count, select the appropriate alternative from the Modicon M340 cordset family — check current availability and confirm the correct SKU at LeadTime.ca.

Expert Verdict: Is the BMXFCW303 the Right Call for Your Project?

The Schneider Electric BMXFCW303 is a straightforward, low-drama component when it is specified correctly — and that qualification matters more than it might appear. For controls engineers commissioning new Modicon M340 or X80 discrete I/O systems where the cabinet-to-field run is 3 meters, this cordset does exactly what it is supposed to do: the factory-terminated 40-pin FCN connector plugs directly into the module, the spring latch locks it in place, and the two color-coded bundles of 20 flying leads give the field technician a clean, pre-identified set of 40 connections to terminate at the field device side. OEM machine builders who need repeatable builds across multiple identical cabinets will find this preformed configuration particularly useful — it removes the human variable from a 40-wire termination task that is otherwise a reliable source of commissioning faults. Systems integrators stocking spares for rapid shutdown-window replacements are the other core buyer for this part, and the stock availability profile from authorized distributors supports that use pattern: the BMXFCW303 ships same-day or next business day from major distributors, which is the right lead time for a spare-parts strategy.

The limits of this part are specific and worth naming honestly. If your system is Modicon M241 or M251, the BMXFCW303 physically cannot connect — connector types and I/O module architectures differ between these generations. Do not assume that the Modicon brand name implies cross-generation compatibility. If your cable run is longer or shorter than 3 meters, the fixed length is a hard constraint — there is no field-adjustable version. And if your application involves EMI-sensitive environments requiring shielded cable, or if your field termination method requires leads pre-crimped to specific connector types before delivery, the standard BMXFCW303 will not meet those requirements and a custom cordset is the correct path, with the associated 3-4 week lead time and cost premium. The comparison points to watch are the BMXFCW203 for shorter-run alternatives and the connector-only FCN 40-pin option for budget installations where the field wiring team handles all 40 terminations manually.

From a procurement standpoint, the single highest-risk moment in buying this part is order entry — specifically, the risk of a one-digit transposition between similar SKU numbers like BMXFCW203 and BMXFCW303. Generic online marketplaces process these orders without application verification, and the wrong cable ships without question because both part numbers are valid and in stock. Specialist distributors who work in industrial automation verify the part against your system documentation before the order leaves the building — that verification step is worth more than the marginal price difference on a single unit when the alternative is a two-week delay during commissioning. View the BMXFCW303 product page at LeadTime.ca to confirm current pricing and stock status before placing your order.

For volume pricing on multi-unit orders or to confirm lead time before committing to a project build schedule, contact the LeadTime.ca team directly — we ship worldwide.

What Engineers Need to Know Before Ordering the BMXFCW303

Because the BMXFCW303 sits in a product family where sequential SKU numbering creates genuine confusion risk, and because the platform compatibility question between Modicon generations is one of the most common sources of costly ordering errors for this type of component, the guidance below synthesizes the most important pre-order checks drawn from documented buyer mistakes and Schneider's own compatibility documentation.

The most frequently reported ordering problem with Modicon M340 cordsets of this type is the wrong-length order — a buyer measures the cabinet layout at the design stage and gets the distance approximately right, but does not account for cable routing slack through trays or conduit, and the 3-meter BMXFCW303 comes up short at installation. The fix is straightforward: measure the actual routed path from the I/O module slot to the field termination point, not the straight-line distance, and add routing margin before selecting the cable length SKU. If the resulting number is not 3 meters, the BMXFCW303 is not the correct part regardless of how similar the catalog number looks to the right one.

The second pattern worth flagging is platform assumption. Controls engineers who have worked on Modicon M340 systems for years and are now being asked to support a newer M241 or M251 installation sometimes carry their M340 cordset part numbers into the new system without rechecking. The BMXFCW303 will not physically connect to an M241 or M251 module — the connector architectures are different. Schneider confirms compatibility explicitly for Modicon M340 and Modicon X80 only. Any other Modicon generation requires a different part number, and the correct starting point is your module datasheet, not your previous project's BOM. When the part is this specific and the sourcing window is tight, consulting with a specialist distributor who can cross-reference your module part number against the official compatibility matrix is the fastest way to get a confirmed answer before the PO is issued.

Wiring and Installation Overview for the BMXFCW303

  • Confirm the I/O module is de-energized and the 40-pin FCN connector slot on the module faceplate is clean and undamaged before seating the BMXFCW303 connector — the spring latch should engage with an audible click and the connector should not move when lightly tugged
  • Route the two 20-lead flying lead bundles from the module through cable tray or conduit toward field devices, keeping the cable away from high-voltage power conductors to minimize EMI coupling into signal leads
  • At the field end, terminate individual color-coded flying leads using your site-standard method — terminal blocks, ring lugs, or crimp connectors — and document the termination in the control system wiring diagram, referencing the manufacturer's color-to-pin assignment from the official BMXFCW303 product datasheet
  • Apply strain relief clamps to the flying lead bundles near the termination points and at any routing change of direction to prevent mechanical stress from transferring to the crimp connections over time
  • Before restoring power, perform a continuity check across all 40 signal pairs from the FCN connector end to the field termination points; any open-circuit pair indicates a termination fault or cable damage that must be resolved before energizing the module

For full wiring diagrams, pin assignment tables, and bend radius specifications, refer to the official Schneider Electric BMXFCW303 product datasheet and the Modicon M340 I/O module installation manual available on se.com.

