Overview

The Allen-Bradley 2094-BC01-MP5-M is a 460V Integrated Axis Module (IAM) from the Kinetix 6200/6500 servo drive series. Designed for modular motion control systems, it combines a 6 kW converter and 4 A inverter in a single unit. This model is scheduled for end-of-life after December 31, 2025.

Key Features

  • 6 kW converter, 9 A max input
  • 1.8 kW continuous output, 4 A peak inverter
  • Safe Torque-Off (STO) functionality
  • Supports up to eight servo axes per power system
  • Compatible with ControlLogix®, CompactLogix™, and SoftLogix™ platforms
  • Mounts on Bulletin 2094 vertical power rail
  • Complies with CE cable length standards

Technical Specifications

Catalog Number 2094-BC01-MP5-M
Voltage Class 360–480V AC
Converter Power 6 kW / 9 A
Inverter Output 1.8 kW / 4 A (peak)
Safety Safe Torque-Off (STO)
Mounting Bulletin 2094 Power Rail (vertical only)
Weight 5.49 kg

Applications

Ideal for multi-axis motion control in packaging, assembly automation, robotics, and high-speed manufacturing lines.

End-of-Life Notice

This model will be discontinued on December 31, 2025. Please consider engineering replacement options.
