Overview of Allen Bradley 104-C09EJ22
The Allen Bradley 104-C09EJ22 is a high-quality IEC reversing contactor engineered by Rockwell Automation. It is designed for controlling AC motors with a rated operating current of 9 amps, making it suitable for medium-load applications. This model features a 24V DC electronic coil with line-side coil termination and screw terminal connections, offering reliable and efficient operation in industrial environments. The contactor includes one normally open (N.O.) and one normally closed (N.C.) auxiliary contact, providing flexibility for control and signaling functions. It complies with UL electrical standards, ensuring safety and performance. The 104-C09EJ22 is factory assembled and well-suited for motor starting and reversing operations in automation systems.
Key Features of Allen Bradley 104-C09EJ22
- Rated operating current of 9A for AC-3 squirrel-cage motor starting and stopping
- 24V DC electronic coil with line-side coil termination
- Screw terminal type for secure and easy wiring installation
- Auxiliary contact arrangement of 1 normally open (N.O.) and 1 normally closed (N.C.)
- Compact IEC design suitable for integration in control panels
- UL certified for electrical safety and industrial use
- Factory assembled for consistent build quality and reliability
- Supports forward and reverse control of motors for versatile applications
Technical Specs of 104-C09EJ22
| Specification | Detail |
|---|---|
| Rated Operating Current | 9 A (AC-3) |
| Coil Voltage | 24 V DC |
| Coil Termination | Line Side |
| Contact Configuration | 1 Normally Open (N.O.), 1 Normally Closed (N.C.) Auxiliary Contacts |
| Terminal Type | Screw Terminals |
| Standards | UL Certified |
| Application | Reversing Contactor for Motor Control |
Applications / Use Case
The Allen Bradley 104-C09EJ22 is ideal for controlling reversible AC motors in various industrial automation applications. It facilitates forward and reverse motor control in conveyor systems, machine tools, hoists, and other motor-driven equipment. Its 9A rating makes it suitable for moderate power loads, commonly found in system control panels for manufacturing and processing industries. The device’s ability to reliably handle motor reversing operations reduces mechanical wear and improves operational efficiency. Furthermore, it is a dependable choice for automated production lines where precise motor direction control is required to maintain workflow and safety.
