Buy Allen-Bradley 1606-XLERED – Product Overview

The Allen-Bradley 1606-XLERED is a dual-input diode redundancy module engineered for critical industrial automation applications requiring reliable backup power. This compact switched-mode power supply delivers 20A nominal output from a 24–60V DC input, featuring two independent 10A input channels that automatically select the active power source. Built to industrial standards with IP20 protection and DIN-35 rail mounting, this component is ideal for factory control panels, motion control systems, and production line automation where continuous operation cannot be compromised.

Allen-Bradley 1606-XLERED Features & Benefits

  • Dual-input diode redundancy ensures automatic failover without manual intervention
  • 20A nominal output with 25A maximum short-circuit rating for high-capacity installations
  • Wide input voltage range (18–60V DC) accommodates variable supply conditions
  • Compact footprint (32 × 124 × 117 mm) maximizes usable panel space
  • Industry-leading 9.1 million hour MTBF at +40°C ensures long service life
  • Low 780 mV output voltage drop and 50 mVpp ripple for sensitive equipment
  • Reverse polarity and output transient protection included; 200V epitaxial diode isolation
  • SELV-compliant design meets EN 60950-1, UL 508, and CE certifications

Allen-Bradley 1606-XLERED Specifications & Datasheet

Parameter Value
Input Voltage (Nominal) 24–48V DC (±25%), Range 18–60V DC
Output Current 20A nominal, 25A max (short circuit)
Number of Inputs 2 (10A each)
Output Voltage Drop 780 mV
MTBF 9.1 million hours (+40°C, SN29500)
Operating Temperature −25 to +70°C
Weight 350 g (0.77 lb)
Dimensions 32 × 124 × 117 mm
Mounting DIN-35 rail
Protection Rating IP20, reverse polarity protected

Allen-Bradley 1606-XLERED Applications in Industrial Automation

This redundancy module is widely deployed in process control systems, factory automation, machine control centers, and industrial production lines where power continuity is mission-critical. It serves as a backup power distribution unit in automated assembly lines, robotics platforms, and automated packaging systems across North America, Europe, and Asia-Pacific industrial markets.
