6ED1055-1CB00-0BA0

Available on Request
$0.00
$0.00
  • Fully secure checkout
  • Trusted by thousands
  • Rated and reviewed

Have a target price? No worries, submit your target price below

Buy genuine Siemens 6ED1055-1CB00-0BA0 online

The Siemens 6ED1055-1CB00-0BA0 is a LOGO! DM8 24 expansion module designed to extend the capabilities of Siemens LOGO! controllers in industrial automation systems. This compact module features 4 digital inputs and 4 digital outputs, all operating at 24 V, providing flexible and reliable expansion options for your automation projects. With integrated short-circuit protection and compliance with multiple industrial standards, the Siemens 6ED1055-1CB00-0BA0 ensures dependable performance in demanding environments. Its IP20 protection rating and compact size make it ideal for space-constrained control panels, delivering seamless integration for enhanced process control and machine automation.

Key Features of Siemens 6ED1055-1CB00-0BA0

  • 4 digital inputs (DI) and 4 digital outputs (DO) at 24 V for versatile control
  • Short-circuit protection on digital outputs for increased safety
  • Compact design: 90 mm height, 36 mm width, and 55 mm depth for easy installation
  • Rated output current of 0.3 A per digital output
  • Switching frequency up to 10 Hz (resistive load) and 0.5 Hz (inductive load)
  • EMC compliant, limit class B, suitable for residential and industrial areas
  • Protection rating IP20 according to EN 60529 standards
  • Approvals including CE, CSA, UL, FM, and marine certifications
  • Designed according to IEC 61131 and VDE 0631 standards

Explore Siemens 6ED1055-1CB00-0BA0 specifications for detailed parameters

Specification Details
Digital Inputs 4 (24 V)
Digital Outputs 4 (24 V), with short-circuit protection
Output Current 0.3 A per output
Switching Frequency 10 Hz (resistive load), 0.5 Hz (inductive load)
Degree of Protection IP20
Dimensions (HxWxD) 90 x 36 x 55 mm
Operating Temperature 0 °C to 55 °C

Applications / Use Case

This Siemens 6ED1055-1CB00-0BA0 is commonly used in industrial automation and machine automation worldwide. It is perfect for expanding the input/output capacity of LOGO! controllers in production line systems, factory control panels, and packaging and conveyor operations. The module’s compact design and robust certifications make it suitable for integration in environments where reliable process control and space optimization are essential. Whether upgrading existing equipment or designing new systems, this expansion module enhances automation flexibility and scalability.
