Allen-Bradley 700-TBR24 — 24V AC/DC Relay Specs & Buying Guide

By Abdullah Zahid
14 min read
Allen-Bradley 700-TBR24 plug-in SPDT replacement relay insert for 700-HL terminal block interface base 24V AC/DC

Allen-Bradley 700-TBR24 — 700-H General Purpose Accessories, Replacement Relay, SPDT (1 C/O), 24V AC/DC, for 700-HL Terminal Block Interface

When a relay insert fails inside an Allen-Bradley 700-HL slim terminal block interface module, you need the right replacement relay confirmed fast — wrong coil voltage, wrong family, or wrong contact form means the panel stays down. The Allen-Bradley 700-TBR24 is the direct plug-in replacement relay for 700-HL terminal block interface bases, with a 24V AC/DC coil and a single-pole SPDT (1 C/O) contact rated up to 6 A. It restores operation without touching field wiring, and it carries UL, cUL, CE, CCC, and KC certifications to keep your panel compliant.

If you have already confirmed the 700-TBR24 is the right replacement for your 700-HL base, check current pricing and availability at LeadTime.ca — ships worldwide.

Who Should Buy the 700-TBR24 — and Who Shouldn't

The 700-TBR24 is the right choice when all of the following are true for your application:

  • Your existing base is confirmed as an Allen-Bradley 700-HL slim terminal block interface relay — not a 700-H or other 700 series variant.
  • Your control supply is 24V AC or 24V DC; the 700-TBR24 coil is rated 24V AC/DC and will not work on 120V AC, 230V AC, or other voltages.
  • A single-pole SPDT (1 C/O) contact configuration is sufficient for your circuit.
  • Your load current is within the 6 A general-purpose contact rating, accounting for load type and any inrush from inductive devices.
  • Your project requires UL, cUL, or CE listed Allen-Bradley components to meet panel inspection or customer specification standards.

If your control voltage is anything other than 24V AC/DC, look at other 700-TBRxx coil voltage variants in the 700-HL family. If your base is damaged or you are building a new panel from scratch, you need a complete 700-HL interface module, not just the relay insert.

On this page:

What the 700-TBR24 Actually Does in Your Control Panel

The 700-TBR24 is the replaceable electromechanical relay element inside a 700-HL slim terminal block interface module. It is not a standalone relay and it is not a complete interface module — it is the relay insert that plugs into an existing 700-HL base and provides the switching action between your low-voltage control signal and the field load. The 700-HL base holds all the terminal wiring; the 700-TBR24 provides the coil and contact mechanism. This separation is the defining feature of the 700-HL concept: when a relay wears out or fails, you extract the insert and seat a new one without cutting a single wire.

The 24V AC/DC coil is energized by the PLC digital output card or control relay driving the 700-HL module. The SPDT contact — rated up to 6 A for general-purpose loads — then switches the field circuit: a solenoid valve, contactor coil, pilot light, or similar device. The relay provides galvanic isolation between the low-current logic circuit and the field load, protecting PLC output cards from voltage transients and inrush events on the load side. The lifecycle status of the 700-TBR24 is listed as Active by the manufacturer, which means ongoing production support and documented replacement availability.

Typical System Architecture for 700-HL Interface Relay Applications

The 700-TBR24 sits at the isolation boundary between the PLC output card and the field device. Here is where it fits in a typical DIN-rail control panel:

  • PLC digital output module — provides the 24V DC switching signal to energize the 700-HL module coil.
  • 700-HL slim terminal block interface base — mounted on DIN rail, holds all field and control wiring at its terminals; accepts the 700-TBR24 relay insert.
  • 700-TBR24 relay insert — plugs into the 700-HL base, provides the SPDT (1 C/O) contact switching up to 6 A.
  • External fusing or circuit breaker — installed on the load side per panel design; not built into the relay.
  • Field device — solenoid valve, contactor coil, indicator, or small motor starter receiving switched power through the relay contact.

Typical Applications and Deployment Scenarios

In automotive assembly and machining cells, 700-HL modules with 700-TBR24 inserts are commonly used to interface PLC output cards with pneumatic cylinder solenoid valves, where the slim terminal block format keeps panel real estate tight and relay replacement during maintenance windows fast.

Food and beverage packaging lines often have dozens of 700-HL interface relays in a single cabinet, all running on a common 24V DC control bus. The 700-TBR24 supports standardized spare stocking in these environments — one relay insert covers every interface position running 24V control, regardless of whether the supply is AC or DC.

Water and wastewater facilities that have standardized on Allen-Bradley control hardware use the 700-TBR24 as the approved replacement relay in panels where the 700-HL family is the interface relay of record, maintaining OEM part conformity required by their control system standards.

