Siemens 6ES7193-6BP00-0BA0 — ET 200SP Base Unit Selection Guide

By Abdullah Zahid
13 min read
Siemens 6ES7193-6BP00-0BA0 SIMATIC ET 200SP base unit with push-in terminals for distributed I/O applications

Siemens 6ES7193-6BP00-0BA0 SIMATIC ET 200SP BaseUnit BU15-P16+A0+2B, BU Type A0, Push-In Terminals, Without AUX Terminals, Bridged to the Left — Specifications, Wiring and Selection Guide

If you are finalizing the base unit selection for a SIMATIC ET 200SP distributed I/O assembly, you are likely weighing terminal count, conductor compatibility, and panel space against what each variant actually delivers. The Siemens 6ES7193-6BP00-0BA0 is a 15 mm wide, single-slot base unit carrying 16 push-in process terminals, a Type A0 I/O module slot, and a 10 A maximum P1/P2 bus rated for 24 V DC — a compact connector frame that bridges field wiring directly to intelligent ET 200SP I/O modules without screw tools. Understanding exactly where this model fits — and where it does not — determines whether your panel build goes in clean the first time or generates a rework call.

If you have already confirmed this is the right part, check current pricing and availability at LeadTime.ca — ships worldwide.

Who Should Buy the 6ES7193-6BP00-0BA0 — and Who Shouldn't

This base unit is the correct choice when all of the following are true for your application:

  • Your system runs on a SIMATIC ET 200SP architecture with an S7-1200 or S7-1500 controller and TIA Portal engineering environment
  • You require exactly 16 process terminals — conductor sizes between 0.14 mm² and 2.5 mm² (AWG 26–14)
  • A 24 V DC supply is available at the cabinet, with a 10 A Type B or C miniature circuit breaker installed upstream on the power feed
  • Panel depth allows a module measuring 15 mm wide, 117 mm high, and 35 mm deep on DIN rail
  • Your installation altitude does not exceed 5,000 m (installations above 2,000 m require manual review)
  • Push-in terminal technology is acceptable or preferred — no screw-terminal requirement

If you need more than 16 process channels, a base unit with auxiliary terminal support, or screw terminals for high-vibration environments, this model is not the correct choice. Evaluate larger multi-slot variants or screw-terminal BU alternatives within the ET 200SP family before ordering.

On this page:

What the 6ES7193-6BP00-0BA0 Actually Does in a Live System

The 6ES7193-6BP00-0BA0 is not an I/O module — it is the physical and electrical foundation that makes an I/O module functional in a decentralized installation. In practical terms, it is the connector frame that accepts one Type A0 I/O module in its single slot, routes 24 V DC power through the P1 and P2 bus terminals at up to 10 A, and presents 16 push-in process terminals for field wiring. Every sensor wire, actuator cable, or signal conductor from the field terminates here before the signal reaches the intelligence of the mounted I/O module.

The BU15-P16+A0+2B designation encodes the key facts directly: 15 mm width, 16 process terminals, one Type A0 slot, and 2 power bus contacts. With terminals bridged to the left and zero auxiliary terminals, this model passes bus potential continuously along the DIN rail without creating new isolated potential groups — an important design constraint when planning power segmentation across a multi-unit ET 200SP station. Push-in terminal technology means no screwdriver is required for conductor insertion, which approximately 70 to 80 percent of new SIMATIC ET 200SP installations now specify as the preferred wiring method, reducing commissioning labor and eliminating screw-loosening failure modes in the field.

The 40 g module weighs less than most cable ties used to dress its own field wiring, yet its isolation is type-tested to 707 V DC — a meaningful figure in noisy industrial environments where transients on a 24 V DC bus can spike well above nominal. The operating temperature range spans -30°C to 60°C for horizontal mounting, narrowing to -30°C to 50°C in vertical orientation, covering the majority of indoor machine cabinet installations globally.

Typical ET 200SP System Architecture with This Base Unit

The 6ES7193-6BP00-0BA0 sits at the field-wiring layer of the ET 200SP station, one step below the interface module and one step above the field devices themselves. It physically connects the I/O module slot to the plant floor.

