1606-XLS480-UPS
1606-XLS480-UPS
Manufacturer: ALLEN BRADLEY
Condition: New and Unused, Surplus.
Overview of Allen-Bradley 1606-XLS480-UPS DC Uninterruptible Power Supply
The Allen-Bradley 1606-XLS480-UPS is a high-performance DC uninterruptible power supply (UPS) module designed to provide backup power and bridge power failures in industrial automation systems. It operates with a 24V DC power supply input and includes integrated battery management for two 12V batteries in series. This UPS module ensures a constant output voltage during battery mode, preventing voltage drops as batteries discharge, thus maintaining system stability and preventing downtime.
Key Features of Allen-Bradley 1606-XLS480-UPS
- Backup Power: Provides 24V DC power backup with a continuous output current of 20A and short bursts up to 30A.
- Battery Management: Features separate charging and monitoring of two 12V batteries for optimized battery life.
- Adjustable Buffer Voltage: Four selectable buffer voltage ranges for system customization.
- Temperature Controlled Charging: Uses temperature sensors to extend battery life through precise charging.
- Diagnostic Functions: Battery health monitoring and fault signaling for reliable system maintenance.
- Wide Operating Temperature: Operates reliably from -40°C to +70°C for industrial environments.
- Compact Design: DIN rail mountable, compact size for easy panel integration.
- Safety and Standards Compliance: Meets global safety and quality standards including UL, CE, and CCC.
Technical Specs
| Specification | Details |
|---|---|
| Part Number | 1606-XLS480-UPS |
| Input Voltage | 24V DC nominal (18–30V DC range) |
| Output Voltage | Selectable 22.5V, 24V, 25V, 26V in battery mode; same as input voltage in power supply mode |
| Output Current | 20A continuous, 30A for up to 4 seconds |
| Battery: | Two 12V batteries in series, 3.9–150 Ah |
| Buffer Time | Ranges from 6 min to over 6 hours depending on battery size |
| Operating Temperature | -40°C to +70°C |
| Size (WxHxD) | 46 x 124 x 127 mm |
| Weight | 700 g |
| Mounting | DIN Rail (35 mm) |
Applications / Use Case
The 1606-XLS480-UPS is ideal for providing backup power in critical control systems, industrial automation, and safety systems requiring continuous 24V DC power to prevent data loss and downtime during power interruptions.
Allen-Bradley products benefit from Rockwell Automation’s warranty and worldwide support for industrial reliability.
