Overview of Siemens 3SE5312-0SD11
Buy genuine Siemens 3SE5312-0SD11 online from LeadTime.ca for your automation system. The Siemens 3SE5312-0SD11 is a durable SIRIUS interlock safety position switch designed to ensure reliable machine safety in demanding industrial environments. Featuring a metal housing with a cathodic immersion coating and an IP66/IP67 enclosure rating, this safety switch withstands harsh conditions while providing a locking force of 2600 N. It operates at 24 VDC with a 3 A amperage rating and has a compact design measuring 54 mm x 43.8 mm x 184.1 mm. The switch’s threaded mounting and spring-locked mechanism make it easy to install and maintain. With a temperature range supporting operation from -25°C to 60°C, it is suited for various factory automation contexts where safety and performance are critical.
Key Features of Siemens 3SE5312-0SD11
- Robust metal casing with cathodic immersion coating for corrosion resistance
- High locking force of 2600 N ensuring secure safety interlocking
- Rated for 24 VDC operation with a 3 A load capacity
- IP66/IP67 rated enclosure for dust and water protection in tough industrial settings
- 2 normally closed (NC) safety contacts plus 1 normally open (NO) auxiliary contact
- Spring-locked design for reliable position monitoring and locking
- Threaded mounting for secure and straightforward installation
- Wide operational temperature range from -25°C to 60°C
- Dimensions: 54 mm (L) x 43.8 mm (W) x 184.1 mm (H) for compact integration
Technical Specs of Siemens 3SE5312-0SD11
Explore Siemens 3SE5312-0SD11 specifications for detailed parameters before installation.
| Specification | Details |
|---|---|
| Voltage Rating | 24 VDC |
| Current Rating | 3 A |
| Contact Configuration | 2 NC + 1 NO |
| Locking Force | 2600 N |
| Enclosure Type | IP66/IP67 |
| Material | Metal with cathodic immersion coating |
| Dimensions (LxWxH) | 54 mm x 43.8 mm x 184.1 mm |
| Operating Temperature | -25°C to 60°C |
| Storage Temperature | -40°C to 80°C |
Applications / Use Case
This Siemens 3SE5312-0SD11 is commonly used in industrial automation worldwide. It provides critical safety interlock functions in production line systems, machine automation, and factory control panels. Its robust construction and high locking force make it ideal for protecting personnel and equipment by ensuring that access doors or guards remain securely locked during hazardous machine operation. The switch’s versatility also suits packaging and conveyor operations where safe access and process integrity are priorities.
