Pro-face PFXGP4501TADW GP-4501TW 10.4-Inch Touch Screen Operator Interface: Specifications, Pricing, and Selection Guide

Controls engineers evaluating a mid-tier HMI for a multi-PLC production environment are looking at one central question: does this panel bridge legacy serial infrastructure and modern Ethernet without adding a gateway? The Pro-face PFXGP4501TADW — the GP-4501TW 10.4-Inch Touch Screen Operator Interface from Pro-face's GP4000 W Series — answers that directly. It ships with COM1 RS-232 and COM2 RS-422/485 as independent ports alongside 10/100 Base-T Ethernet, operates on 24 V DC, and draws 17 W or less from your cabinet supply. For retrofit projects and mixed-brand PLC floors, that combination is the specification that closes purchase orders.

If you have already confirmed this is the right part, check current pricing and availability for the PFXGP4501TADW at LeadTime.ca — ships worldwide.

Who Should Buy the PFXGP4501TADW — and Who Shouldn't

This panel is the right choice for production engineers and integrators who need a proven, panel-mount HMI that handles dual serial PLC protocols natively in a compact 10.4-inch footprint. Confirm all of the following before ordering:

  • Your cabinet power distribution runs 24 V DC (acceptable range 19.2–28.8 V DC) — not 12 V, 48 V, or 110 V DC
  • You require resistive analog touch panel technology for gloved operator use or industrial durability, not capacitive multi-touch response
  • Your PLC communication mix includes RS-232 on one port (Mitsubishi FX/Q series, legacy Siemens S5) and RS-422/485 on the other (Allen-Bradley ControlLogix, distributed I/O) — both on a single panel
  • 640 x 480 VGA resolution is sufficient for your operator dashboard data density and text legibility requirements
  • Your network uses 10/100 Base-T Ethernet — Gigabit is not supported; verify your PLC supports legacy Ethernet protocol levels (Modbus TCP, legacy PROFINET)
  • Panel-mount cabinet installation is your deployment model — this is a fixed hardwired unit, not a mobile or wireless operator terminal

If your application requires a larger display, look at the GP4701 (18.5-inch) within the GP4000 family. If you need capacitive multi-touch and higher resolution in the same footprint, the GP4505 (800x600 SVGA) is the direct upgrade. If wireless mobility is the requirement, a different product family is needed entirely.

On this page:

What the PFXGP4501TADW Actually Does on the Production Floor

The PFXGP4501TADW is an operator interface panel — not a PLC, not a controller. Its job is to sit between the people running a production line and the controllers managing it. Operators read real-time data, acknowledge alarms, adjust production parameters, and launch pre-configured recipes from its 10.4-inch TFT color display. That display renders 65,536 colors at 640 x 480 VGA resolution across an effective viewing area of 211.2 x 158.4 mm — visible under typical factory ambient lighting without requiring a shade hood or anti-glare film.

The resistive film analog touch panel, operating at 1024 x 1024 resolution, is the correct technology choice for environments where operators wear gloves, where surfaces collect dust or machine oil, and where a fingernail or stylus press needs to register accurately without false activation. It does not support capacitive multi-touch gestures — that is intentional for industrial deployment, not a limitation. The panel accepts up to 32 GB SD/SDHC cards for historical data logging and firmware storage, and connects to a commissioning PC via USB mini-B for screen uploads and firmware updates. Power draw is 17 W or less, passive cooling with no integrated fan, making thermal management inside a sealed control cabinet straightforward.

For multi-brand PLC environments, the dual serial architecture is the defining specification: COM1 delivers RS-232 asynchronous serial via a D-Sub 9-pin connector for Mitsubishi FX/Q series and legacy Siemens S5 connections; COM2 delivers RS-422/485 asynchronous via a D-Sub 9-pin for Allen-Bradley ControlLogix, distributed remote I/O, and Siemens S7-300/400 gateway connections. Both ports support configurable baud rates from 2,400 to 115,200 bps, with 187.5 kbps MPI also available, and data formats of 7 or 8 bits with selectable parity and stop bits. This architecture eliminates the need for an external protocol gateway in most mixed-brand installations — a real cost and complexity reduction confirmed in the official Pro-face PFXGP4501TADW datasheet.

