1321-3RA45-B

Overview of Allen Bradley 1321-3RA45-B

The Allen Bradley 1321-3RA45-B is a three-phase line reactor designed for power conditioning and motor protection applications. It features a NEMA 1 enclosure suitable for indoor environments and is rated at 45 amps with an inductance of 0.7 mH. This line reactor helps reduce harmonics, voltage spikes, and electrical noise in motor drive systems, improving reliability and extending equipment life. Its robust design complies with industry standards, making it a trusted component for industrial automation and motor control setups. With a voltage rating up to 600 V and frequency support at 50 Hz, the 1321-3RA45-B integrates seamlessly into a variety of electrical control systems.

Key Features of Allen Bradley 1321-3RA45-B

• Three-phase line reactor with 45 amp continuous current rating
• Inductance value of 0.7 millihenries to provide power conditioning
• NEMA 1 type enclosure offering protection for indoor use
• Designed to minimize harmonics and reduce electrical noise in motor circuits
• Compatible with 600 V input voltage systems at 50 Hz frequency
• Helps protect variable frequency drives and motors from voltage spikes
• Compact design suitable for space-constrained industrial panels
• Improves system reliability by enhancing power quality and reducing stress on components

Technical Specs of 1321-3RA45-B

Parameter	Specification
Current Rating	45 Amps
Inductance	0.7 mH
Enclosure Type	NEMA 1 (Indoor)
Voltage Rating	Up to 600 V
Frequency	50 Hz
Mounting	Panel Mount

Applications / Use Case

The Allen Bradley 1321-3RA45-B line reactor is primarily used in motor control centers and variable frequency drive (VFD) systems for industrial automation. It reduces electrical noise and mitigates the harmful effects of voltage spikes that can cause premature failure in motors and sensitive electronic components. This reactor is suitable for factory automation, conveyor systems, pump controls, and HVAC motor applications where maintaining power quality is critical. It also assists in maintaining smooth motor operation by limiting current surges during start-up and improving overall system efficiency. Its robust design and standardized ratings make it ideal for integration into a wide range of industrial environments requiring reliable motor protection and power conditioning.