Wrong-Part Prevention Checklist for the BMXFCW303

Before placing your purchase order, work through each item on this checklist. Every item represents a documented source of ordering errors for this type of component:

  1. Confirm I/O module datasheet specifies 40-pin FCN connector (not DB25, DB37, or other types)
  2. Verify module is part of Modicon M340 or Modicon X80 platform (not MODBUS, TSX, or legacy Quantum)
  3. Check actual module part number against Schneider compatibility matrix (common error: confusing M340 modules with M241 or M251)
  4. Confirm required cable length is exactly 3m (BMXFCW303 fixed length; alternative lengths require different SKUs)
  5. Ensure flying lead termination is acceptable for field installation (vs. connector-on-connector daisy chaining)
  6. Verify locking mechanism is compatible with field device receptacles (some legacy systems use push-fit connectors)
  7. Confirm no custom wire gauge or shielding requirements for EMI-sensitive applications
  8. Check that spare inventory on hand won't exceed shelf life (cordsets are time-sensitive for outdoor use due to UV exposure on flying leads)

If any item on this checklist cannot be confirmed against your system documentation, do not guess — contact the LeadTime.ca team with your I/O module part number and application details before placing the order. Verifying now takes minutes; correcting a wrong-part delivery takes weeks.

Frequently Asked Questions

Will the BMXFCW303 physically connect to a Modicon M241 or M251 controller?

No. The BMXFCW303 is confirmed compatible with Modicon M340 and Modicon X80 platforms only. Modicon M241 and M251 use different I/O module connector architectures. If you have recently migrated or are specifying a new M241 or M251 system, you need a different cordset part number — do not assume the M340 cordset carries over.

What happens if my cable run is longer than 3 meters — can I extend the BMXFCW303?

The BMXFCW303 is a fixed 3-meter assembly and is not designed to be extended in the field. Extending signal leads beyond the rated cable length without signal conditioning introduces the risk of signal degradation on discrete I/O connections. If your installation requires a longer run, select an alternative SKU from the Modicon M340 cordset product family or contact Schneider technical support to confirm the correct solution for your specific distance requirement.

Is the BMXFCW303 a direct replacement for a damaged cordset on an existing M340 installation, or does it require reconfiguration?

The BMXFCW303 is a direct physical replacement for any compatible existing cordset on a Modicon M340 or X80 discrete I/O module with a 40-pin FCN connector. No PLC configuration changes are required — the cordset carries field signals to the module and is transparent to the controller logic. Confirm the replacement cable's color code matches the wiring diagram of the original installation before terminating the flying leads at the field end.

The BMXFCW303 and BMXFCW203 look almost identical in catalog listings — what is the actual difference and how do I avoid ordering the wrong one?

The numeric suffix in Schneider Modicon cordset part numbers encodes cable length and connector configuration. BMXFCW303 designates the 3-meter, 40-way variant. BMXFCW203 designates a different variant — verify the exact connector pin count and cable length against your module datasheet before ordering either. The safest practice is to copy the part number directly from your module's compatibility documentation and paste it into the order, rather than typing from memory. Ask your distributor to confirm the part matches your stated application before shipment.

Does the BMXFCW303 carry power to the I/O module, or is it a signal-only cable?

The BMXFCW303 is a signal cordset only. Power to the Modicon M340 or X80 I/O module is supplied separately through the backplane or dedicated power terminals — it does not pass through this cordset. The 40 signal pairs carry discrete I/O signals between the module and field devices exclusively.

Is the BMXFCW303 stocked or is it a long-lead-time special order?

Schneider Electric's own product documentation and authorized distributor inventory data confirm the BMXFCW303 is normally stocked in distribution, with same-day or next-business-day shipping typical from major authorized distributors. For specific current stock status and lead time for your region, check the product page or contact LeadTime.ca directly — availability can shift during supply constraint periods and confirming before issuing a PO is always the right practice.

Why Order the BMXFCW303 From LeadTime.ca

  • Authorized distributor stocking Schneider Electric Modicon components with same-day processing on in-stock orders
  • Application verification during order entry — team confirms your module part number and system platform match the BMXFCW303 specification before the order ships
  • Ships worldwide — not limited to any single region or country
  • Volume pricing available for multi-unit orders — contact for terms on 5 or more units
  • Technical support accessible post-purchase for installation questions and compatibility follow-up

BMXFCW303 At-a-Glance Summary

  • Official product name: Cordset, Modicon M340, 40-way terminal, two end flying leads, 3m
  • Connector: 40-pin FCN female with spring latch locking mechanism
  • Cable length: 3 meters fixed — no field-adjustable length
  • Signal capacity: 40 total leads divided into two bundles of 20 color-coded flying leads
  • Compatible platforms: Modicon M340 and Modicon X80 I/O Platform — confirmed by manufacturer documentation
  • Not compatible with: Modicon M241, M251, Compact, legacy Quantum, or TSX platforms
  • Module type: High-density discrete digital input and output modules with 40-pin FCN connector
  • Key ordering risk: SKU number confusion with similar variants (e.g., BMXFCW203) — always verify against module datasheet before placing PO
  • Stock status: Normally available from authorized distributors; same-day or next-business-day shipping typical
  • Pricing: Available on the BMXFCW303 product page at LeadTime.ca