Material handling and logistics equipment — conveyor drives, diverters, and sorter gate controls — uses 700-HL relay bases to isolate scanner and sensor logic from actuator coil wiring, with the 700-TBR24 as the field-replaceable element that maintenance technicians can swap during a conveyor stoppage without an engineer on site.

Application Typical Deployment
PLC output to solenoid valve interface 700-HL base with 700-TBR24 insert driven by 24V DC PLC output card
Contactor coil switching from logic circuit Single 700-TBR24 SPDT contact energizes contactor coil on load side
Preventive relay maintenance shutdown Spare 700-TBR24 inserts swapped into 700-HL bases without disturbing terminal wiring
Panel retrofit — retained 700-HL bases Existing 700-HL bases kept; only 700-TBR24 relay inserts replaced or upgraded
Multi-site MRO spare standardization Single 700-TBR24 part number covers all 24V AC/DC positions across facilities

Key Specifications and the Right 700-TBRxx Variant for Your Voltage

Parameter Value Notes
Brand Allen-Bradley (Rockwell Automation) Confirm labeling on latest datasheet
Catalog Number 700-TBR24 Replacement relay insert for 700-HL terminal block interface bases
Coil Voltage 24V AC/DC Control supply must be 24V AC or 24V DC; verify before ordering
Contact Configuration SPDT (1 C/O), 1-pole changeover Provides one normally open and one normally closed circuit path
Contact Current Rating Up to 6 A (general-purpose) Verify voltage-specific and inductive load derating in datasheet
Mounting Style Plug-in insert for 700-HL slim terminal block interface base No direct panel terminals; all wiring on the 700-HL base
Product Family Bulletin 700-HL slim terminal block interface relays (accessories) Use only in compatible 700-HL bases
Standards and Approvals UL, cUL, CE, CCC, KC Verify specific file numbers if required by project documentation
Lifecycle Status Active Check latest Rockwell bulletin before large orders
Typical Lead Time Often in stock; days to a few weeks depending on quantity and region Confirm current availability with distributor before committing to schedule

Full technical specifications are available on the product page at LeadTime.ca.

700-TBRxx Coil Voltage Variants — Choosing the Right Relay for Your Control Supply

Catalog Number Coil Voltage Contact Configuration Compatible Base Choose When
700-TBR24 24V AC/DC SPDT (1 C/O) 700-HL Control supply is 24V AC or 24V DC
Other 700-TBRxx variants Other voltages (e.g., 120V AC, 12V DC, 48V DC) SPDT (1 C/O) 700-HL Control supply is not 24V; match variant to your panel voltage
Complete 700-HL module Per module selection Per module selection New DIN-rail installation Base is damaged, missing, or new panel build requires base plus relay
Higher-rated 700 series relay Per selection Multi-pole or higher current Appropriate 700-series base Load exceeds 6 A or multiple poles are required

If your control supply is anything other than 24V AC or 24V DC, the 700-TBR24 is the wrong insert — selecting another 700-TBRxx coil voltage variant for your 700-HL base is straightforward. Check current availability at LeadTime.ca or contact the team to confirm the correct variant for your voltage.

Expert Verdict: Should You Standardize on the 700-TBR24?

For maintenance engineers and panel builders already operating Allen-Bradley 700-HL interface modules on 24V control circuits, the 700-TBR24 is the straightforward, low-risk choice. It plugs into the existing base, restores switching function through a UL, cUL, and CE listed component, and leaves every wire on the 700-HL base exactly where it was. That matters when you are under downtime pressure or when the machine is under warranty and OEM conformity is a requirement. The 24V AC/DC coil covers both AC and DC control schemes with a single part number, which simplifies spare parts inventory for facilities running mixed control power supplies across multiple panels.

The 700-TBR24 is not the right answer in every situation, and it is worth being direct about that. If your load current exceeds 6 A, or if you need multiple switched poles, you need a different relay family within the Allen-Bradley 700 series. If you are designing a new panel from scratch and you are not locked into the 700-HL ecosystem, you have more flexibility to evaluate interface relay systems on cost and feature terms — other slim interface relay platforms offer comparable isolation functionality and may represent better value in high-density or cost-sensitive new builds. And if your existing base is damaged rather than just the relay insert, ordering only the 700-TBR24 will leave you without a working module; a complete 700-HL module is what you need in that case.