Where the PFXGP4501TADW Sits in a Typical Control System

The PFXGP4501TADW sits at the operator interface layer — above field devices and I/O, connected to one or more PLCs, and directly facing the production operator or maintenance technician. Here is how a typical deployment chain looks:

  • Plant Ethernet network or isolated automation VLAN feeds the panel via 10/100 Base-T connection to a managed switch, enabling Modbus TCP communication to networked PLCs or SCADA systems
  • Primary PLC (e.g., Mitsubishi FX or Q series) connects via COM1 RS-232 D-Sub 9-pin serial cable — direct, no gateway required
  • Secondary controller or distributed I/O (e.g., Allen-Bradley ControlLogix or remote I/O rack) connects via COM2 RS-422/485 — again, no additional interface hardware
  • SD card slot carries historical production data, alarm logs, and recipe files — technicians pull the card post-shift for trend analysis or upload new recipes without a PC connection
  • USB Type-A port supports barcode scanners, external USB drives, or peripheral input devices; USB mini-B port connects to the commissioning PC running Pro-face Design Tool for screen development and firmware management

Industries and Applications That Specify This Panel

The PFXGP4501TADW is most frequently specified in food and beverage processing, pharmaceutical manufacturing, discrete automotive and aerospace assembly, plastics and composites production, and packaging and labeling systems. In these environments, a 10.4-inch panel-mount touchscreen provides adequate operator visibility without consuming the panel real estate that larger screens demand in space-constrained retrofit enclosures.

Production line status monitoring is the core use case: shift operators read real-time alarm states, acknowledge fault conditions by touch, and adjust production parameters without navigating a hardware keypad. The SD card's 32 GB capacity supports extended historical logging that technicians retrieve post-shift for predictive maintenance trending and quality audit trails — eliminating the need for a PC-based logging station at each machine.

Recipe management applications are another strong fit: operators select pre-configured production recipes stored on the SD card, reducing transcription errors that occur with manual parameter entry. For OEM equipment designers building discrete assembly or packaging machinery, the PFXGP4501TADW offers a mature, broadly supported platform that minimizes integration risk when deploying to end-customer sites running diverse PLC brands.

Secondary applications include heavy equipment service shops using the panel for on-machine diagnostics on CNC and punch press operations, and training environments where new operators interact with production system workflows in simulation mode without triggering actual equipment motion.

Application Typical Deployment
Production line alarm monitoring Panel-mount in control cabinet at production station; operator acknowledges alarms and adjusts parameters by touch
Multi-station recipe management SD card stores pre-configured recipes; operator selects and launches without PC access
Predictive maintenance data logging Historical logs to 32 GB SD card; technicians retrieve and analyze post-shift trend data
Retrofit HMI upgrade in legacy cabinets Replaces analog operator panel in space-constrained enclosure; dual serial preserves existing PLC wiring
Operator training and simulation Simulation mode in Pro-face Design Tool allows workflow interaction without triggering equipment motion
Multi-brand PLC integration (Mitsubishi + Allen-Bradley) COM1 RS-232 to Mitsubishi FX/Q; COM2 RS-485 to Allen-Bradley ControlLogix — single panel, no gateway

Specifications That Drive the Purchase Decision

Specification Value
Display Type 10.4-inch TFT Color LCD with LED backlight
Display Resolution 640 x 480 pixels (VGA)
Display Colors 65,536 (no blink) / 16,384 (with blink)
Effective Display Area 211.2 x 158.4 mm (8.31 x 6.24 in.)
Touch Panel Technology Resistive film analog, 1024 x 1024 resolution; gloved operation capable
Input Voltage 24 V DC rated; acceptable range 19.2–28.8 V DC
Power Consumption 17 W or less; passive cooling, no fan
Operating Temperature 0–50°C (32–122°F)
Serial Ports COM1: RS-232 D-Sub 9-pin; COM2: RS-422/485 D-Sub 9-pin; 2,400–115,200 bps (187.5 kbps MPI)
Ethernet / USB / Storage 10/100 Base-T (IEEE 802.3i/u); USB Type-A 2.0 x1, mini-B 2.0 x1; SD/SDHC up to 32 GB (FAT32)

Full technical specifications are available on the product page at LeadTime.ca.