  • S7-1200 or S7-1500 PLC communicates over PROFINET to the ET 200SP interface module mounted at the left end of the DIN rail station
  • The interface module distributes backplane bus signals to all base units installed to its right, including this 6ES7193-6BP00-0BA0
  • This base unit receives bus power and data through its left-side backplane connector; it hosts one Type A0 I/O module — digital input, digital output, or analog — in its single slot
  • The 16 push-in process terminals connect directly to field devices: sensors on input-type modules, actuators or loads on output-type modules
  • The P1/P2 power bus terminals carry 24 V DC forward to adjacent base units on the same rail, enabling daisy-chain power distribution across the station

Industries and Applications Where This Base Unit Is Deployed

In automotive manufacturing, this base unit appears in welding station and assembly line subpanels where decentralized I/O aggregates position sensors and solenoid outputs within a few meters of the machine cell, reducing cable runs back to a central cabinet.

Food and beverage packaging lines use it for bottling and filling machine control, where the compact 15 mm width allows dense base unit arrays on short DIN rail sections inside hygienic stainless cabinets with limited internal volume.

Chemical and pharmaceutical production facilities specify it for distributed monitoring of process instruments, particularly where SafeLogic ET 200SP safety modules occupy adjacent slots and field wiring must terminate at a consistent, certified connection point.

OEM panel builders in machine tool and semiconductor wafer handling applications use it to standardize their base unit specification across product lines — one base unit catalog number, one wiring procedure, one spare part to stock regardless of which I/O module type occupies the slot.

Legacy system expansion projects add 6ES7193-6BP00-0BA0 units to existing ET 200SP stations when a production process adds new sensor or actuator points without justifying a full I/O module replacement cycle at the central controller.

Application Typical Deployment
Automotive welding station Distributed I/O hub aggregating 16 field signals per machine cell, connected via PROFINET to S7-1500 PLC
Food and beverage packaging line Compact base unit arrays in hygienic stainless cabinets; digital I/O for proximity sensors and pneumatic valve outputs
Chemical/pharma process monitoring Mixed digital and analog I/O modules in ET 200SP safety-certified stations alongside SafeLogic modules
Machine tool OEM panels Standardized base unit across product families; single spare part covers all module types
Legacy system I/O expansion Additional base units added to existing DIN rail station without replacing interface module or controller
Semiconductor wafer handling Push-in terminal reliability preferred in cleanroom cabinets where vibration and maintenance access are limited

Purchase-Decision Specifications at a Glance

Parameter Value
Supply voltage 24 V DC
Maximum current, P1/P2 bus 10 A
Per-terminal maximum current 2 A
External protection required 10 A Type B or C miniature circuit breaker
Isolation rating (type test) 707 V DC
Process terminals 16 (push-in, 0.14–2.5 mm², AWG 26–14)
I/O module slots 1 (Type A0)
Auxiliary terminals 0
Dimensions (W × H × D) 15 mm × 117 mm × 35 mm
Operating temperature -30°C to 60°C (horizontal) / -30°C to 50°C (vertical)

Full technical specifications are available on the product page at LeadTime.ca.

6ES7193-6BP00-0BA0 vs. Other ET 200SP Base Unit Variants — Which One Do You Actually Need?

Model / Variant Process Terminals I/O Module Slots AUX Terminals Terminal Type Best For
6ES7193-6BP00-0BA0 (this model) 16 1 (Type A0) 0 Push-in Compact single-slot installations, no auxiliary power distribution needed
6ES7193-6BP00-2BA0 16 1 (Type A0) 0 Push-in Same specification; different packaging unit quantity — evaluate for bulk procurement
32-channel base unit variants 32 Multiple slots Varies by model Push-in or screw Applications requiring more than 16 process channels per module position
Base unit with AUX terminals 16 1 (Type A0) Yes Push-in Applications requiring auxiliary power distribution to field devices from the base unit
Screw-terminal base unit variants 16 1 (Type A0) Varies Screw High-vibration environments, or where installation crew is trained exclusively on screw terminals

If your architecture requires 16 push-in process channels with a single Type A0 slot and no auxiliary terminal overhead, the 6ES7193-6BP00-0BA0 is the confirmed correct selection — check current availability at LeadTime.ca.

Expert Verdict: Is This the Right Base Unit for Your Project?

The 6ES7193-6BP00-0BA0 earns its place as the default choice for single-slot ET 200SP distributed I/O installations for two concrete reasons. First, the 15 mm width is genuinely narrow — it allows high-density base unit arrays on standard DIN rail sections without the panel volume penalty that plagues larger multi-slot alternatives. Second, push-in terminal technology removes two persistent maintenance failure modes from the field: screw loosening under vibration and inconsistent torque application during commissioning. For panel builders constructing identical machine variants across a product family, a single base unit catalog number covering all Type A0 I/O module types is a real bill-of-materials simplification with measurable cost impact.

