Overview of Allen Bradley 1734-8CFG

The Allen Bradley 1734-8CFG is a versatile POINT I/O digital module featuring 8 configurable DC points that can function as inputs or outputs. It operates on a voltage range of 11 to 28.8 Volts DC and supports an input current range of 2 to 5 mA. Designed for modular automation systems, it fits seamlessly on DIN rail mounts and connects with 1734-TOPS, 1734-TOP, 1734-TBS, and 1734-TB terminal base units. Its open-style enclosure and rugged engineering allow operation in temperatures from -20 to 55 degrees Celsius. The module supports independent input filtering adjustable in millisecond intervals, enhancing signal reliability. This POINT I/O module is widely used in industrial control applications requiring flexible and scalable digital I/O solutions.

Key Features of Allen Bradley 1734-8CFG

  • 8 self-configuring I/O points allowing each point to be independently set as input or output
  • On-state voltage range from 10 to 28.8 V DC with a nominal voltage of 24 V DC
  • Low current consumption with on-state input current between 2 and 5 mA
  • Compatible with Allen Bradley 1734 series POINT I/O terminal bases for flexible installation
  • DIN rail mounting for easy integration into existing automation panels
  • Open-style enclosure suited for cabinet mounting and easy access
  • Supports removal and insertion while powered, enabling maintenance without shutdown
  • Reverse polarity protection enhances reliability in harsh environments
  • Operating temperature range from -20°C to 55°C for various industrial settings
  • Max output current per point up to 0.5 A with surge current protection

Technical Specs of 1734-8CFG

Specification Details
Input/Output Points 8 Configurable DC Points
Input Voltage Range 11 to 28.8 V DC
Input Current 2 - 5 mA
Max Output Current per Point 0.5 A
Module Current (All Outputs) 3.0 A max
Operating Temperature -20 to 55 °C
Mounting DIN Rail
Enclosure Style Open
Power Dissipation 2.6 W at 28.8 V DC
Surge Current 1 A for 100 ms, repeatable every 2s

Applications / Use Case

The Allen Bradley 1734-8CFG module is ideal for industrial automation tasks requiring both digital input and output flexibility. It is widely used in manufacturing systems, packaging machinery, and process control where remote I/O points need configurable access. Its modular design makes it suitable for scalable automation projects, allowing engineers to easily expand or modify control systems. It excels in environments where quick device replacement or upgrades are needed without system downtime, thanks to its hot-swappable capability. The module’s compatibility with Allen Bradley POINT I/O platform ensures smooth integration into Rockwell Automation control architectures, supporting diverse application needs such as machine control, monitoring, and data acquisition.