PFXGP4501TADW vs. GP4505, GP4701, and Siemens Mobile Panels

Understanding where the PFXGP4501TADW sits relative to its alternatives is the clearest way to confirm you are specifying the right part. The comparison below covers the models most frequently evaluated alongside it.

Model Screen Size Resolution Touch Type Communication Best For
Pro-face PFXGP4501TADW 10.4 in. 640x480 VGA Resistive analog Dual serial (RS-232 + RS-422/485) + Ethernet 10/100 Legacy multi-PLC integration, compact cabinets, gloved operation
Pro-face GP4505 10.4 in. 800x600 SVGA Capacitive Dual serial + Ethernet + USB Same footprint, faster touch response, higher-resolution modern UI
Pro-face GP4701 18.5 in. 1366x768 Capacitive Dual Ethernet + USB Large facility monitoring, control room deployment, distance readability
Siemens KTP400 Mobile 4 in. handheld 480x272 Capacitive Wireless + USB Mobile operator station, remote troubleshooting, untethered use
Siemens KTP700 Mobile 7 in. handheld 800x480 Capacitive Wireless + USB Portable modern interface, light industrial mobile operations

If your operator workstation requires 800x600 SVGA resolution and capacitive touch in the same 10.4-inch panel-mount footprint, the GP4505 is the direct upgrade path. If your project demands an 18.5-inch display for control room visibility or distance readability, the GP4701 is the correct selection. The Siemens KTP400 and KTP700 Mobile panels address a completely different deployment model — wireless mobility — and are not direct alternatives to a fixed panel-mount application. Check current availability and compare pricing at LeadTime.ca before finalizing your selection.

Expert Verdict: Is the PFXGP4501TADW the Right Call for Your Project?

The PFXGP4501TADW is the right choice for production engineers and integrators working retrofit or mid-tier new-build projects where dual serial PLC protocol support must coexist on a single panel in a compact 10.4-inch cabinet footprint. The specific buyer this panel serves is a controls engineer integrating Mitsubishi production equipment alongside Allen-Bradley packaging or distributed I/O — a combination that would otherwise require a protocol gateway. The panel's IEC/EN 61131-2 vibration compliance (5–9 Hz single amplitude 3.5 mm; 9–150 Hz at 9.8 m/s² fixed acceleration across X, Y, Z for 10 cycles) confirms it is rated for machine shop and factory floor deployment, not just benign control room environments. The 17 W passive cooling design is a real advantage in sealed enclosures where fan maintenance and air ingress are ongoing concerns. For manufacturers with capital-constrained upgrade budgets who need proven, mature software support through Pro-face Design Tool and broad integrator familiarity, this panel delivers a solid return on investment within the mid-market HMI category.

Be honest about where the PFXGP4501TADW has real limits. The 640 x 480 VGA resolution is adequate for standard operator dashboards, alarm lists, and numeric displays — but if your application requires dense graphical data visualization, small-font text legibility, or a modern UI experience that operators expect from consumer touchscreen devices, specify the GP4505 (800x600 SVGA, capacitive) or the GP4512 instead. Washdown environments in food, beverage, or pharmaceutical production require protective enclosures or a ruggedized alternative; the PFXGP4501TADW carries no IP washdown rating for spray or hose-down conditions. High-vibration machine shop deployments require a proactive recalibration schedule — resistive analog touch panels are susceptible to calibration drift under continuous low-frequency vibration in the 5–9 Hz range, and operators will notice misregistration within weeks if that maintenance plan is not in place from commissioning day one.

