Buy Schneider TSXAEY1614 – Product Overview
The Schneider TSXAEY1614 is a high-density analog input module for the Modicon Premium automation platform, engineered for precision temperature measurement in industrial control systems. This 16-channel thermocouple input module delivers accurate sensor data acquisition with 16-bit conversion resolution and supports multiple thermocouple types (B, E, J, K, N, R, S, T, U) plus voltage inputs. Designed for demanding industrial automation environments, the TSXAEY1614 installs in any Modicon Premium rack slot and features hot-swap capability for minimal downtime. It is a discontinued product as of December 31, 2018, with end-of-service scheduled for December 31, 2026, making it ideal for legacy system support and replacement projects.
Schneider TSXAEY1614 Features & Benefits
- 16 analog input channels with 16-bit analog-to-digital conversion
- Supports thermocouple and voltage input types for flexible sensor integration
- 70 ms nominal read cycle time per channel for responsive control
- 1000 Vrms isolation between channels and bus; 1000 Vrms isolation to ground
- Hot-swap compatible; supports TELEFAST wiring accessories for simplified installation
- Cold junction compensation via dedicated pins (SOCJC/MOCJC)
- Dual SUB-D 25-pin connectors for robust industrial connectivity
- CE marked and RoHS compliant; meets DIN 43710, IEC 1131, and IEC 584 standards
Schneider TSXAEY1614 Specifications & Datasheet
| Parameter | Value |
|---|---|
| Product Type | Analog Input Module, Modicon Premium |
| Input Channels | 16 thermocouple / voltage inputs |
| A/D Resolution | 16 bits |
| Measurement Range | ±63 mV thermocouple; ±80 mV voltage |
| Read Cycle Time | 70 ms per channel |
| Connectors | 2 × SUB-D 25-pin |
| Power Consumption | 300 mA at 5 V DC |
| Operating Temperature | 0 to 60°C |
| Weight | 0.35 kg (0.77 lbs) |
| Protection Class | IP20 |
Schneider TSXAEY1614 Applications in Industrial Automation
This analog input module is commonly used in industrial automation, process control, machine automation, production line systems, and factory control panels worldwide. It excels in applications requiring precise temperature monitoring via thermocouples, including furnace control, HVAC systems, food processing, pharmaceutical manufacturing, and chemical processing industries where multi-channel sensor data acquisition is critical for maintaining product quality and safety compliance.
