Siemens 6ES7511-1AK02-0AB0 SIMATIC S7-1500 CPU 1511-1 PN module for distributed PROFINET IRT automation systems

SIMATIC S7-1500 CPU 1511-1 PN (Siemens 6ES7511-1AK02-0AB0): Complete Specifications, Price and Alternatives Guide

Controls engineers evaluating a compact, high-performance CPU for distributed PROFINET IRT applications have one critical question to answer before ordering: does the 6ES7511-1AK02-0AB0 have enough program memory and the right communication architecture for this specific system? With 150 KB of program work memory, 1 MB of data memory, 60 nanosecond bit performance, and an integrated dual-port PROFINET IRT switch, the Siemens 6ES7511-1AK02-0AB0 — the SIMATIC S7-1500 CPU 1511-1 PN — sits at the intersection of real-time synchronization capability and practical cost control for mid-scale automation systems. This guide covers specifications, variant selection, firmware compatibility, and procurement considerations in one place so you can confirm fit and move to order without second-guessing.

If you have already confirmed this is the right part, check current pricing and availability at LeadTime.ca — ships worldwide.

Who Should Buy the 6ES7511-1AK02-0AB0 — and Who Shouldn't

This CPU is the right choice for engineers building or maintaining SIMATIC S7-1500 systems where PROFINET IRT real-time synchronization is a functional requirement and program size stays within 150 KB. Confirm these criteria before ordering:

  • Your application requires PROFINET IRT with an integrated dual-port Ethernet switch — the 6ES7511-1AK02-0AB0 includes this natively; single-port variants do not
  • Your TIA Portal installation is V17 or newer — firmware V2.9 on this module requires it; legacy V15.x installations need the older 6ES7511-1AK01-0AB0
  • Program memory demand is at or below 150 KB — programs exceeding this ceiling require a CPU 1515 or higher
  • Panel supply voltage is 24 VDC within the 19.2 to 28.8 VDC permissible range
  • You have budgeted for a SIMATIC memory card ordered separately — the CPU will not initialize without one

If your application requires PROFIsafe failsafe logic, the CPU 1511F variant is the correct choice. If program memory above 150 KB is needed, move to the CPU 1515. If PROFINET IRT is not required and budget is the primary driver, the single-port CPU 1511 is a lower-cost option.

On this page:

What the SIMATIC S7-1500 CPU 1511-1 PN Actually Does in Your System

The Siemens 6ES7511-1AK02-0AB0 is the controller brain of a SIMATIC S7-1500 distributed automation system — not a standalone unit. It executes user control logic, manages process data flow between I/O modules and communication interfaces, and handles PROFINET IRT real-time communication via its integrated dual-port Ethernet switch. At 60 nanosecond bit performance, it is the fastest available execution speed in the 1511 product line, delivering deterministic cycle times down to 625 microseconds in distributed isochronous mode and 1 millisecond in central mode.

The integrated dual-port PROFINET IRT switch is the defining feature that separates this model from budget alternatives. In practical terms, it eliminates the need for a separate communication module in distributed synchronization applications, saving cabinet space, reducing wiring complexity, and lowering latency. The CPU supports up to 96 concurrent PROFINET connections, with 10 of those reserved for engineering workstations, HMI panels, and web access — leaving 86 connections available for field devices and distributed I/O.

The front-panel 3.45 cm display with 8 pushbuttons and 2 mode buttons provides on-site diagnostics and parameter access without a laptop. A hardware real-time clock with 6-week backup at 40 °C and configurable cycle time monitoring round out the operational intelligence built into the module. The hardware functional status is FS03, representing the stable production release for this generation.

Typical System Architecture for the 6ES7511-1AK02-0AB0

The 6ES7511-1AK02-0AB0 sits at the top of the local S7-1500 station, coordinating all I/O modules on the backplane while simultaneously managing PROFINET IRT communication to remote distributed field devices. Here is where it fits in a typical deployment chain:

  • TIA Portal engineering workstation connects via Ethernet to the CPU's PROFINET interface for programming, diagnostics, and commissioning
  • CPU 1511-1 PN installed on 35 mm DIN rail with S7-1500 backplane power supply module directly adjacent
  • Local signal modules (digital and analog I/O) connect on the same backplane, powered through the backplane bus — CPU draws up to 10 W from the bus
  • SIMATIC memory card installed in CPU front slot before power-on — stores program code and retentive data independently of backplane
  • Dual RJ45 PROFINET ports daisy-chain to remote ET 200SP or ET 200MP distributed I/O stations, servo drives, and HMI panels across the production network using CAT5e or better shielded cable up to 100 meters per segment

Where This CPU Gets Deployed: Industries and Use Cases

Conveyor synchronization with robotic pick-and-place stations is a primary deployment scenario for the 6ES7511-1AK02-0AB0. The 625 microsecond distributed IRT cycle eliminates synchronization jitter between robot arm position feedback and conveyor belt speed control — critical in packaging and automotive assembly where misalignment by even a few milliseconds causes downstream rejects.