From a procurement standpoint, the most important action before issuing a purchase order is verifying that the suffix on the ordered part reads exactly PFXGP4501TADW — not TADH, TADE, or any other regional variant, which carry different electrical specifications and certifications. Specialist automation distributors matter here precisely because this confusion is common: a general-purpose channel cannot verify regional variant compliance or confirm that units carry current factory firmware before shipment. Typical lead times through authorized distributors run 2–4 weeks for standard stock, with Canadian local inventory potentially reducing that window. For volume orders or projects with firm commissioning deadlines, locking in confirmed stock before finalizing your build schedule is the only way to eliminate lead time risk. View current pricing and availability for the PFXGP4501TADW at LeadTime.ca — we ship worldwide.

For volume pricing or to confirm lead time before committing to a build schedule, contact the LeadTime.ca team directly — we ship worldwide.

What Engineers Need to Know Before Ordering the PFXGP4501TADW

Because community discussion on the PFXGP4501TADW specifically — and the GP4000 W Series broadly — is sparse across the major automation forums, the most reliable pre-purchase guidance comes from the technical specification record, distributor experience, and the commissioning patterns that emerge from field deployments. This section surfaces the most consequential pre-order knowledge points that engineers consistently need when specifying this panel.

The single most common ordering error in this product family is suffix confusion. The PFXGP4501TADW suffix designates the worldwide 24 V DC standard variant. Variants ending in TADH or TADE carry different regional electrical specifications and certifications — CE, UL, and CSA compliance status varies by suffix. An engineer ordering from an unfamiliar distributor who does not explicitly confirm the suffix on the physical product label risks receiving a unit that does not power on correctly in a North American 24 V DC cabinet, or one that fails a site inspection for regional certification compliance. The prevention is simple but must be applied explicitly: verify the exact suffix on the purchase order, on the shipping documentation, and on the physical product label before installation.

The second pattern that creates commissioning delays is serial port protocol mismatch. COM1 is RS-232 only — it cannot be reconfigured for RS-485. COM2 is RS-422/485. Engineers who map an Allen-Bradley ControlLogix device to COM1 in Pro-face Design Tool will encounter a silent runtime communication failure: the panel connects in the Design Tool environment but receives no data at runtime, with no error message surfaced to the operator screen. The resolution requires rewiring and reconfiguration. The prevention is to build a protocol compatibility matrix — PLC model, required protocol, correct port assignment — before any screen development begins. This is particularly important on multi-PLC projects where screen logic is developed across several weeks and the port assignment error may not surface until final site commissioning. LeadTime.ca's technical team can assist in verifying protocol-to-port assignment for your specific PLC models before the order is placed.

Wiring, Power, and Installation Overview

  • Connect 24 V DC supply leads with correct polarity confirmed; the acceptable input range is 19.2–28.8 V DC — verify your cabinet power supply output is within this window before energizing the panel
  • Use appropriate wire gauge for a 17 W load draw and install a fused disconnect (slow-blow fuse recommended) in the supply line to the panel
  • Apply EMI shielding best practices to Ethernet and serial cable runs — ground the cable shield at one end to avoid ground loops in environments with significant electrical noise from VFDs or large motor starters
  • Panel-mount installation requires an enclosure cut-out matching the standard 10.4-inch form factor; mounting depth is typically in the 60–80 mm range — confirm with the distributor datasheet for exact rear-clearance requirements before cutting
  • In high-vibration environments (machine shops, press lines), use shock-absorbent rubber isolator mounting brackets to dampen low-frequency vibration transmission to the resistive touch panel and reduce calibration drift over time