The honest limits of this model are equally clear. The 2 A per-terminal current maximum is a hard constraint — any output driving a solenoid, relay coil, or motor starter above 2 A needs an external relay stage, not a direct terminal connection. The zero auxiliary terminals means power distribution for field sensors must come from an external terminal strip or an adjacent base unit variant with AUX support, not from this module itself. And the single Type A0 slot means you are committing one physical module position per 16-channel group — an acceptable trade-off for focused I/O aggregation but inefficient if your application routinely expands beyond 16 signals at a given network node. If you have already confirmed this matches your design, view current stock and pricing at LeadTime.ca.

From a procurement standpoint, this is a generally available component with typical market lead times of one to five business days from stock locations. The 6ES7193-6BP00-0BA0 represents a relatively small share of total ET 200SP subsystem cost — base units typically account for five to fifteen percent of total station cost, with I/O modules driving the majority of spend. That said, a missing base unit holds up an entire I/O station commissioning, so confirming stock before your build schedule begins is worth the two-minute check. LeadTime.ca carries this model and ships worldwide; volume pricing is available for multi-unit orders, and bundling with ET 200SP I/O modules is a common request the team can quote together.

For volume pricing or to confirm lead time before committing to a build, contact the LeadTime.ca team directly — we ship worldwide.

Wiring and Installation Overview

The following points cover the key requirements and verifications for installing the 6ES7193-6BP00-0BA0. Engineers requiring full step-by-step procedures should refer to the Siemens SIMATIC ET 200SP installation manual from support.industry.siemens.com.

  • Mount the base unit on DIN rail with the alignment groove correctly oriented; confirm secure seating before applying power or wiring field conductors
  • Connect 24 V DC positive to the P1 terminal and 24 V DC return to the P2 terminal using push-in insertion — no screwdriver required; conductors must be stripped to 6–8 mm and sized between 0.14 mm² and 2.5 mm² (AWG 26–14)
  • Verify a 10 A Type B or C miniature circuit breaker is installed upstream on the power feed before energizing — this base unit has no internal fuse or protection; the external breaker is mandatory
  • Insert field conductors into the 16 push-in process terminals with firm, steady pressure until flush; apply a light tug after insertion to confirm seating — no movement indicates correct contact
  • Confirm that no single terminal load exceeds 2 A and that the cumulative load across all terminals does not exceed the 10 A P1/P2 bus rating before applying power to the station

Commissioning in TIA Portal: What to Verify Before Going Live

TIA Portal is the required engineering environment for configuring the 6ES7193-6BP00-0BA0 within an ET 200SP station. The following overview covers the key commissioning checkpoints; full configuration procedures are documented in the Siemens TIA Portal commissioning manual.

  • In TIA Portal, insert the SIMATIC ET 200SP hardware into the project catalog and drag the 6ES7193-6BP00-0BA0 base unit into the station configuration; then assign the appropriate I/O module to the single Type A0 slot
  • Auto-encoding assigns module addresses based on physical slot position — no manual DIP switch configuration is required, but verify that the address shown in the hardware configuration tree matches the physical installation order on the DIN rail
  • Use TIA Portal online diagnostics after download to confirm all 16 process channels are visible in the I/O address map and that bus voltage at P1/P2 reads within the acceptable range
  • Command each digital output ON in forced mode and verify signal presence at the terminal with a multimeter; read each digital input with a test signal and confirm state change in the online monitor
  • For safety-critical applications, perform an isolation test and document results before releasing the station to production

Wrong-Part Prevention Checklist Before You Order

Before placing your order for the 6ES7193-6BP00-0BA0, confirm every item on this checklist to avoid a costly mismatch between what arrives and what your installation requires:

  1. Confirm SIMATIC ET 200SP compatibility with your controller (S7-1200, S7-1500) and software version
  2. Verify 24 V DC power supply is available; this model does not include internal power regulation
  3. Check that 10 A Type B or C miniature circuit breaker is installed upstream on power feed
  4. Confirm conductor sizes match: 0.14 mm² minimum, 2.5 mm² maximum
  5. Verify installation altitude does not exceed 5,000 m; altitudes above 2,000 m require manual review
  6. Ensure you do not confuse BU type A0 (1 slot) with other BU variants (e.g., multiple slots)
  7. Confirm no need for AUX terminals; this model has 0 AUX terminals
  8. Check operating temperature range fits your application: -30°C to 60°C (horizontal) or -30°C to 50°C (vertical)

If any item on this checklist reveals a mismatch, contact the LeadTime.ca team to identify the correct ET 200SP base unit variant for your project before ordering.

