Siemens 6EP1436-2BA10 — SITOP PSU300S 20A Power Supply Review

By Abdullah Zahid
12 min read
Siemens 6EP1436-2BA10 SITOP PSU300S 20A stabilized 24V DC DIN rail power supply for industrial control panels

Siemens 6EP1436-2BA10 SITOP PSU300S 20A Stabilized Power Supply — Specs, Selection Guide, and Procurement Review

Controls engineers searching for the Siemens 6EP1436-2BA10 are typically at one of two decision points: confirming this is the right unit for a current build, or verifying a replacement for a failed supply already in service. The 6EP1436-2BA10 is Siemens' SITOP PSU300S 20A Stabilized Power Supply — a three-phase industrial unit that converts 400–500V AC input to a regulated 24V DC output at 20A continuous, delivering 480W of stabilized control power for PLC systems, safety modules, and solenoid banks. The wide input tolerance of 340–550V AC and passive convection cooling are the two characteristics that most often close the selection decision.

If you have already confirmed this is the correct part for your panel, check current pricing and availability for the 6EP1436-2BA10 at LeadTime.ca — ships worldwide.

Who Should Buy the 6EP1436-2BA10 — and Who Shouldn't

The Siemens 6EP1436-2BA10 SITOP PSU300S is the right choice when your site and load profile match the following hard constraints:

  • Three-phase 400–500V AC (wide range 340–550V AC) is confirmed available at the panel input — this is a three-phase-only unit
  • Total 24V DC control load across all solenoids, PLC modules, safety relays, and indicators draws less than 18A at full simultaneous operation
  • Output voltage adjustment range of 24–28V DC is acceptable to all downstream devices in the circuit
  • Panel has a 35mm DIN rail with adequate clear length for mounting — no panel-mount standoff option exists
  • Operating environment stays within 0°C to 70°C — no outdoor enclosures, no furnace-adjacent mounting
  • Single-unit design is acceptable — no active failover or built-in redundancy is required

If your site has single-phase input only, the SITOP PSU100U is the correct selection. If your sustained load exceeds 20A or you require a redundancy architecture, plan for PSU300U, PSU400U series, or a modular SITOP configuration with a dedicated redundancy module before ordering.

On this page:

What the 6EP1436-2BA10 Actually Does in a Control Cabinet

The Siemens 6EP1436-2BA10 SITOP PSU300S 20A Stabilized Power Supply occupies the critical interface layer between facility three-phase power distribution and the 24V DC control logic layer. It steps 400–500V AC three-phase input down to a stable, regulated 24V DC output rated at 20A continuous — 480W total — and holds that output steady even when the upstream utility voltage moves anywhere within the 340–550V AC wide tolerance band. That automatic input range adjustment is the functional core of this product: it absorbs utility sags, transient overvoltages, and inter-phase imbalances without requiring any external voltage conditioning hardware.

The output is adjustable from 24V to 28V DC via a front-panel trim potentiometer, which matters when feeding servo drive enable circuits or resolver signal conditioning where the exact rail voltage affects firmware calibration. Built-in overload and short-circuit protection prevent cascade failures to connected PLC modules or safety relays. The unit is fanless, relying entirely on natural convection cooling — which means zero maintenance on thermal components and no acoustic signature in the panel. Weight is 1.6 kg, and the form factor is DIN rail only, making panel integration fast for integrators building cabinets on standard 35mm rail.

Where the 6EP1436-2BA10 Sits in a Typical Control System

The 6EP1436-2BA10 sits between the facility three-phase service and the 24V DC bus that feeds all control logic and field devices in the panel. Understanding the component chain helps confirm whether 20A capacity is sufficient before ordering.