Distributed temperature zone control in pharmaceutical or food processing ovens is another well-matched application. The integrated PID controller with optimization handles real-time loop synchronization across multiple distributed analog I/O modules, and the 1 MB data memory provides adequate space for zone setpoints, trend data, and batch records.

Multi-axis coordination in discrete manufacturing — CNC integration, servo drive networks, material handling gantries — benefits from the full IRT synchronization mode, which ensures actuator commands and position feedback arrive within a predictable, bounded cycle window. The CPU's support for up to 96 concurrent connections accommodates dense device networks without additional hardware.

Water treatment and chemical processing facilities with distributed pump and valve networks use the centralized logic with distributed I/O model: a single 6ES7511-1AK02-0AB0 manages remote pressure, flow, and level sensors across multiple process zones while maintaining sub-millisecond response to critical threshold alerts.

Application Typical Deployment
Automotive assembly line CPU coordinates multi-station robot handoff via PROFINET IRT; distributed ET 200SP I/O at each station
Packaging machinery Conveyor speed and pick-and-place synchronization; IRT eliminates jitter across distributed drives
Pharmaceutical batch processing Distributed temperature and pressure zone control; PID optimization; retentive data for batch records
Food and beverage processing Centralized logic with remote I/O across oven zones, filling stations, and labeling units
Logistics and material handling Conveyor network control with robotic integration; NTP synchronization for event timestamping
Water and chemical processing Distributed pump and valve control; real-time sensor feedback synchronized to actuator commands

Purchase-Decision Specifications at a Glance

Specification Value
Model Number 6ES7511-1AK02-0AB0
Product Line SIMATIC S7-1500
Firmware Version V2.9 (requires TIA Portal V17 or newer)
Bit Performance 60 nanoseconds
Program Work Memory 150 KB
Data Work Memory 1 MB
PROFINET Interface 1 × IRT with integrated 2-port switch, 2 × RJ45
Max Concurrent Connections 96 total (10 reserved for ES/HMI/web)
Supply Voltage 24 VDC (19.2 to 28.8 V permissible)
Operating Temperature -25 to +60 °C horizontal / -25 to +40 °C vertical

Full technical specifications are available on the product page at LeadTime.ca.

CPU 1511-1 PN vs. Other S7-1500 CPUs: Which One Do You Actually Need?

Feature 6ES7511-1AK02-0AB0 (This Model) CPU 1511 Single Port CPU 1511F Failsafe CPU 1515
Program Memory 150 KB 150 KB 128 KB 500 KB
PROFINET IRT Switch Yes (dual-port) No (single port) No (single port) Yes (dual-port)
PROFIsafe Support No No Yes No
Min Isochronous Cycle 625 µs distributed / 1 ms central Limited 2–4 ms 625 µs distributed
Real-Time Sync Mode Full IRT Limited Not applicable Full IRT
Typical Cost (USD) $1,200–1,600 $900–1,100 $1,400–1,800 $1,800–2,200
Best For IRT distributed systems Budget-driven builds Safety-rated applications Large program footprints

If your architecture requires PROFINET IRT real-time synchronization at the lowest entry cost, the 6ES7511-1AK02-0AB0 is the correct choice — check current availability at LeadTime.ca.

Expert Verdict: Honest Assessment for Procurement and Engineering Teams

The Siemens 6ES7511-1AK02-0AB0 earns its place as the workhorse entry point for PROFINET IRT distributed automation. The integrated dual-port switch is not a marketing feature — it directly eliminates a separate communication module from the BOM, reducing cabinet width, wiring runs, and per-node latency in isochronous mode. The 60 nanosecond bit performance and 150 KB program memory are adequate for most single-machine and multi-zone applications in food, pharma, packaging, and logistics. The FS03 hardware status confirms this is a mature, stable production release with full TIA Portal V17 support under firmware V2.9. The 6-week hardware clock backup, front-panel display, and 4-trace 512 KB diagnostics buffer add meaningful commissioning and maintenance utility that lower-tier CPUs omit.

The honest limits are equally clear. Program memory at 150 KB becomes a real constraint as logic complexity grows — if your application involves coordinating more than a few dozen motion axes, extensive recipe management, or large data logging requirements, the 150 KB ceiling will force a redesign. Engineers who discover this constraint mid-project typically pay a significant cost penalty migrating to CPU 1515 hardware. Similarly, this CPU has no failsafe capability; applications requiring SIL-rated safety logic must use the CPU 1511F variant. Finally, phaseout planning matters here: the successor 6ES7511-1AL02-0AB0 has been announced, and new designs should evaluate whether to standardize on the next generation rather than the current model. For existing S7-1500 installations requiring replacements or spares, the 6ES7511-1AK02-0AB0 remains the correct and available part.

