Buy genuine Siemens 5SY4106-7 online

The Siemens 5SY4106-7 is a high-quality SENTRON miniature circuit breaker designed for reliable protection in industrial and commercial electrical systems. This 1-pole device operates at 230/400 V AC with a current rating of 6 A and boasts a 10 kA interrupt capacity, ensuring robust performance under demanding conditions. With a compact form factor and DIN rail mounting, it integrates seamlessly into control panels and distribution boards. Its C-class trip characteristic is ideal for general use, offering thermal and magnetic tripping functionalities to guard against overloads and short circuits effectively. The Siemens 5SY4106-7 is IP20 rated, providing protection against solid objects, suitable for installation in controlled environments.

Key Features of Siemens 5SY4106-7

  • 1-pole miniature circuit breaker with 6 A rated current
  • C-class thermal-magnetic trip characteristic for precise overload and short-circuit protection
  • Rated operational voltage: 230/400 V AC, compatible with standard industrial voltages
  • High breaking capacity of up to 10 kA (EN 60898) and 35 kA (IEC 60947-2)
  • Compact dimensions: 90 mm height x 18 mm width x 70 mm depth for space-saving installation
  • DIN rail mounting for easy and secure panel installation
  • IP20 protection against solid ingress with connected conductors
  • Wide operating temperature range from -25 to +45 °C enhancing versatility
  • Designed to connect wire sizes ranging from 14 to 4 AWG with screw connection terminals
  • Robust design compliant with industrial standards and Siemens quality

Explore Siemens 5SY4106-7 specifications covering voltage, I/O, and communication

Specification Value
Number of Poles 1 (1P)
Rated Current 6 A
Rated Voltage 230/400 V AC
Breaking Capacity 10 kA (EN 60898), 35 kA (IEC 60947-2)
Trip Class C (Thermal Magnetic)
Enclosure Protection IP20
Mounting DIN Rail
Operating Temperature -25 to +45 °C
Dimensions (HxWxD) 90 x 18 x 70 mm

Applications / Use Case

This Siemens 5SY4106-7 is commonly used in industrial automation, providing essential circuit protection in control panels, machinery, and distribution systems. It is suitable for machine automation, process control systems, and production line applications where reliable electrical protection ensures equipment safety and operational continuity. Its robust thermal-magnetic tripping mechanism is perfect for guarding motors, transformers, and wiring against overloads and short circuits in factory control environments. The compact size and DIN rail compatibility make it a preferred choice for upgrade or new installations in electrical distribution boards.