Commissioning and Communication Setup Overview

  • Initial power-up: verify 24 V DC cabinet supply with a multimeter before connecting the panel; connect USB mini-B to a commissioning PC running Pro-face Design Tool, power on, and use the Detect Device function to confirm the panel is recognized before uploading any screen project
  • Serial port configuration: in Design Tool under System Settings, assign the correct protocol driver to COM1 (RS-232 for Mitsubishi FX/Q, legacy Siemens S5) and COM2 (RS-422/485 for Allen-Bradley ControlLogix, distributed I/O); set baud rate to match the PLC configuration — mismatch here is the most common commissioning delay
  • Ethernet setup: assign a static IP address or configure DHCP in Design Tool; test connectivity to the PLC using Modbus TCP or the applicable legacy Ethernet protocol; verify that network segmentation rules and any firewall configurations allow HMI-to-PLC traffic on the required ports
  • SD card setup: insert a FAT32-formatted SD card (up to 32 GB SD/SDHC; SDXC cards 64 GB and above are not supported); configure logging parameters including sample rate and file storage limits in Design Tool before deployment
  • Firmware verification: before uploading a screen project, confirm the panel firmware version in Design Tool Properties; if the firmware is not current, perform the firmware update via USB mini-B before commissioning — do not disconnect power or USB during the update process

Wrong-Part Prevention Checklist

Before submitting your purchase order for the PFXGP4501TADW, verify each item on this checklist. These are the documented failure points that result in wrong-part returns, commissioning delays, and unplanned project costs.

  1. Verify the model ends in "TADW" (not TADH, TADE, or other suffix variants—different suffixes indicate different regional power standards and certifications)
  2. Confirm 24 V DC input requirement matches your power distribution system before ordering; do not order if your cabinet uses 12 V, 48 V, or 110 V DC
  3. Check that resistive touch panel (analog 1024 x 1024 resolution) meets your accuracy needs; capacitive alternatives are not compatible as direct drop-in replacements
  4. Verify serial port type matches your PLC: COM1 is RS-232 (standard for Mitsubishi, some Siemens); COM2 is RS-422/485 (standard for Allen-Bradley ControlLogix, distributed I/O)
  5. Ensure Ethernet 10/100 Base-T (not Gigabit) is sufficient for your network speed requirements and that your PLC supports legacy Ethernet protocols (Modbus TCP, EtherCAT, PROFINET at older spec levels)
  6. Confirm 640 x 480 VGA resolution is adequate for your data display density; do not order if your application requires high-resolution graphics or small-font text legibility
  7. Check SD card slot support: panel supports up to 32 GB SD/SDHC cards for historical data logging and firmware updates; verify USB mini-B port compatibility with your upload/backup procedures

If any item on this checklist raises a flag, contact the LeadTime.ca team before ordering — our technical team can verify model suffix compliance, protocol compatibility, and current stock status for your specific project requirements.

Frequently Asked Questions

Can the PFXGP4501TADW handle two different PLC brands on a single panel simultaneously — for example, Mitsubishi on one port and Allen-Bradley on the other?

Yes. COM1 RS-232 supports Mitsubishi FX/Q series and legacy Siemens S5 protocols natively; COM2 RS-422/485 supports Allen-Bradley ControlLogix and distributed I/O. You configure screen logic in Pro-face Design Tool to route data blocks to each port independently. This dual-protocol architecture is the primary reason engineers in mixed-brand environments specify this panel — it eliminates the need for an external gateway device. Verify that your specific PLC firmware versions are supported by the current Pro-face Design Tool driver library before finalizing the purchase.

What happens to touch accuracy after months of use in a high-vibration machine shop — and how do you prevent misregistration from shutting down production?

The resistive analog touch panel is susceptible to calibration drift under continuous low-frequency vibration in the 5–9 Hz range. In practice this means touch input begins to misregister — pressing a button activates adjacent controls — typically within 4–6 weeks in a heavy machine shop environment. The prevention plan has two parts: install the panel on shock-absorbent rubber isolator mounting brackets to dampen vibration transmission, and schedule touch recalibration every three months using the calibration utility in Pro-face Design Tool. Document the baseline calibration coordinates after initial installation and track drift at six-month intervals against the IEC/EN 61131-2 vibration compliance limit of 9.8 m/s² fixed acceleration.

Is the PFXGP4501TADW still in production and supported with current firmware and software tools in 2026?

