Siemens 6ES7193-6BP20-0BA0 SIMATIC ET 200SP BaseUnit BU15-P16+A10+2B push-in terminals for distributed I/O panel

Siemens 6ES7193-6BP20-0BA0 SIMATIC ET 200SP, BaseUnit BU15-P16+A10+2B, Type A0, Push-in terminals, with 10 AUX terminals, bridged to the left — Specs, Installation & Selection Guide

When a controls engineer or procurement specialist searches for the Siemens 6ES7193-6BP20-0BA0 by exact part number, the decision is already close. The question is whether this specific 15mm BaseUnit with 16 push-in signal terminals and 10 left-bridged auxiliary terminals matches the exact slot in your SIMATIC ET 200SP architecture — or whether a closely related variant like the 6ES7193-6BP00-0BA0 is actually what you need. This guide gives you the technical verification, variant comparison, and procurement reality to confirm the right call before the order goes out.

If you have already confirmed this is the right part, check current pricing and availability at LeadTime.ca — ships worldwide.

Who Should Buy the 6ES7193-6BP20-0BA0 — and Who Shouldn't

This BaseUnit is the right choice if your application checks the following criteria:

  • You are building on a SIMATIC ET 200SP carrier rail and need a Type A0 BaseUnit that accepts ET 200SP I/O modules
  • Your panel layout requires 16 push-in signal terminal positions and the physical wire gauge falls within the supported range (push-in terminal design per IEC 60947-7-1)
  • You need 10 auxiliary terminals pre-bridged to the left for cross-rail signal continuity without manual jumper wires
  • Your DIN rail layout can accommodate the 15mm mounting width and 141mm height of this unit
  • Your system design includes an external upstream protection device, since this BaseUnit has no internal circuit breaker

If you need screw or cage-clamp terminals instead of push-in, require zero auxiliary terminals to reduce cost, or are working with a wider enclosure format that suits a 20mm or 27mm BaseUnit variant, you will want to evaluate the 6ES7193-6BP00-0BA0 or the 6ES7193-6BP21-0BA0 respectively before ordering.

On this page:

What the 6ES7193-6BP20-0BA0 Actually Does in a Distributed I/O System

The 6ES7193-6BP20-0BA0 is a distributed I/O base unit terminal module — the physical foundation onto which SIMATIC ET 200SP I/O modules mount and terminate their process signals. In practical terms, it is the component that translates field wiring (sensors, actuators, discrete and analog signals) into the organized, modular connection structure that the ET 200SP carrier rail system expects.

What separates this variant from the simplest BaseUnit options is the inclusion of 10 auxiliary terminals pre-bridged to the left. In multi-module panel builds, these bridged AUX terminals eliminate the need for manual jumper wires between adjacent modules, reducing commissioning time by 6 to 10 hours on typical multi-module installations while also removing undocumented jumper configurations that complicate future troubleshooting. The push-in terminal design, compliant with IEC 60947-7-1, adds a second reliability advantage: unlike screw terminals, push-in connections do not loosen under thermal cycling or mechanical vibration, which directly reduces maintenance-related downtime in high-vibration environments such as automotive welding cells or CNC machinery.

The Type A0 designation is not cosmetic. It defines a standardized signal routing and pin assignment configuration that ensures consistent behavior across all Type A0 units in the ET 200SP ecosystem, making it straightforward to replicate rack layouts across multiple machines or production lines without re-validating pinouts each time.

Where This BaseUnit Sits in a Typical ET 200SP System Architecture

The 6ES7193-6BP20-0BA0 occupies the field-side termination layer — it sits between the physical process wiring and the ET 200SP I/O modules that report signal states back to the controller.

  • A SIMATIC S7-1500 or S7-1200 PLC communicates over PROFINET or PROFIBUS to an ET 200SP interface module mounted on the carrier rail
  • The ET 200SP carrier rail hosts the interface module and a series of BaseUnits, each accepting one I/O module on top
  • The 6ES7193-6BP20-0BA0 mounts directly to the ET 200SP carrier rail at its 15mm slot position, bridging AUX signal rails to adjacent units on the left
  • Digital input modules, digital output modules, or analog I/O modules seat into the BaseUnit and connect to its 16 signal terminals
  • Field sensors and actuators wire directly into the push-in terminal positions on the BaseUnit, completing the signal path from process to controller

Industries and Applications That Specify This BaseUnit

Automotive manufacturing is the most common deployment environment for the 6ES7193-6BP20-0BA0. In robotic welding cells and assembly line controls, the compact 15mm width allows 6 to 8 modules to fit within a standard automation enclosure — compared to 3 to 4 modules with older 40mm-plus screw-terminal baseunits — delivering approximately a 60% reduction in panel footprint for equivalent I/O count. The push-in terminal stability under vibration is a direct operational requirement in these environments.

