Overview of Allen Bradley 2198-BARCON-55DC200
The Allen Bradley 2198-BARCON-55DC200 is a DC bus link kit specifically designed for use with Kinetix 5700 servo drives, including models 2198-D006-ERS and 2198-D012-ERS. This component facilitates the extension of DC-bus power between multiple drives in a multi-axis system, supporting efficient power distribution and system integration. Rated for 200 A current and 55 mm bus-bar width, this accessory is essential for applications requiring reliable, high-current connections in industrial automation environments.
Key Features of Allen Bradley 2198-BARCON-55DC200
- Rated for 200 amperes continuous bus-bar current capacity
- Compatible with Kinetix 5700 dual axis servo drives (2198-D006-ERS, 2198-D012-ERS)
- 55 mm bus-bar width designed for robust power connections
- Facilitates DC bus power extension between drives for multi-axis configurations
- Supports enhanced system power management and efficiency
- Compliant with industrial safety and performance certifications (C-TICK, CCC, CUL, UL)
- Enables simplified wiring and power distribution in complex servo drive setups
- Durable construction suitable for demanding industrial conditions
Technical Specs of 2198-BARCON-55DC200
| Specification | Details |
|---|---|
| Rated Current | 200 A |
| Bus-bar Width | 55 mm |
| Compatible Drives | 2198-D006-ERS, 2198-D012-ERS (Kinetix 5700 series) |
| Certification | C-TICK, CCC, CUL, UL |
| Application | DC bus power extension in multi-axis servo drive systems |
Applications / Use Case
The Allen Bradley 2198-BARCON-55DC200 is commonly used in advanced industrial automation systems where multiple Kinetix 5700 servo drives operate together. It enables the extension of DC bus power between drives, which is critical in multi-axis motor control applications such as robotic arms, CNC machinery, and automated assembly lines. By linking the DC bus across drives, the module allows for efficient energy use and reduces the overall wiring complexity. This contributes to improved system reliability, easier maintenance, and streamlined installation in manufacturing and motion control environments.
