Overview of Mitsubishi FR-A740-7.5K-CHT Inverter

The Mitsubishi FR-A740-7.5K-CHT is a high-performance frequency inverter from the FR-A740 series, designed for controlling 3-phase motors with a rated output of 7.5 kW. It operates on a 3-phase 380-480 V AC power supply at 50/60 Hz, optimized for elevator and industrial automation applications.

Key Features of Mitsubishi FR-A740-7.5K-CHT

  • Rated Output Power: 7.5 kW
  • Input Voltage: 3-phase 380-480 V AC
  • Rated Current: 16.0 A
  • Maximum Current: 29.5 A
  • Overload Capacity: 150% for 60 seconds, 200% for 0.5 seconds
  • Cooling Method: Forced air cooling
  • Protection Class: IP20 (enclosed type)
  • Ambient Conditions: Operation temperature -10°C to +50°C, humidity up to 90% RH (non-condensing)
  • Dimensions: 129.5 mm (W) x 260 mm (H) x 195 mm (D)
  • Weight: 3.3 kg
  • Communication: RS-485 communication available for network integration
  • Certification: CE, UL

Technical Specifications of FR-A740-7.5K-CHT

Specification Details
Model FR-A740-7.5K-CHT
Rated Output Power 7.5 kW
Input Voltage 3-phase 380-480 V AC
Rated Current 16.0 A
Maximum Current 29.5 A
Overload 150% for 60s, 200% for 0.5s
Cooling Forced air cooling
Protection IP20
Ambient Temp -10°C to +50°C
Humidity Up to 90% RH (non-condensing)
Size (WxHxD) 129.5 x 260 x 195 mm
Weight 3.3 kg
Communication RS-485 available
Certifications CE, UL

Applications / Use Case

The FR-A740-7.5K-CHT inverter is ideal for elevator drives and other industrial automation applications requiring reliable and precise motor control. Its enhanced overload capacity, compact dimensions, and robust cooling system make it suitable for demanding environments and processes.

Manufactured by Mitsubishi Electric, the FR-A740-7.5K-CHT is a reliable solution for high-efficiency motor control in commercial and industrial settings.