Pharmaceutical batch processing systems specify this BaseUnit for its hygienic push-in terminal design and the traceability that comes from a standardized, pre-bridged configuration. Fewer undocumented field modifications during commissioning is a compliance advantage in regulated manufacturing environments.

Food and beverage packaging lines, high-speed discrete assembly, multi-axis CNC control architectures, and building management systems for HVAC valve and damper control all appear regularly in procurement records for this part. The 24 VDC operating voltage standard for ET 200SP distributed I/O aligns with the power architectures of all these applications.

Application Typical Deployment
Automotive welding cell PLC Distributed I/O node reducing panel wiring, improving diagnostics on robotic stations
Pharmaceutical batch reactor Decentralized sensor aggregation with push-in terminals for hygienic, traceable connections
High-speed packaging line Compact enclosure automation where 15mm footprint reduces overall machine profile
Multi-axis CNC control Remote start/stop and emergency halt signal distribution across control cabinet
Building management / HVAC 24 VDC standardized node for valve and damper control in BMS architecture

Purchase-Decision Specifications and Variant Comparison

Specification Value / Detail
Model Number 6ES7193-6BP20-0BA0
Product Family SIMATIC ET 200SP
BaseUnit Variant BU15-P16+A10+2B
BaseUnit Type Type A0
Width 15 mm
Height 141 mm
Terminal Type Push-in (IEC 60947-7-1)
Signal Terminals 16
Auxiliary Terminals 10 (bridged to left)
Circuit Protection No internal breaker — external upstream protection device required

Full technical specifications are available on the product page at LeadTime.ca.

Variant Part Number Signal Terminals AUX Terminals Width Best For
BU15-P16+A10+2B (This model) 6ES7193-6BP20-0BA0 16 10 (left-bridged) 15 mm Multi-module systems, dense panels
BU15-P16+A0+2B (No AUX) 6ES7193-6BP00-0BA0 16 None 15 mm Simple I/O systems, cost-sensitive builds
BU16-P16+A10+2B (Right-bridged) 6ES7193-6BP21-0BA0 16 10 (right-bridged) 20 mm Larger enclosures, right-side AUX bridging
Wider modules Various 32+ Varies 27+ mm High-density I/O, system scale-up

If your architecture requires left-bridged auxiliary terminals in a 15mm footprint for a multi-module ET 200SP stack, the 6ES7193-6BP20-0BA0 is the correct choice — check current availability at LeadTime.ca.

Expert Verdict: When to Buy It and When to Look at Alternatives

The 6ES7193-6BP20-0BA0 earns its place in almost every multi-module ET 200SP build where panel space is constrained and commissioning efficiency matters. The 15mm width delivers a measurable panel footprint advantage — approximately 60% smaller than equivalent I/O count built on older 40mm-plus screw-terminal baseunits — and the pre-bridged AUX terminals eliminate a category of wiring errors that are genuinely difficult to trace after the fact. For automotive assembly lines, pharmaceutical process skids, or any installation where the ET 200SP architecture is already standardized, this is not a difficult decision. SIMATIC ET 200SP distributed I/O architecture is reported in approximately 70% of new automotive assembly line controls and 60% of pharmaceutical process automation systems in North America and Europe, which translates to strong long-term spare parts availability and technician familiarity.

Where the 6ES7193-6BP20-0BA0 is not the right answer: if you are wiring a simple two-module island where cross-bridging is unnecessary, the 6ES7193-6BP00-0BA0 saves cost without any functional penalty. If your field wiring uses screw or cage-clamp terminations as a site standard, this BaseUnit is the wrong terminal type entirely and you need to identify the appropriate screw-terminal variant before ordering. And if your I/O count exceeds what 16 signal terminals can support in a single slot, plan for multiple units in series or evaluate 27mm-width variants rather than expecting this unit to stretch beyond its specification.

