Overview

The Siemens 6ES7322-1BH01-0AA0 is a digital output module designed for the SIMATIC S7-300 automation system. With 16 isolated digital outputs operating at 24 V DC, it supports high-speed, reliable switching in industrial environments. Each channel delivers 0.5 A, ideal for controlling actuators, relays, or solenoids in process and factory automation.

Key Features

  • 16 digital outputs (DO)
  • 24 V DC operating voltage
  • 0.5 A per output channel
  • Isolated output channels for signal protection
  • Total current: 4 A per group, 8 A per module
  • 1x 20-pole front connector interface
  • DIN rail mounting support

Technical Specifications

Part Number 6ES7322-1BH01-0AA0
Module Type SM 322 Digital Output
Outputs 16 (Digital, Isolated)
Operating Voltage 24 V DC
Output Current 0.5 A per channel
Total Current 4 A per group / 8 A per module
Connector 1x 20-pole
Mounting DIN Rail
Dimensions 125 x 40 x 120 mm
Operating Temp Up to +60°C
Weight 0.244 kg
Country of Origin Germany
Compliance RoHS, WEEE, REACH

Applications

Suitable for use in industrial automation systems with SIMATIC S7-300 PLCs.

Compatible Accessories

  • 6ES7392-1AJ00-0AA0 – Front connector (screw contact, 20-pole)
  • 6ES7392-1BJ00-0AA0 – Front connector (spring contact, 20-pole)