  • Facility three-phase distribution feeds the main panel service disconnect (external branch circuit protection required — the 6EP1436-2BA10 does not replace this)
  • AC input connects to the 6EP1436-2BA10 terminals (L1, L2, L3, PE) — 340–550V AC wide input range handles voltage variation transparently
  • 24V DC output bus distributes regulated power to the PLC rack (S7-1200 or S7-300 series), distributed I/O modules, SIRIUS safety relay modules, and solenoid valve banks
  • An external DC-side fuse or miniature circuit breaker (rated to 20A) is required in series on the positive output per electrical code — this is not integrated
  • Optional SITOP redundancy module or UPS unit can be added downstream on the 24V bus for critical continuity applications

Industries and Applications That Rely on the SITOP PSU300S

In automotive assembly and stamping environments, the 6EP1436-2BA10 commonly serves as the primary 24V DC supply for compact PLC stations controlling fixture clamping, weld gun enable signals, and conveyance interlocks — applications where the load is well-characterized and typically falls within the 10–16A range at full cycle.

Food and beverage processing lines use it to power pneumatic control valve solenoid banks (8–12 devices) alongside SIRIUS safety relay modules handling emergency stop and light curtain logic. The stabilized output is valued here because conveyors and filling machines cycle solenoids rapidly, and inductive switching transients on an unstabilized supply can generate nuisance faults in PLC input modules.

In pharmaceutical and packaging machinery, the unit frequently supplies servo drive enable circuits and resolver signal conditioning in motion control subsystems, where the adjustable 24–28V DC output allows the commissioning technician to match the exact rail voltage required by drive firmware without adding a separate trim regulator.

Material handling and logistics installations — sorters, accumulation conveyors, transfer cars — use it in modular panel designs where the compact 1.6 kg form factor and DIN rail mounting allow standardized cabinet assemblies to be replicated across multiple system segments.

Application Typical Deployment
PLC station with distributed I/O (S7-1200 + 16 modules) Primary 24V DC bus supply; estimated 5–8A typical draw, well within 20A rating
Safety relay module bank (emergency stop, light curtain) Stabilized supply for SIRIUS 3RK series; 3–5A typical load
Pneumatic solenoid valve bank (10 devices, staggered actuation) 12–15A typical; verify simultaneous energization does not approach 20A limit
Servo drive enable and resolver signal conditioning 2–3A steady-state; adjustable output used for firmware voltage calibration
Redundant supply topology with SITOP redundancy module Paired with second PSU300S and redundancy card on shared 24V bus
Mobile or retrofit control cabinet, space-constrained 1.6 kg DIN rail form factor fits tight panel layouts; no mounting brackets required

Key Specifications: What Engineers Need to Make the Purchase Decision

Parameter Specification
Input Voltage (Nominal) 400–500V AC, three-phase, 50/60Hz
Input Voltage (Wide Range) 340–550V AC (auto-adjusts, no manual range switching)
Output Voltage (Nominal) 24V DC
Output Voltage (Adjustable) 24–28V DC (front-panel trim potentiometer)
Output Current (Rated) 20A continuous
Total Power Output 480W
Mounting 35mm DIN rail only
Weight 1.6 kg
Operating Temperature 0°C to 70°C
Cooling Method Natural convection — no fan

Full technical specifications are available on the product page at LeadTime.ca.

6EP1436-2BA10 vs. PSU300U vs. Alternatives — Which One Do You Actually Need?

Feature 6EP1436-2BA10 (PSU300S) PSU300U (Siemens) Meanwell RSP-500-24 Phoenix Contact QUINT POWER
Output Capacity 20A / 480W 20A / 480W (higher internal margin) 20.8A / 500W 20A / 480W (base config)
Input Voltage 400–500V AC three-phase 400–500V AC three-phase 180–264V AC single-phase 400–500V AC three-phase
Form Factor DIN rail compact DIN rail compact Enclosed single unit Modular, field-expandable
Stabilization Integrated Integrated Integrated Integrated
Redundancy Capable With external SITOP module With external SITOP module No Yes, native support
Cost Position Entry-level SITOP Mid-tier SITOP Budget competitor Premium competitor
Typical Lead Time 4–8 weeks 4–8 weeks 2–4 weeks 4–8 weeks
SITOP Ecosystem Full integration Full integration Limited compatibility No integration

If your application needs full SITOP ecosystem compatibility with an established three-phase stabilized supply, the 6EP1436-2BA10 is the correct starting point — check current stock and pricing at LeadTime.ca.

