Overview of Allen-Bradley 1411-2DRL-500 Current Transformer
The Allen-Bradley 1411-2DRL-500 is a single-piece solid-core current transformer with a round outer shape and a 1-inch inner diameter. It has a primary to secondary current ratio of 50:5 amps and provides precise current measurement and monitoring in power systems. This model offers an accuracy of ±3% at 60 Hz, suitable for power monitoring and protection applications.
Key Features of Allen-Bradley 1411-2DRL-500
- Single Piece Solid-Core Design: Ensures durability and reliable magnetic performance.
- Current Ratio: 50 Amp primary to 5 Amp secondary, standard for industrial applications.
- Accuracy: ±3% at 60 Hz for reliable power measurement and monitoring.
- 1 Inch Inner Diameter: Fits around conductors up to 1 inch in diameter.
- Round Outer Shape: Facilitates easy installation in power distribution systems.
- Compatible with Safety Standards: Designed for use in power monitoring and protection circuits.
Technical Specs of Allen-Bradley 1411-2DRL-500
| Parameter | Specification |
|---|---|
| Core Type | Single Piece (Solid-Core) |
| Module Designation | 1" Inner Diameter, Round Outer Shape |
| Current Ratio | 50 A Primary to 5 A Secondary |
| Accuracy at 60 Hz | ±3% |
| Burden VA at 60 Hz | 1.5 VA |
| Frequency | 60 Hz |
| Application | Power Monitoring and Protection |
Applications / Use Case
The 1411-2DRL-500 current transformer is used in industrial power monitoring systems and protection circuits. It is suitable for accurate measurement of current flow in feeders, transformers, and power metering applications.
Allen-Bradley products are supported by Rockwell Automation’s quality assurance and global service network.
-
