Overview of Allen Bradley 2198-DBR40-F
The Allen Bradley 2198-DBR40-F is a dynamic brake resistor module designed for industrial automation environments. Manufactured by Rockwell Automation, this component is engineered to complement Kinetix 5700 400V servo drive systems, delivering reliable performance and enhanced safety in demanding motion control applications. The 2198-DBR40-F is rated for high voltage and robust power handling, making it suitable for applications where controlled deceleration and energy dissipation are critical. With its durable construction and compliance with industry standards, the Allen Bradley 2198-DBR40-F is an essential part of advanced servo drive installations, helping to protect equipment and maintain system integrity.
Key Features of Allen Bradley 2198-DBR40-F
- Designed for compatibility with Kinetix 5700 400V servo drive systems
- High voltage rating up to 528V AC for single- and three-phase applications
- Maximum current rating of 54A at 50°C
- Typical power loss of 15W at rated current
- Low typical leakage current for improved safety
- Compact and robust enclosure suitable for industrial use
- Complies with Rockwell Automation installation and wiring guidelines
- Operates in a broad temperature range from 0 to 50°C
- Supports efficient energy dissipation during dynamic braking
- Certified for use in industrial automation environments
Technical Specs of Allen Bradley 2198-DBR40-F
| Specification | Value |
|---|---|
| Voltage Rating | 528V AC (single/three-phase, 50/60 Hz) |
| Current Rating | 54A @ 50°C |
| Power Loss | 15W @ rated current |
| Leakage Current | Low, typical |
| Operating Temperature | 0 to 50°C (32 to 122°F) |
| Terminal Torque | 1.9 N•m (16.8 lb•in) |
| Recommended Wire Size | 12.0 mm² (0.47 in) |
| Weight (approx.) | 3.3 kg (7.28 lb) |
Applications / Use Case
The Allen Bradley 2198-DBR40-F is primarily used in industrial automation systems that require precise motion control and safe, efficient braking. It is commonly installed in manufacturing environments, packaging machines, robotics, and material handling systems where rapid deceleration of servo motors is necessary. The 2198-DBR40-F helps dissipate excess energy generated during braking, reducing stress on drive components and extending equipment life. Its robust design ensures reliable operation in environments with electrical noise and fluctuating loads, making it a critical component for maintaining system stability and safety in high-performance servo applications.
