Overview of Allen Bradley 5069-OB16

The Allen Bradley 5069-OB16 is a high-performance digital output module from the Compact 5000 series. This module provides 16 DC sourcing outputs designed for fast, reliable digital control in industrial automation environments. Engineered for easy integration with CompactLogix controllers, the 5069-OB16 supports 10 to 32V DC operation and offers precise control with sourcing outputs rated for 0.5 A per channel. Its compact design allows efficient use of panel space while maintaining high durability and reliability. The module is suitable for systems requiring robust digital output with clear status indication via LEDs for each channel. Certified for worldwide industrial standards, it ensures compliance with safety and operational guidelines making it ideal for a range of automation projects requiring dependable digital output capabilities.

Key Features of Allen Bradley 5069-OB16

  • 16 Points of DC Sourcing Digital Output for comprehensive device control
  • Operating voltage range from 10 to 32V DC suitable for various applications
  • Maximum output current of 0.5 A per channel ensuring reliable performance
  • Compact 22 mm wide module footprint optimized for panel space savings
  • Individual LED indicators for each channel to display ON/OFF status
  • Seamless integration with Allen Bradley CompactLogix systems
  • Certification for CE, UL, ATEX, IECEx, and other global standards for industrial safety
  • Supports electronic keying to avoid installation errors within modular systems
  • Operating temperature range from 0 to 60°C to suit typical industrial environments
  • Designed for DIN rail or panel mounting for flexible installation

Technical Specs of 5069-OB16

Specification Details
Output Type DC Sourcing Digital Output
Number of Channels 16
Voltage Range 10-32 V DC
Max Current per Channel 0.5 A
Operating Temperature 0 to 60 °C (32 to 140 °F)
Mounting DIN Rail or Panel Mount
Dimensions (HxWxD) 144.57 x 22 x 105.42 mm
Indicators Green/red status LED, yellow/red per channel I/O status LED
Certifications CE, UL, ATEX, IECEx, KC, Marine, RCM, UL Hazardous Location Listed

Applications / Use Case

The Allen Bradley 5069-OB16 module is ideal for applications demanding precise digital output control in industrial automation settings. It is widely used in manufacturing plants, material handling systems, and process control environments where multiple outputs need to be managed simultaneously. The module’s digital sourcing outputs can drive loads such as solenoids, relays, and indicator lights. Its compact design suits space-constrained control panels, and the robust certifications support deployment in hazardous or demanding conditions. Integration with CompactLogix PLC platforms enables streamlined control architecture for machine automation, assembly lines, and factory floor equipment. The module is effective for both retrofit projects and new installations where reliable, scalable output expansion is required.