From a procurement standpoint, lead times of 2 to 4 weeks are typical for standard orders, with 4 to 8 weeks for bulk or configured builds. Total system cost for a complete S7-1500 starter configuration — CPU, power supply, I/O modules — runs $3,000 to $5,000 USD and above; the CPU alone represents roughly 25 to 35 percent of that figure. Do not overlook the SIMATIC memory card in the BOM: the CPU will not initialize without one, and cards are sold separately in the $100 to $150 range for typical 100–500 MB capacities. If this matches your system requirements, view current stock and pricing at LeadTime.ca.

For volume pricing or to confirm lead time before committing to a build, contact the LeadTime.ca team directly — we ship worldwide.

Wiring and Installation Overview

  • Mount the CPU module on a 35 mm DIN rail within the S7-1500 backplane; both horizontal and vertical orientations are supported, but operating temperature limits differ — horizontal allows up to +60 °C, vertical is limited to +40 °C, and the front display deactivates above +50 °C horizontal or +40 °C vertical
  • Connect 24 VDC supply within the 19.2 to 28.8 V permissible range to the CPU power input; reverse polarity protection is built in, so no external protection diode is required — rated current draw is 0.7 A with a maximum of 0.95 A and a 5 ms hold-up time on supply loss
  • Insert the SIMATIC memory card into the front-panel slot before applying power — the card must be present at power-on for the CPU to initialize; a green LED confirms card recognition
  • Connect PROFINET IRT cables to the two rear RJ45 ports using CAT5e or better shielded cabling; ground cable shields at the control cabinet entry point and observe the 100-meter maximum cable length per PROFINET specification; ports support auto-crossing and daisy-chain topology via the internal switch
  • Verify no gaps between the CPU and adjacent I/O modules on the backplane before powering on; confirm all retention clips are fully engaged and inspect rear connector faces for contamination

Firmware Version and TIA Portal Compatibility: What Engineers Miss

Firmware version mismatches are the single most common source of order errors for this CPU. The 6ES7511-1AK02-0AB0 ships with firmware V2.9, which requires STEP 7 TIA Portal V17 or newer. If your engineering environment is running TIA Portal V15.x, this module will not be fully compatible — you need the 6ES7511-1AK01-0AB0, which carries firmware V2.5. Verify your installed TIA Portal version before finalizing the purchase order.

For teams running mixed firmware environments or upgrading from V2.5 installations, an existing V2.5 module can be updated to V2.9 via firmware upload through TIA Portal — but confirm your software license covers the target version before attempting this in a production environment. The phaseout successor, 6ES7511-1AL02-0AB0, is the recommended choice for new designs that will be built on TIA Portal V17 and beyond.

Wrong-Part Prevention Checklist Before You Order

The following checklist catches the majority of ordering errors for the Siemens 6ES7511-1AK02-0AB0. Verify every item before submitting a purchase order:

  1. Confirm firmware version matches installation: FW V2.9 requires STEP 7 TIA Portal V17 or newer; if using TIA Portal V15.x, order 6ES7511-1AK01-0AB0 instead (older FW V2.5)
  2. Verify system architecture: this CPU cannot be used standalone; must install on S7-1500 backplane with power supply, signal modules, and SIMATIC memory card
  3. Check PROFINET vs. non-PROFINET need: "6ES7511-1AK02-0AB0" = PROFINET IRT dual switch included; "6ES7511-1AK00-0AB0" = single PROFINET port only (no IRT switch)
  4. Confirm memory card procurement: order SIMATIC memory card separately; CPU will not initialize without it (cards sold separately, ~100-500 MB capacity options)
  5. Validate supply voltage: must be 24 VDC ±20% (19.2-28.8 V nominal range); check existing cabinet power availability
  6. Confirm replacement scenario: if replacing older S7-1200 or S7-300 CPU, confirm program migration feasibility and connector compatibility (not plug-and-play; new panel layout required)
  7. Check phaseout status: this model approaches end-of-life; confirm availability window with distributor (typically 24+ months still available, but new designs should consider 6ES7511-1AL02-0AB0)

If any item on this checklist raises a question before you finalize the order, contact the LeadTime.ca team — or review the full product listing to cross-reference specifications before committing.

Frequently Asked Questions

Does the 6ES7511-1AK02-0AB0 include a SIMATIC memory card in the box?

No. The SIMATIC memory card is sold separately and must be ordered alongside the CPU. The CPU will not boot or initialize without a memory card installed in the front-panel slot. Typical capacity options range from 100 MB to 500 MB and above; confirm required capacity based on your program size and retentive data requirements before ordering.

