1769-IQ32
1769-IQ32
Manufacturer: ALLEN BRADLEY
Condition: New and Unused, Surplus.
Overview of 1769-IQ32 by Allen-Bradley
The Allen-Bradley 1769-IQ32 is a high-density, 32-point discrete input module designed for CompactLogix and MicroLogix controllers. It features 24V DC sink/source inputs organized into four groups of eight inputs, suitable for various industrial control applications requiring reliable digital input monitoring. This module supports flexible wiring configurations and offers efficient integration in automation systems.
Key Features of Allen-Bradley - 1769-IQ32
- Thirty-two (32) 24V DC discrete input channels grouped in four groups of eight inputs
- Supports both sinking and sourcing wiring configurations for versatility
- Power supply distance rating of 8 modules to maintain proper power distribution
- Compatible with MicroLogix 1500 and CompactLogix controllers
- Operating voltage range of 10 to 30V DC with on-state voltage minimum of 10V DC
- Input response time of 8 ms ensuring timely signal detection
- Operating temperature range from 0°C to 60°C with CE and c-UL certifications
- Compact open-style design with panel or DIN rail mounting options
Technical Specs of 1769-IQ32
| Model | 1769-IQ32 |
| Product Family | Compact I/O |
| Number of Inputs | 32 Discrete Inputs |
| Input Voltage | 10 to 30 V DC |
| Input Type | Sink/Source |
| Input Groups | 4 groups of 8 inputs |
| Input Response Time | 8 ms |
| Power Supply Distance Rating | 8 modules |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -40 to 85 °C |
| Humidity | 5 to 95% non-condensing |
| Weight | Approx. 440 g (0.97 lbs) |
| Dimensions (HxWxD) | 118 x 52.5 x 87 mm (4.65 x 2.07 x 3.43 in.) |
Applications / Use Case
The Allen-Bradley 1769-IQ32 is ideal for gathering discrete digital signals from sensors and switches in manufacturing, process control, and other automated industrial applications. The high channel density and flexible configuration allow efficient system expansion and reliable real-time input monitoring.
