Overview of Siemens EL6224 EtherCAT Terminal
The Siemens EL6224 is an EtherCAT Terminal designed for communication with IO-Link devices, acting as a 4-channel IO-Link master. It enables bidirectional parameterization and control of up to four actuators or sensors, allowing flexible and precise integration in industrial automation systems. The device supports IO-Link V1.1 with multiple baud rates and offers comprehensive diagnostics and configurability via TwinCAT software.
Key Features
- 4 IO-Link master ports for flexible connection of sensors and actuators.
- Supports IO-Link version 1.1 with baud rates: 4.8 kbaud, 38.4 kbaud, and 230.4 kbaud.
- Power supply via EtherCAT bus (E-bus) and power contacts at 24 V DC.
- Each channel is individually parameterizable via TwinCAT for customized operation.
- Communication over 3-wire connection with support for cable lengths up to 20 meters.
- Electrical isolation of 500 V between E-bus and signal voltage for safety.
- Device markings and LED indicators provide status and diagnostics.
- Robust polycarbonate HD housing with IP20 protection, suitable for DIN rail mounting.
- Wide operating temperature range from -25°C to +60°C, with storage flexibility (-40°C to +85°C).
- Certified for CE, UL, ATEX, IECEx standards ensuring industrial compliance.
Technical Specs
| Specification | Details |
|---|---|
| Model | EL6224 |
| Technology | IO-Link input/output master, EtherCAT terminal |
| IO-Link Version | 1.1 |
| Channels | 4 |
| Field Voltage | 24 V DC via power contacts |
| Connection Type | 3-wire |
| Baud Rates | 4.8 kbaud, 38.4 kbaud, 230.4 kbaud |
| Maximum Cable Length | 20 meters |
| Power Supply | Via EtherCAT bus and power contacts |
| Electrical Isolation | 500 V (E-bus/signal voltage) |
| Current Consumption (E-bus) | Approx. 120 mA |
| Dimensions (W x H x D) | 12 mm x 100 mm x 68 mm |
| Operating Temperature | -25°C to +60°C |
| Protection Rating | IP20 |
Applications / Use Case
Ideal for smart automation solutions requiring integration of IO-Link sensors and actuators into EtherCAT networks. It supports efficient communication, parameterization, and diagnostics in Industry 4.0 environments, enabling real-time monitoring and control within PLC and SCADA systems.
Siemens ensures compact, reliable, and high-performance terminals for industrial automation and advanced machine communication.
-