Yes. Pro-face continues production and software support for the GP4000 W Series. This is a mature platform; the GP4505 and GP4512 offer newer processing capability and higher resolution, but the PFXGP4501TADW remains actively available through authorized distributors with typical lead times of 2–4 weeks for standard stock. Firmware updates are delivered via USB mini-B or SD card through Pro-face Design Tool. Verify current firmware availability with your distributor at time of order.

What is the maximum SD card capacity, and what file system format is required?

The PFXGP4501TADW supports SD and SDHC cards up to 32 GB. The card must be formatted as FAT32. SDXC cards of 64 GB or larger are not supported — do not attempt to use them, as the panel will not recognize the card and logging functions will fail silently. For extended historical logging applications, 32 GB is sufficient for most production audit trail and trend analysis requirements when logging parameters are configured appropriately in Design Tool.

Is the PFXGP4501TADW suitable for food, beverage, or pharmaceutical washdown areas?

No, not without additional protective measures. The PFXGP4501TADW carries no IP washdown rating for spray or hose-down conditions. For food, beverage, or pharmaceutical environments with direct washdown exposure, a ruggedized alternative — such as the GP2000F series with conformal coating — is required, or the panel must be mounted inside an enclosure with an appropriate IP-rated stainless steel bezel. Consult your distributor for the correct ruggedized configuration for your specific environmental rating requirement.

Can multiple PFXGP4501TADW panels share the same Ethernet network and connect to the same PLC simultaneously?

Yes, provided each panel is assigned a unique IP address — either via static configuration or DHCP — in Pro-face Design Tool. Confirm that your managed switch and PLC support multiple concurrent Ethernet connections from HMI clients. In standard factory automation deployments using 10/100 Base-T Ethernet, network bandwidth is not typically a constraint for this type of HMI-to-PLC polling traffic.

Why Order From LeadTime.ca

  • Global shipping — LeadTime.ca ships worldwide; no geographic restriction on sourcing
  • Model suffix verification — specialist distributor support confirms PFXGP4501TADW variant compliance before shipment, reducing wrong-part return risk
  • Hard-to-find and short-lead automation parts — access to GP4000 series stock and ability to source across authorized distributor networks when local inventory is constrained
  • Volume pricing available — contact the team directly for multi-unit project quotes and lead time commitments before finalizing build schedules
  • Technical pre-sales support — protocol compatibility, port assignment verification, and commissioning logistics guidance from automation specialists, not a general-purpose electronics counter

At-a-Glance Summary

  • Display: 10.4-inch TFT Color LCD, 640 x 480 VGA resolution, 211.2 x 158.4 mm effective viewing area, 65,536 colors (no blink)
  • Touch panel: Resistive film analog at 1024 x 1024 resolution — gloved operation capable, no capacitive multi-touch
  • Power input: 24 V DC rated, acceptable range 19.2–28.8 V DC; 17 W or less consumption; passive cooling, no fan
  • Serial ports: COM1 RS-232 (D-Sub 9-pin) for Mitsubishi FX/Q, legacy Siemens S5; COM2 RS-422/485 (D-Sub 9-pin) for Allen-Bradley ControlLogix, distributed I/O; 2,400–115,200 bps (187.5 kbps MPI)
  • Ethernet: 10/100 Base-T IEEE 802.3i/u — Modbus TCP and legacy protocol support; not Gigabit
  • Storage: SD/SDHC up to 32 GB (FAT32); SDXC 64 GB and above not supported
  • USB: Type-A 2.0 x1 for peripherals; mini-B 2.0 x1 for commissioning PC and firmware updates
  • Operating temperature: 0–50°C (32–122°F); storage: −20–60°C (−4–140°F)
  • Vibration compliance: IEC/EN 61131-2 — 5–9 Hz single amplitude 3.5 mm; 9–150 Hz at 9.8 m/s² fixed acceleration, 10 cycles
  • Altitude endurance: up to 2,000 m (6,561 ft) — 800–1,114 hPa operational range
  • Model suffix to order: PFXGP4501TADW — worldwide 24 V DC standard variant; do not substitute TADH or TADE