From a procurement standpoint, the 700-TBR24 is listed as an Active product, which supports its inclusion in long-term spare parts planning. Lead times are typically short for standard stocking quantities, but supply chain conditions do shift — confirming availability before committing to a scheduled maintenance window or production build is always worth doing. Working with a specialist automation distributor rather than a general catalog channel gives you a faster cross-reference check, accurate confirmation that the 700-TBR24 fits your specific 700-HL base revision, and realistic lead time data from inside the Rockwell supply chain. View current pricing and stock status for the 700-TBR24 at LeadTime.ca — we ship worldwide.

For volume pricing, scheduled shipments, or to confirm lead time before committing to a maintenance build, contact the LeadTime.ca team directly — we ship worldwide.

What Engineers Need to Know Before Ordering the 700-TBR24

Community discussion specific to the 700-TBR24 is limited, but broader feedback from controls professionals working with Allen-Bradley interface relay families is consistent enough to be useful. On the positive side, engineers who work with 700-HL interface modules regularly cite the relay insert concept as a practical advantage: when a relay fails, the swap takes minutes and does not require touching a single terminal. Long service life under rated conditions is a recurring observation, and the familiarity of staying within an Allen-Bradley ecosystem — where documentation, cross-references, and part identification follow a consistent logic — is noted as a real-world productivity benefit for teams managing large installed bases.

The complaints that surface repeatedly center on two things: cost and confusion within the 700 series catalog. Allen-Bradley interface relay pricing draws comments from engineers managing large spare parts inventories, where the per-unit premium adds up quickly compared with third-party slim interface relay systems. The more operationally significant issue is ordering errors within the 700 family — forum posts on PLCTalk, r/PLC, and similar communities document cases where technicians ordered the wrong coil voltage (24V instead of 120V AC, or vice versa), or confused 700-H and 700-HL parts, because catalog numbers look visually similar and the difference is easy to miss under time pressure. Running relay contacts at or near their 6 A maximum on inductive loads without proper surge suppression is another recurring contributor to premature failure that experienced users warn about explicitly.

The most commonly reported ordering mistake — and the one that causes the most delay — is purchasing the 700-TBR24 relay insert when what was actually needed was a complete 700-HL interface module including the base and terminals, typically because the base itself was damaged or had never been installed. The second most reported mistake is assuming coil voltage from the panel supply without physically reading the marking on the existing relay or its base. These two errors account for the majority of wrong-part scenarios. When direct community data is sparse, that is exactly the scenario where consulting a specialist distributor before placing an order eliminates risk — the LeadTime.ca team can confirm base compatibility, coil voltage, and contact rating suitability from your 700-HL catalog number before the order ships.

Replacement and Wiring Overview for the 700-TBR24 in a 700-HL Base

The following points cover the key requirements and checks for replacing a relay insert in a 700-HL module. For full step-by-step procedures, refer to the Allen-Bradley 700-HL installation instructions and your site's lockout/tagout procedures.

  • All control and field circuits must be de-energized and locked out before removing or installing any relay insert in a 700-HL base. Do not assume the base is de-energized from the PLC side alone.
  • All field and control wiring connects to the 700-HL terminal block base, not to the 700-TBR24 relay insert itself — relay replacement does not require any wiring changes at the terminals.
  • Confirm the replacement relay is fully seated in the base after installation; a partially engaged insert will not make reliable contact and can cause intermittent faults.
  • After restoration of power, measure coil voltage at the base when the PLC output commands the relay on and verify the SPDT contact changes state as expected — confirm correct switching through to the load terminals.
  • External fusing or circuit breakers protecting the load circuit are required per panel design standards; the 700-TBR24 does not include built-in contact protection, and surge suppression across inductive loads is recommended to protect contacts and extend service life.

Wrong-Part Prevention Checklist Before You Order the 700-TBR24

Run through every item on this checklist before submitting your order. These are the checks that prevent the most common and most costly ordering mistakes with this part.

  1. Confirm you need a replacement relay insert, not a complete 700-HL terminal block interface module.
  2. Verify the existing base is a 700-HL slim terminal block interface relay, and that it uses the 700-TBRxx style replacement relay.
  3. Confirm control supply is 24V AC or 24V DC and that 24V AC/DC is acceptable; do not order 700-TBR24 if your control voltage is 120V, 230V, or another value.
  4. Check required contact form: ensure a single-pole SPDT (1 C/O) contact is sufficient for your circuit.
  5. Confirm the 6 A contact rating is adequate for your load type and inrush (especially motors, solenoids, or lamps).
  6. Verify environmental conditions (ambient temperature, enclosure, pollution degree) are within relay ratings.
  7. Check lifecycle status (currently active) and any project-specific approved parts lists that may restrict substitutions.
  8. For Canadian buyers, confirm the part number and description with the distributor to avoid regional substitutions or packing variants.