What is the difference between the 6ES7511-1AK02-0AB0 and the 6ES7511-1AK00-0AB0?

The 6ES7511-1AK02-0AB0 includes an integrated dual-port PROFINET IRT switch enabling isochronous real-time synchronization down to 625 microseconds in distributed mode. The 6ES7511-1AK00-0AB0 has a single PROFINET port with no IRT switch, which eliminates isochronous mode capability. If your application requires distributed synchronized control across multiple PROFINET devices, the dual-port IRT variant is the correct choice. If PROFINET connectivity is needed only for basic I/O communication without strict timing requirements, the single-port variant reduces cost.

Can this CPU be used to replace an S7-300 or S7-1200 CPU in an existing panel?

Not as a direct plug-in replacement. The SIMATIC S7-1500 uses a different backplane architecture, connector format, and programming model than the S7-300 and S7-1200 families. Migrating from those platforms requires a new panel layout, new mounting hardware, and a program migration effort in TIA Portal. Siemens provides migration tools within TIA Portal to assist with code conversion, but physical installation is not plug-and-play. Confirm migration scope before ordering to avoid panel rework surprises.

What is the phaseout timeline for the 6ES7511-1AK02-0AB0, and should I still design it into new systems?

The 6ES7511-1AK02-0AB0 is entering end-of-life, with the successor 6ES7511-1AL02-0AB0 announced as the next-generation replacement. Current availability is typically confirmed through a 24-plus month support window from distributors, meaning stock remains accessible for spares and replacement orders. For new system designs starting today, evaluating the successor model is advisable to avoid a mid-lifecycle hardware change. For existing S7-1500 installations requiring replacements, this part remains the correct and available option — confirm current stock with your distributor before committing to a build schedule.

What cycle time performance can I expect in a real PROFINET IRT deployment?

In distributed isochronous mode, the minimum achievable cycle time is 625 microseconds. In central isochronous mode, the minimum is 1 millisecond. These figures are hardware-defined minimums under FW V2.9; actual application cycle times depend on the number of connected devices, I/O volume per cycle, and user program execution load. The CPU supports up to 96 concurrent PROFINET connections, with 10 reserved for engineering and HMI access.

Is the front-panel display always active, or does it shut off in hot environments?

The front-panel 3.45 cm display deactivates automatically above 50 °C in horizontal mounting orientation and above 40 °C in vertical orientation. This is a thermal protection behavior, not a fault condition — the CPU continues operating normally while the display is deactivated. If continuous front-panel access in high-ambient-temperature cabinets is required, plan the mounting orientation and cabinet cooling accordingly.

Why Order the 6ES7511-1AK02-0AB0 from LeadTime.ca

  • Ships worldwide — LeadTime.ca supplies automation engineers and procurement teams globally, not limited to any single region
  • Sourcing support for hard-to-locate parts, phaseout models, and time-sensitive replacement orders
  • Volume pricing available for multi-unit orders and system builds — contact the team directly for quotes on quantities
  • Fast response on lead time confirmation before you commit to a build schedule — avoids project delays caused by availability surprises
  • Paired accessory sourcing: SIMATIC memory cards and supporting S7-1500 components available alongside the CPU

At-a-Glance Summary

  • Model: Siemens 6ES7511-1AK02-0AB0 — SIMATIC S7-1500 CPU 1511-1 PN, hardware status FS03, firmware V2.9
  • Bit performance: 60 nanoseconds — fastest execution speed in the 1511 product line
  • Work memory: 150 KB program / 1 MB data — sufficient for small-to-medium automation logic; programs exceeding 150 KB require CPU 1515 or higher
  • PROFINET IRT: integrated dual-port switch with 2 × RJ45, up to 96 concurrent connections, 625 µs minimum distributed isochronous cycle
  • Supply voltage: 24 VDC, 19.2 to 28.8 V permissible range, 0.7 A rated / 0.95 A maximum current
  • Operating temperature: -25 to +60 °C horizontal mounting / -25 to +40 °C vertical mounting
  • Dimensions: 35 × 147 × 129 mm, 405 g — standard S7-1500 DIN rail form factor
  • TIA Portal requirement: V17 or newer for FW V2.9; legacy V15.x users must order 6ES7511-1AK01-0AB0 (FW V2.5)
  • SIMATIC memory card: mandatory, sold separately, system will not initialize without it
  • Phaseout status: successor 6ES7511-1AL02-0AB0 announced; current model available with 24-plus month typical support window — new designs should evaluate the successor
  • Typical market pricing: $1,200–1,600 USD for CPU module; complete S7-1500 starter system typically $3,000–5,000 USD and above
