Overview of "Omron CJ1W-MAD42"

The Omron CJ1W-MAD42 is a special analog I/O unit designed for the CJ-series PLCs. It features 4 analog inputs and 2 analog outputs with high resolution, supporting a wide range of input and output signal types for precise control and monitoring in industrial automation applications.

Key Features of "Omron - CJ1W-MAD42"

  • Multiple Analog Inputs: Supports 4 inputs with signal ranges including -10 to 10 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, and 4 to 20 mA.
  • Analog Outputs: Offers 2 outputs with similar flexible voltage and current ranges for accurate process control.
  • High Resolution: 13-bit resolution ensures precise analog signal measurement and output.
  • Conversion Time: 4000 ms per unit for reliable and stable analog signal processing.
  • Connection Type: Screw terminal with a detachable 18-point terminal block for easy wiring and maintenance.
  • Compact Size: 90 mm (H) x 31 mm (W) x 89 mm (D) and weighing 150 g, suitable for space-efficient panel mounting.
  • Compatible with Safety Functions: Suitable for applications requiring safety monitoring and control.

Technical Specs of "CJ1W-MAD42"

Specification Details
Model CJ1W-MAD42
Brand Omron
Number of Analog Inputs 4
Analog Input Signal Range -10 to 10 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 4 to 20 mA
Analog Input Resolution 13 Bit
Number of Analog Outputs 2
Analog Output Signal Range -10 to 10 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 4 to 20 mA
Analog Output Resolution 13 Bit
Conversion Time 4000 ms/unit
I/O Connection Type Screw terminal
Detachable Terminal Block 18-point (M3 screws)
Dimensions (H x W x D) 90 mm x 31 mm x 89 mm
Weight 150 g

Applications / Use Case

The Omron CJ1W-MAD42 is designed for precise analog signal control in industrial automation, ideal for applications requiring flexible input/output ranges and high resolution. It is commonly used in process control, monitoring, and safety-related automation tasks where reliable analog data conversion is crucial.
