Overview of Schneider Electric 56170 Residual Current Protection Relay

The Schneider Electric 56170, also known as the VigiPacT RH99M, is a residual current protection relay designed for enhanced electrical safety. It monitors earth leakage currents between 30 mA and 30 A, providing quick disconnection to prevent electric shock, equipment damage, and fire hazards. This DIN rail-mounted relay suits both AC and DC supply types, making it flexible for various industrial applications.

Key Features of Schneider 56170 Residual Current Protection Relay

  • Wide Leakage Current Range: Adjustable between 0.03 A to 30 A with 9 selectable thresholds via front-panel dial.
  • Time Delay Setting: Configurable delay from 0 to 4.5 seconds to customize trip response.
  • Voltage Compatibility: Works with 12/24 V AC at 50/60 Hz or 12/48 V DC power supply.
  • High Insulation Rating: Rated for up to 1000 V AC at 50/60 Hz and 400 Hz, suitable for industrial environments with overvoltage category IV.
  • Manual Reset: Requires manual reset after fault clearance for safety compliance.
  • Compact DIN Rail Mount: Easy installation and integration within control panels.
  • Certification: Meets IEC and UL standards for residual current protection.

Technical Specs

Specification Details
Leakage Current Range 0.03 A to 30 A (9 selectable thresholds)
Time Delay Range 0 to 4.5 seconds
Voltage Supply 12/24 V AC 50/60 Hz, 12/48 V DC
Power Consumption 4 VA
Insulation Voltage 1000 V AC at 50/60 Hz and 400 Hz max
Mounting DIN rail
Reset Type Manual reset after fault
Operating Temperature -20 to 60 °C

Applications / Use Case

The Schneider 56170 residual current protection relay is used in industrial and commercial electrical systems to monitor and protect against earth leakage faults, minimizing risks to personnel and equipment. It is widely applied in motor protection and critical power distribution panels.

Schneider Electric provides this relay with rigorous certification and a commitment to safety and reliability in demanding systems.
