Overview of Schneider LV429033 Trip Unit TM50D

The Schneider LV429033 is a thermal-magnetic trip unit (TM50D) designed for Compact NSX 100/160 circuit breakers. It features a current rating of 50 amps and 3-pole with 3d (3 duration ranges) characteristics for precise motor and circuit protection. The trip unit ensures reliable overload and short-circuit protection, aligning with industrial standards for electrical distribution.

Key Features of Schneider LV429033

  • Current Rating: 50 A for overload protection in Compact NSX breakers.
  • 3-Pole Configuration: 3 poles with 3d trip setting for versatile protection.
  • Thermal-Magnetic Protection: Offers precise motor overload and short-circuit protection.
  • Compatibility: Designed for use with Compact NSX 100/160 circuit breakers.
  • Standards Compliance: Complies with IEC 60947-2 and UL 508 standards.
  • Configurable Settings: Allows setting of different trip curves for flexible protection schemes.
  • Durability: Engineered for reliable performance in industrial environments.

Technical Specs

Specification Details
Model Number LV429033
Current Rating 50 A
Poles 3 (3d configured)
Trip Type Thermal magnetic
Compatible Breakers Compact NSX 100/160
Voltage Up to 690 V AC
Standards IEC 60947-2, UL 508
Cooling Type Self-cooled
Trip Curve Options 3d

Applications / Use Case

The LV429033 trip unit is used in Compact NSX circuit breakers for precise motor and circuit protection in industrial power distribution. It is suitable for manufacturing, commercial, and utility applications requiring dependable overload safety.

Schneider Electric provides comprehensive support and warranty to ensure product reliability and performance.
