Overview of "Omron S8VK-T48024"

The Omron S8VK-T48024 is a high-efficiency 480 W three-phase power supply unit delivering a 24 V DC output at 20 A. Designed for industrial automation, it offers reliable power conversion and supports wide input voltage ranges, making it ideal for demanding factory environments.

Key Features of "Omron - S8VK-T48024"

  • Power Output: Provides 480 watts with a rated output current of 20 A for stable power supply to automation devices.
  • Wide Input Voltage Range: Supports 320 to 576 VAC (three-phase) and 450 to 810 VDC ensuring compatibility with various power sources.
  • High Efficiency: Achieves up to 91% efficiency reducing energy loss and heat dissipation.
  • Built-in Protections: Features overload automatic reset, overvoltage protection with shutdown and restart functionality.
  • Compact Design: DIN rail mountable with dimensions of 95 mm width, 125 mm height, and 140 mm depth for space-saving installation.
  • Environmental Range: Operates in temperatures ranging from -40°C to 70°C ensuring robust use in harsh conditions.
  • Safety and Reliability: Compliance with IP20 protection and IEC safety standards with 135,000 hours MTBF (Mean Time Between Failures).

Technical Specs of "S8VK-T48024"

Specification Details
Model S8VK-T48024
Brand Omron
Power Rated 480 W
Output Voltage 24 V DC
Rated Output Current 20 A
Power Boost Ratio 120%
Input Voltage Range 320-576 VAC (3-phase), 450-810 VDC
Efficiency 91% typical (3-phase, 400 VAC input)
Output Ripple 30 mV peak-to-peak max
Protection Features Overload auto reset, overvoltage shutdown
Mounting DIN rail
Dimensions (W x H x D) 95 mm x 125 mm x 140 mm
Operating Temperature -40 to 70 °C
Weight 1.4 kg

Applications / Use Case

The Omron S8VK-T48024 is suited for powering industrial automation systems including factory machinery, conveyors, and control panels requiring a stable and efficient 24 V DC supply. It is designed to withstand harsh industrial environments, ensuring continuous reliable operation.
