Overview of Schneider RM17TG00 Phase Control Relay

The Schneider RM17TG00 is a modular 3-phase control relay designed for monitoring phase sequence and phase loss in three-phase power supplies. It operates within a voltage range of 183 to 528 V AC and provides reliable detection of phase failure or sequence errors to protect industrial equipment and installations. The compact 17.5 mm width design allows flexible DIN rail mounting in control panels.

Key Features of Schneider RM17TG00 Phase Control Relay

  • Monitors phase sequence and detects phase failure (loss of two or more phases).
  • Wide voltage measurement range from 208 to 480 V AC.
  • One changeover (1 C/O) relay contact rated at 5 A for control output.
  • Fast fault detection with response time less than 130 ms.
  • LED indicator for relay ON status for easy local signalling.
  • Compact 17.5 mm wide housing suitable for DIN rail (35 mm) mounting.
  • Conforms to IEC 60255-1 electrical safety and electromagnetic compatibility standards.

Technical Specs

Specification Details
Voltage Range 183…528 V AC
Frequency 50/60 Hz ± 10%
Output Contact Type 1 C/O relay
Relay Current Rating 5 A at 250 V AC/DC
Switching Capacity 1250 VA
Response Time ≤ 130 ms (fault detection)
Power Consumption ≤ 22 VA at 400 V AC 50 Hz
Dimensions 17.5 mm width, DIN rail mount
Operating Temperature -20°C to +50°C
Indicators Yellow LED for relay ON
Standards IEC 60255-1, IEC 60947-5-1

Applications / Use Case

Used in industrial automation and control panels to monitor three-phase power supplies for correct phase sequence and detect phase failure, preventing damage to motors and sensitive equipment.

Schneider Electric’s RM17TG00 relay is known for reliability, compact size, and compliance with international safety standards.
