6ES75225-HH00-0AB0
Regular price
$434.04
Sale price
$434.04
Regular price
Unit price
per
Couldn't load pickup availability
- Fully secure checkout
- Trusted by thousands
- Rated and reviewed
Have a target price? No worries, submit your target price below
Overview of Siemens 6ES75225HH000AB0
Buy genuine Siemens 6ES75225HH000AB0 online for your automation system. This SIMATIC S7-1500 digital output module is designed to provide reliable and efficient switching of loads in industrial automation environments. Equipped with 16 relay outputs, it supports up to 230 VAC at 2 A per channel, making it suitable for a variety of control tasks. Compact and robust, the module features push-in/screw terminals and an intuitive LED diagnostic system that indicates channel status, errors, and maintenance needs, enhancing operational transparency and minimizing downtime. It integrates seamlessly with Siemens S7-1500 PLCs, ensuring optimal performance and system compatibility in demanding applications.
Key Features of Siemens 6ES75225HH000AB0
- 16 relay outputs enabling flexible switching functions in groups of two
- Supports output voltage of 230 VAC with a maximum current of 2 A per channel
- Rated supply voltage for relay coils is 24 V DC with low typical current consumption of 185 mA
- Robust diagnostics including RUN, ERROR, MAINT, and PWR LEDs for real-time status monitoring
- External protection via miniature circuit breakers B10/B16 for enhanced safety
- Compact dimensions (147 mm height x 35 mm width x 129 mm depth) ideal for panel mounting
- Long cable length support with up to 1000 m for shielded and 600 m unshielded wiring
- Designed specifically for SIMATIC S7-1500 PLC integration with push-in and screw terminal options
Technical Specs of 6ES75225HH000AB0
Explore Siemens 6ES75225HH000AB0 specifications covering voltage, I/O, and communication before installation.
| Specification | Details |
|---|---|
| Number of Outputs | 16 relay outputs |
| Output Voltage | 230 VAC |
| Max Output Current per Channel | 2 A |
| Rated Relay Coil Voltage | 24 V DC |
| Current Consumption (typical) | 185 mA |
| Module Dimensions | 147 x 35 x 129 mm (H x W x D) |
| Terminal Type | Push-in/Screw |
| Cable Length Max (shielded) | 1000 m |
| Cable Length Max (unshielded) | 600 m |
Applications / Use Case
This Siemens 6ES75225HH000AB0 is commonly used in industrial automation, process control, and machine automation worldwide. Its reliable relay outputs enable switching of diverse electrical loads such as motors, solenoids, and actuators in production lines, packaging, and conveyor operations. The module’s diagnostic capabilities support predictive maintenance and fault detection in factory control panels and motion control setups, reducing downtime and enhancing system efficiency. Its robust design and compatibility with the S7-1500 series make it a preferred choice for complex automation tasks requiring reliable digital outputs.
Price & Availability
Get updated on Siemens 6ES75225HH000AB0 price and availability through LeadTime.ca for fast worldwide dispatch.
Why Order from LeadTime.ca
All product on LeadTime.ca is genuine, original OEM, supplied by trusted distributors, and ready for international delivery. Order now for worldwide delivery to secure factory-grade Siemens automation components backed by professional support and fast shipping.