From a procurement standpoint, the 6ES7193-6BP20-0BA0 carries an active lifecycle status with an EAN code of 4025515080862 for direct supplier verification. Typical lead times run 4 to 8 weeks depending on regional warehouse stock, so for time-sensitive builds it is worth confirming availability before finalizing your schedule. If you are ordering in volume, bundling BaseUnits with compatible ET 200SP I/O modules in a single order often improves both lead time coordination and pricing. If this matches your system requirements, view current stock and pricing at LeadTime.ca.

For volume pricing or to confirm lead time before committing to a build, contact the LeadTime.ca team directly — we ship worldwide.

Wiring and Installation Overview

  • Mount the BaseUnit on a secured, de-energized ET 200SP carrier rail — slide horizontally until seated; verify audible seating confirmation before proceeding with any wiring
  • Confirm left-bridged AUX terminal orientation against your system layout diagram before inserting field conductors; the bridging direction is fixed in this model and cannot be reconfigured on site
  • Use conductors within the push-in terminal specification range — verify gauge compatibility per Siemens datasheet before assembly; over-sized conductors risk terminal contact damage that is not field-repairable
  • After inserting each push-in conductor to the audible click, perform a gentle tug-test on each wire and a multimeter continuity check across all signal terminals before applying power
  • Install and label an external upstream protection device on the 24 VDC supply line before energizing — this BaseUnit has no internal circuit breaker, and operating without upstream protection risks catastrophic failure of connected I/O modules

ET 200SP Module Compatibility

The 6ES7193-6BP20-0BA0 is compatible with the standard ET 200SP I/O module ecosystem. The following table from the brief summarizes what integrates and what does not:

Module Type Compatible with 6ES7193-6BP20-0BA0 Notes
8-point digital input module Yes Standard input termination
8-point digital output module Yes Standard output termination
4-point analog input/output module Yes Analog signal routing
Combination I/O modules Yes Mixed signal configurations
ET 200S baseunits (older generation) No Different carrier standard — not interchangeable
SIMATIC S7-1200 terminal blocks No Incompatible pinout
Third-party distributed I/O No Siemens ET 200SP ecosystem only

Always verify that your ET 200SP carrier rail revision supports this BaseUnit before finalizing the module stack. Do not mix ET 200SP and ET 200S hardware on the same carrier.

What Engineers Get Wrong When Ordering This Part — and How to Prevent It

The following checklist is drawn directly from the most common ordering and installation errors associated with this BaseUnit. Verify every item before submitting a purchase order or beginning installation:

  1. Verify input identifier matches official Siemens part number 6ES7193-6BP20-0BA0 exactly (case-sensitive)
  2. Confirm ET 200SP carrier rail compatibility with your specific I/O module set (do not mix with ET 200S or older SIMATIC series)
  3. Check that push-in terminal design suits your wiring gauge and connection method (not suitable for screw or cage-clamp terminals)
  4. Validate 15mm mounting width fits target DIN rail or frame (not compatible with 20mm or 27mm spacing)
  5. Confirm 10 AUX terminals bridged to the left orientation (not the BU15-P16+A0+2B variant without AUX)
  6. Ensure external upstream protection device exists (this baseunit has no internal circuit breaker)
  7. Verify operating voltage range (typically 24 VDC for ET 200SP distributed I/O systems)
  8. Confirm delivery lead time acceptable (typically 4-8 weeks for this variant; check current EAN stock)

If any item on this checklist raises a conflict with your project spec, contact the LeadTime.ca team before ordering — we can help verify the correct variant or confirm stock against your required delivery date.

Frequently Asked Questions

What is the difference between 6ES7193-6BP20-0BA0 and 6ES7193-6BP00-0BA0?

The 6ES7193-6BP20-0BA0 includes 10 auxiliary terminals pre-bridged to the left, while the 6ES7193-6BP00-0BA0 has no auxiliary terminals. Both share the same 15mm width, 16 signal terminal positions, and push-in terminal design. The practical difference shows up in multi-module systems: the BU15-P16+A10+2B (6BP20) eliminates manual jumper wires between modules, reducing commissioning time by 6 to 10 hours on typical builds. If you do not need cross-module AUX bridging, the 6BP00 variant is a lower-cost option.