If any item on this checklist raises a question, contact the LeadTime.ca team before ordering — we can confirm compatibility with your specific 700-HL base and control circuit before the order ships.

Frequently Asked Questions

What is the difference between the 700-TBR24 relay insert and a complete 700-HL interface module?

The 700-TBR24 is only the replaceable electromechanical relay element — the coil and SPDT contact mechanism. A complete 700-HL interface module includes the terminal block base with DIN-rail mounting hardware and all field and control wiring terminals. If your base is intact and only the relay has failed, you need the 700-TBR24 insert. If the base itself is damaged, missing, or you are building a new panel position, you need a complete 700-HL module.

How do I confirm the 700-TBR24 is compatible with my existing 700-HL base?

Read the catalog number and voltage markings directly off the existing relay insert and its base before ordering. The base should be identified as a 700-HL slim terminal block interface relay, and the coil voltage marking on the current insert should read 24V AC or DC. If the base catalog number or existing relay markings are unclear, consult the panel schematic or contact your Allen-Bradley distributor for a cross-reference confirmation.

Can the 700-TBR24 be used on both 24V AC and 24V DC control circuits?

Yes — the coil is rated 24V AC/DC, meaning the same relay insert will operate correctly on either a 24V AC or 24V DC control supply. This is a practical advantage for facilities with mixed control power schemes, as a single spare part number covers both circuit types. Verify the control supply voltage and type before installation to confirm it falls within the rated range.

Is a 6 A SPDT contact sufficient for driving solenoid valves and small contactors?

For many solenoid valves and contactor coils, the 6 A general-purpose contact rating is adequate, but inductive loads draw higher inrush currents at energization. Always verify the steady-state and peak current of your specific load against the rated contact capacity for the applicable voltage and load type, and apply surge suppression across inductive loads to protect contacts and extend service life. If your load pushes close to or beyond 6 A, evaluate a higher-rated relay within the Allen-Bradley 700 series.

Are there lower-cost alternatives to the 700-TBR24, and what are the trade-offs?

Third-party slim interface relay systems from other manufacturers offer comparable SPDT isolation function at lower per-unit cost, but they are not plug-in replacements for 700-HL bases — they require new bases and terminal hardware. For an existing 700-HL installation, substituting a non-Allen-Bradley insert is not a supported configuration and may affect UL/cUL panel listing and warranty conformity. Third-party alternatives are most relevant in new panel designs where no 700-HL bases are already installed and the engineer has freedom to select the interface relay platform.

How many 700-TBR24 inserts should I stock for a panel with many 700-HL modules?

Spare relay quantity depends on the number of installed 700-HL positions, the duty cycle and load type of each relay, and your facility's acceptable maximum downtime. A common approach is to maintain a minimum buffer of 5–10% of installed relay count as on-site spares, with higher reserves for positions driving inductive loads at high cycle rates. For facilities managing multiple panels across sites, a standardized 24V AC/DC spare using the 700-TBR24 simplifies inventory because one part number covers all 700-HL positions on 24V control circuits.

Why Order the 700-TBR24 From LeadTime.ca

  • LeadTime.ca ships Allen-Bradley components worldwide — whether you are in Canada, the US, or sourcing internationally, orders are handled from a single specialist source.
  • Specialist distributors can confirm 700-HL base compatibility and coil voltage suitability before the order ships, reducing the risk of the wrong-part errors that are the most common delay in relay replacement projects.
  • Access to realistic, current lead time data from inside the Rockwell Automation supply chain — not generic catalog estimates.
  • Volume and MRO pricing available for facilities stocking across multiple panels or sites; contact the team for current pricing on larger quantities.
  • Hard-to-find variants and alternative coil voltage 700-TBRxx inserts sourced through established distribution relationships.

At-a-Glance Summary

  • Catalog number: 700-TBR24 — plug-in replacement relay insert for Allen-Bradley 700-HL slim terminal block interface bases.
  • Coil voltage: 24V AC/DC — covers both AC and DC 24V control circuits with a single part number.
  • Contact configuration: SPDT (1 C/O), single-pole changeover, rated up to 6 A for general-purpose loads.
  • All field and control wiring stays on the 700-HL base — relay replacement requires no wiring changes.
  • Certifications: UL, cUL, CE, CCC, KC — supports compliant industrial control panel installations.
  • Lifecycle status: Active — confirmed ongoing manufacturer support and availability.
  • Not a complete interface module — the 700-HL base must already be installed; the 700-TBR24 is the relay insert only.
  • Wrong coil voltage and wrong 700 series family are the two most common ordering errors — verify base catalog number and control supply voltage before ordering.
  • Available for worldwide shipment through LeadTime.ca.
