Buy Omron CPM1A-MAD01 – Product Overview

The Omron CPM1A-MAD01 is a compact analog I/O expansion module designed for the CPM1A series micro programmable controller. This 2-input, 1-output analog module delivers high-precision signal conversion for industrial automation applications requiring mixed analog signal processing. Built for reliability and ease of integration, the CPM1A-MAD01 extends the capabilities of your PLC system with minimal footprint and maximum performance.

Omron CPM1A-MAD01 Features & Benefits

This analog I/O module supports flexible input and output configurations: voltage inputs (0–10V, 1–5V) and current inputs (4–20mA), with corresponding voltage output (0–10V, –10–10V) and current output (4–20mA) options. The 1/256 resolution ensures precise analog-to-digital and digital-to-analog conversion with 1.0% full-scale accuracy. Photocoupler isolation between I/O terminals and the PLC protects against signal interference. Fast 10ms conversion time per unit supports responsive automation control. The non-removable 9-pin terminal block simplifies field installation, while the compact 66×50×90mm dimensions fit seamlessly into control panels worldwide.

Omron CPM1A-MAD01 Specifications & Datasheet

Parameter Specification
Model CPM1A-MAD01
Analog Inputs 2 channels
Analog Outputs 1 channel
Input Range 0–10V, 1–5V, 4–20mA
Output Range 0–10V, –10–10V, 4–20mA
Resolution 1/256 (1/512 for –10–10V output)
Accuracy 1.0% of full scale
Conversion Time 10ms max. per unit
Max Output Current 21mA total
Dimensions 66(W) × 50(H) × 90(D) mm
Power Consumption 60mA max. (5VDC or 24VDC)

Omron CPM1A-MAD01 Applications in Industrial Automation

This analog I/O module is widely used in process control, temperature monitoring, pressure sensing, and proportional valve control across manufacturing plants. Industries including automotive, food processing, pharmaceutical production, and HVAC systems rely on the CPM1A-MAD01 for reliable signal conditioning and real-time data acquisition. As a worldwide industrial parts distributor, we supply this module to automation integrators and OEMs across North America, Europe, and Asia.

Omron CPM1A-MAD01 Price & Worldwide Availability

Get updated pricing and availability for the Omron CPM1A-MAD01 with real-time stock status. Fast global shipping available for bulk orders and export-ready deployment. LeadTime.ca offers competitive wholesale pricing to suppliers in Canada and the United States, with worldwide dispatch capabilities.

Why Buy Omron Products from LeadTime.ca

Every product on LeadTime.ca is genuine, authentic OEM and factory-tested, sourced from verified Omron suppliers. We maintain in-stock inventory of the CPM1A-MAD01 and related CPM1A expansion modules for immediate shipment across international industrial markets. Our commitment to quality, fast delivery, and customer support makes us your trusted automation components partner.
