FX3U-4AD 24V A/D
FX3U-4AD 24V A/D
Manufacturer: MITSUBISHI
Condition: New and Unused, Surplus.
Overview of Mitsubishi FX3U-4AD-24V-A-D
The Mitsubishi FX3U-4AD-24V-A-D is a 4-channel analog input module designed for the FX3U series programmable logic controllers (PLCs). It supports DC 24V power supply and offers both voltage and current input modes, providing precise analog data acquisition for industrial automation.
Key Features of Mitsubishi - FX3U-4AD-24V-A-D
- Four Analog Inputs: Supports voltage (-10 to +10V) and current (-20 to +20mA, 4 to 20mA) input ranges for versatile sensor connectivity.
- 16-bit Resolution: Provides high precision with 16-bit signed binary digital output.
- Low Power Consumption: Operates on 24V DC power supply with efficient energy usage.
- Signal Accuracy: Total accuracy approx. ±0.3% at 25°C, ensuring reliable measurements.
- Input Resistance: High input resistance to prevent signal distortion (200 kΩ for voltage, 250 Ω for current inputs).
- Easy Integration: Occupies 8 I/O points on the PLC, with compact dimensions for easy installation.
- Wide Operating Temperature: Suitable for industrial environments (0°C to 55°C).
- Compatible with FX3U Series: Fully compatible and expandable within FX3U PLC systems.
Technical Specs of FX3U-4AD-24V-A-D
| Model | FX3U-4AD-24V-A-D |
| Brand | Mitsubishi Electric |
| Power Supply | 24 V DC |
| Analog Inputs | 4 channels |
| Input Voltage Range | -10 to +10 V DC |
| Input Current Range | -20 to +20 mA, 4 to 20 mA |
| Resolution | 16-bit (with sign) |
| Input Resistance | 200 kΩ (Voltage), 250 Ω (Current) |
| Occupied I/O Points | 8 |
| Operating Temperature | 0°C to 55°C |
| Dimensions (W x H x D) | 55 x 90 x 87 mm |
| Weight | 0.2 kg |
Applications / Use Case
The Mitsubishi FX3U-4AD-24V-A-D module is commonly used for precise measurement and control in factory automation, process control, and monitoring systems requiring versatile analog signal inputs. Mitsubishi’s reliable product quality ensures stable and accurate performance.