Does this BaseUnit have a built-in circuit breaker?

No. The 6ES7193-6BP20-0BA0 has no internal circuit breaker or integrated protection device. An external upstream protection device must be installed in series with the 24 VDC supply before this BaseUnit. Omitting external protection exposes the BaseUnit and all connected I/O modules to potential catastrophic failure in the event of a power surge or short circuit. Include the protection device part number and rating in your system bill of materials.

Is the 6ES7193-6BP20-0BA0 compatible with an ET 200S carrier rail?

No. The 6ES7193-6BP20-0BA0 is designed exclusively for the SIMATIC ET 200SP carrier rail. It is not compatible with ET 200S baseunits, which use a different carrier standard. Mixing ET 200S and ET 200SP hardware on the same rail is not supported and will result in physical and electrical incompatibility. Verify your carrier rail designation before specifying this BaseUnit.

What conductor gauges are supported by the push-in terminals on this BaseUnit?

Push-in terminals on ET 200SP BaseUnits are designed for conductors typically in the range supported per the Siemens datasheet for this product — verify the exact gauge specification in the official Siemens product documentation for 6ES7193-6BP20-0BA0 before wiring. The terminals comply with IEC 60947-7-1. Using conductors outside the specified gauge range risks terminal contact damage that cannot be repaired in the field.

What is the typical lead time for the 6ES7193-6BP20-0BA0?

Lead time for this active product is typically 4 to 8 weeks depending on regional warehouse stock levels at time of order. The EAN code 4025515080862 can be used to check current inventory status with your distributor. For time-sensitive builds, confirm availability before locking a project delivery schedule. LeadTime.ca ships worldwide and can provide current stock status and lead time confirmation on request.

Can I use the 6ES7193-6BP20-0BA0 with analog I/O modules as well as digital?

Yes. The Type A0 BaseUnit designation covers compatibility with 8-point digital input modules, 8-point digital output modules, 4-point analog input/output modules, and combination mixed-signal modules within the ET 200SP ecosystem. Verify that each specific I/O module you intend to use is rated for a Type A0 BaseUnit in the Siemens module documentation before finalizing your module selection.

Why Order the 6ES7193-6BP20-0BA0 from LeadTime.ca

  • LeadTime.ca ships worldwide — no geographic restriction on orders, whether you are sourcing for a single panel build or a multi-site project
  • Exact part number stocking focus means the 6ES7193-6BP20-0BA0 is sourced and verified by catalog number, not approximated by description
  • Volume pricing is available for multi-unit orders — contact the team before placing a large order to discuss bundling with compatible ET 200SP I/O modules
  • Lead time confirmation is available before order commitment — use EAN 4025515080862 or the exact part number to get a current availability response
  • Hard-to-find and time-sensitive industrial automation parts are the core business, not a secondary catalog

6ES7193-6BP20-0BA0 At-a-Glance Summary

  • Official product: SIMATIC ET 200SP, BaseUnit BU15-P16+A10+2B, Type A0, push-in terminals, 10 AUX terminals bridged to the left
  • Part number: 6ES7193-6BP20-0BA0 — verify digit-by-digit; differs from 6ES7193-6BP00-0BA0 (no AUX) by a single character sequence
  • Physical footprint: 15mm width x 141mm height — fits standard ET 200SP carrier rail slot
  • 16 push-in signal terminals (IEC 60947-7-1) plus 10 left-bridged auxiliary terminals
  • No internal circuit breaker — external upstream 24 VDC protection device is mandatory
  • Pre-bridged AUX terminals reduce commissioning time by 6 to 10 hours on typical multi-module builds
  • 15mm width enables 6 to 8 modules in a standard enclosure — approximately 60% footprint reduction versus older 40mm-plus screw-terminal baseunits
  • Compatible with 8-point DI, 8-point DO, 4-point AI/AO, and combination ET 200SP modules; not compatible with ET 200S or S7-1200 terminals
  • Lifecycle status: Active — EAN 4025515080862 for stock verification
  • Typical lead time: 4 to 8 weeks — confirm availability at LeadTime.ca before locking project schedule
