Overview of Siemens 3RV20214DA15

Buy genuine Siemens 3RV20214DA15 online today for your automation system. This Siemens SIRIUS 3RV2 Motor Protection Circuit Breaker is a high-quality industrial component designed for reliable motor protection in demanding environments. Rated for 690 VAC and supporting a current range of 18 to 25 A, it enhances system safety by providing thermal magnetic trip protection. With its compact S0 frame and robust design, the 3RV20214DA15 ensures minimized power loss and reduced heat generation within control cabinets, which helps maintain optimum performance and equipment longevity. It integrates smoothly into DIN rail mounting systems, making it a preferred choice for motor controllers and electrical panels.

Key Features of Siemens 3RV20214DA15

  • Rated for 690 V AC and 25 A current, suitable for up to 22 kW motors
  • Thermal magnetic trip mechanism supports both overload and short circuit protection
  • Adjustable trip range from 18 to 25 A for flexible motor protection settings
  • Compact S0 frame with dimensions of 97 x 45 x 97 mm for space-saving installation
  • IP20 enclosure rating ensures finger-safe operation and basic protection
  • 3 poles with a 4 kA interrupt rating, complying with industrial safety standards
  • Screw-type connections with secure mounting on DIN rail systems
  • Auxiliary contact rating of 1NO-1NC for signaling and control integration
  • Optimized bimetal trip units minimizing energy losses and heating

Technical Specs of 3RV20214DA15

Explore Siemens 3RV20214DA15 technical data covering voltage, I/O, and communication before installation.

Specification Details
Voltage Rating 690 V AC
Amperage Range 18 to 25 A
Number of Poles 3
Interrupt Rating 4 kA
Frame Size S0
Trip Type Thermal Magnetic
Dimensions (HxWxD) 97 x 45 x 97 mm
Enclosure Rating IP20
Auxiliary Contact 1NO-1NC

Applications / Use Case

This Siemens 3RV20214DA15 is commonly used in industrial automation worldwide. It is ideal for protecting motors in production line systems, automation machinery, and factory control panels. Its reliable overload and short circuit safeguards make it essential for packaging and conveyor operations, ensuring minimal downtime and secure operation. The circuit breaker’s compatibility with DIN rail mounts and standardized dimensions further enhances its suitability for integration into existing motor control centers and electrical control systems.

Price & Availability

Check Siemens 3RV20214DA15 pricing online through LeadTime.ca for fast worldwide dispatch.

Why Order from LeadTime.ca

All product on LeadTime.ca is authentic OEM, supplied by trusted distributors, and ready for international delivery. Order now for worldwide delivery to ensure you receive genuine Siemens components swiftly with full support and warranty coverage.
