Overview of Allen-Bradley LC1F330

The Allen-Bradley LC1F330 is a heavy-duty motor contactor designed for industrial applications requiring high current switching capabilities. It has three normally open power poles and is rated for 330 amps at 440 volts AC for AC-3 motor control applications. This contactor is part of the TeSys F range and supports motor control for large loads such as fans, crushers, pumps, compressors, and overhead cranes.

Key Features of Allen-Bradley - LC1F330

  • Rated Current: 330 amps for motor control (AC-3) at 440 V AC.
  • Power Poles: 3 normally open (NO) contacts.
  • Coil Voltage Options: Available with a variety of coil voltages (AC and DC) for flexible control system integration.
  • High Mechanical and Electrical Life: Durable design with up to 10 million mechanical operations and 800,000 electrical operations.
  • Compact Design: Optimized for panel installation with easy wiring using ring terminals and busbar connections.
  • Operating Temperature Range: -5°C to 55°C.
  • Certifications: UL, CSA, CE, ABS, and other international safety approvals.

Technical Specs of LC1F330

Number of Poles 3 Normally Open
Rated Operational Current (AC-3) 330 A at 440 V AC
Rated Operational Current (AC-1) 400 A at 440 V AC (at 40°C)
Rated Insulation Voltage 1000 V
Thermal Current (Ith) 400 A (at 40°C)
Contact Material Silver Alloy
Control Circuit Voltage Varies by coil type (24 V to 1000 V AC/DC)
Mechanical Durability 10 million cycles
Electrical Durability 800,000 cycles
Connection Type Ring terminal and busbar connectors
Protection Rating IP20 front face with shrouds
Dimensions Height: 206 mm, Width: 213 mm, Depth: 219 mm
Weight Approximately 9.5 kg

Applications / Use Case

The LC1F330 contactor is used to control and protect heavy industrial motors and equipment, including pumps, compressors, fans, and cranes in manufacturing plants and processing facilities. Its robust design and high current rating make it suitable for demanding environments requiring reliable motor switching and overload protection.

Backed by broad international certifications and Allen-Bradley's quality standards, it ensures safe and efficient motor control across a variety of industries.