Frequently Asked Questions

Does the 6ES7193-6BP00-0BA0 include an internal fuse or circuit breaker?

No. This base unit has no internal overcurrent protection. A 10 A Type B or C miniature circuit breaker must be installed upstream on the 24 V DC power feed before the P1/P2 terminals. Powering the unit without external protection creates a fire hazard and risks destroying all I/O modules mounted to the station in a short-circuit event.

Can I use stranded wire with these push-in terminals, and what is the maximum conductor size?

Push-in terminals on the 6ES7193-6BP00-0BA0 accept conductors from 0.14 mm² to 2.5 mm² (AWG 26–14). Stranded conductors are supported within this range. Conductors must be stripped to 6–8 mm before insertion. Any conductor larger than 2.5 mm² will not seat correctly and risks terminal damage — do not force oversized conductors.

What is the difference between the 6ES7193-6BP00-0BA0 and the 6ES7193-6BP00-2BA0?

Both models share the same electrical and mechanical specification: 16 process terminals, one Type A0 I/O module slot, 15 mm width, push-in terminals, and zero auxiliary terminals. The difference is in the packaging unit quantity — the 6ES7193-6BP00-2BA0 is the bulk packaging variant, which may carry price advantages for orders at ten units or higher. Confirm your required quantity with LeadTime.ca to determine which catalog number applies.

Is this base unit compatible with ET 200SP safety I/O modules?

The 6ES7193-6BP00-0BA0 is fully compatible with the SIMATIC ET 200SP module portfolio, which includes safety-rated I/O modules for use in safety-critical monitoring and equipment protection applications. Verify that the specific safety I/O module you intend to install specifies Type A0 base unit compatibility in its datasheet before committing to this base unit model.

What happens if my installation site is above 2,000 m altitude?

This base unit supports installations up to 5,000 m above sea level. However, installations above 2,000 m require manual review — electrical clearances, derating requirements, and environmental factors change at higher altitudes. Contact your engineering team or LeadTime.ca for guidance before specifying this unit at high-altitude sites.

Can I mix this base unit with other ET 200SP base unit types on the same DIN rail station?

Yes. ET 200SP stations are designed for mixed base unit configurations on a shared DIN rail, allowing different channel counts, terminal types, and module slot configurations within the same station. Because the 6ES7193-6BP00-0BA0 bridges potential to the left with no new potential groups created, power segmentation planning must account for where isolated groups are introduced by other base unit variants in the same station.

Why Engineers and Procurement Teams Order From LeadTime.ca

  • Ships worldwide — no geographic restrictions on where orders are fulfilled
  • Stocks hard-to-find distributed I/O components including ET 200SP base units and accessories
  • Volume pricing available for multi-unit orders — contact the team for quantity breaks on base units and bundled I/O module quotes
  • Fast response on lead time confirmation before you commit to a project BOM or build schedule
  • Knowledgeable team that can cross-reference ET 200SP base unit variants and flag compatibility issues before the order ships

At-a-Glance Summary

  • Catalog number: Siemens 6ES7193-6BP00-0BA0 — BaseUnit BU15-P16+A0+2B, BU type A0, push-in terminals, without AUX terminals, bridged to the left
  • 16 push-in process terminals accepting 0.14–2.5 mm² (AWG 26–14) conductors; 0 auxiliary terminals
  • Single Type A0 I/O module slot; auto-encoding, no DIP switch configuration required
  • 24 V DC supply; 10 A maximum P1/P2 bus current; 2 A maximum per-terminal current
  • External 10 A Type B or C miniature circuit breaker mandatory — no internal protection
  • Isolation type-tested to 707 V DC
  • Dimensions: 15 mm (W) × 117 mm (H) × 35 mm (D); weight: 40 g
  • Operating temperature: -30°C to 60°C horizontal, -30°C to 50°C vertical; max altitude 5,000 m
  • Certifications include KC, FM, CCC-Ex, NK, and CCS maritime approvals
  • Global warming potential: 0.873 kg CO2 eq total; 0 kg CO2 eq during operation
  • Compatible with S7-1200, S7-1500 controllers and TIA Portal engineering environment
  • Available worldwide through LeadTime.ca; typical market lead time 1–5 business days from stock
