Overview of Allen-Bradley 1756-PC75 ControlLogix Power Supply

The Allen-Bradley 1756-PC75 is a ControlLogix standard power supply designed to provide reliable 48V DC power to ControlLogix systems. It delivers a maximum output power of 75 watts and features multiple voltage outputs to support various modules within the chassis. This power supply ensures consistent operation in demanding industrial environments.

Key Features of Allen-Bradley 1756-PC75

  • Output Power: Maximum 75 W at 0 to 60°C operating temperature.
  • Multiple Voltage Outputs: Provides 5.1V, 3.3V, 1.2V, and 24V DC power outputs for different chassis components.
  • Input Voltage Range: Accepts 85 to 265V AC at 47 to 63 Hz frequency.
  • Hold-Up Time: Approximately 5 cycles at 85V AC and 6 cycles at 120V AC stabilizing power during outages.
  • Overcurrent Protection: User-supplied 15A fuse for circuit protection.
  • Fusing: Non-replaceable fuse soldered in place for internal protection.
  • Isolation Voltage: 250V continuous reinforced insulation between power input and backplane.
  • Compact Size: Dimensions approximately 14.0 x 11.2 x 14.5 cm and a weight of around 0.95 kg.
  • Mounting Compatibility: Designed for ControlLogix chassis models including 1756-A4, A7, A10, A13, and A17.

Technical Specs of 1756-PC75

Input Voltage: 85 to 265V AC, 47 to 63 Hz
Output Power: 75 W max @ 0-60°C
Outputs: 5.1V DC @ 13A, 3.3V DC @ 4A, 1.2V DC @ 1.5A, 24V DC @ 2.8A
Hold-Up Time: 5-6 cycles depending on input voltage
Overcurrent Protection: User-supplied 15A fuse
Dimensions (HxWxD): Approx. 14.0 x 11.2 x 14.5 cm
Weight: Approx. 0.95 kg
Mounting: Compatible with several ControlLogix chassis models
Operating Temperature: 0 to 60°C (32 to 140°F)
Safety: Reinforced insulation and internal fusing for reliability

Applications / Use Case of Allen-Bradley 1756-PC75

The Allen-Bradley 1756-PC75 power supply supports ControlLogix control systems, providing power for controllers and modules in manufacturing, process control, and industrial automation applications. It ensures stable and reliable power delivery even during voltage fluctuations, contributing to system uptime and performance.