Expert Verdict: Honest Assessment of the SITOP PSU300S for Industrial Use

The Siemens 6EP1436-2BA10 SITOP PSU300S 20A Stabilized Power Supply delivers on its core promise: stable 24V DC output from a wide-range three-phase input, in a compact 1.6 kg DIN rail package that does not require fan maintenance or external voltage conditioning. The 340–550V AC input tolerance is a genuine operational advantage on sites where utility voltage quality varies seasonally or where the same cabinet design is deployed across different facility electrical services. The fanless convection design holds up well in typical industrial cabinet environments within the 0–70°C operating range, and the output ripple and regulation characteristics are appropriate for feeding both logic-level PLC modules and inductive solenoid loads simultaneously. For integrators building standardized 24V DC panels in the 10–16A load range, this model represents a known quantity with an established delivery history.

Where the 6EP1436-2BA10 has real limits: 20A is a hard ceiling, and real-world simultaneous solenoid inrush on a 10-device pneumatic bank can approach or exceed that ceiling during commissioning if actuation is not staggered. The unit also offers no active failover — if redundancy is in the specification, the external SITOP redundancy module must be planned into the BOM from the start, not retrofitted later. The PSU300U is the stronger choice for critical applications where internal design margin matters even if the electrical nameplate is identical, and the Phoenix Contact QUINT POWER range is worth evaluating when field-expandable redundancy is a future-state requirement. The Meanwell RSP-500-24 is single-phase only and does not offer SITOP ecosystem integration — it is not a drop-in equivalent regardless of the 500W headline figure.

From a procurement standpoint, typical lead time is 4–8 weeks for new factory stock, and expedited orders typically carry a 15–25% premium over standard pricing. Single-unit pricing typically falls in the $400–600 CAD range depending on distributor and order volume, with volume discounts available at 5-unit quantities or more. For critical continuous-process applications, maintaining a spare unit on-site is worth the carrying cost given the lead time window. If you have confirmed this is the correct part for your build, view current stock and pricing for the 6EP1436-2BA10 at LeadTime.ca.

For volume pricing or to confirm lead time before committing to a build schedule, contact the LeadTime.ca team directly — we ship worldwide.

Wiring and Installation Overview

The following is an installation overview only. Engineers performing first installation or working in jurisdictions with specific electrical code requirements should reference the official Siemens SITOP PSU300S installation manual and applicable local standards for full wiring diagrams, torque specifications, and conductor sizing tables.

  • Mount the unit on a 35mm DIN rail — this is the only supported mounting orientation; the unit must be mounted vertically on the rail with a minimum 100mm of clear air space above and below for convection cooling
  • Connect three-phase AC input: L1, L2, L3 line conductors plus PE ground to the input terminal block — conductor sizing for a 20A three-phase supply is typically 2.5–4mm² per local electrical code; all AC connections must be made with the main service disconnect open and verified dead with a multimeter
  • Connect DC output: positive 24V DC to the red output terminal, 0V return to the black terminal — install the external DC-side fuse or miniature circuit breaker rated for 20A in series on the positive output lead before any branch loads
  • Adjust output voltage using the front-panel trim potentiometer (marked 24–28V DC range) with a flat-head screwdriver, verifying with a digital multimeter; allow 5 minutes between adjustments before re-measuring
  • After initial power-up, verify the LED indicator shows green (normal operation), measure DC output under actual load conditions, and document the commissioning results including input AC voltage, output DC voltage set point, measured load current, and ambient temperature

Compatible SITOP Modules and System Expansion

The 6EP1436-2BA10 is part of the SITOP PSU stabilized power supply ecosystem, which supports downstream expansion and monitoring without replacing the base supply unit.

  • SITOP Redundancy Module — connects in parallel with a second PSU300S unit on the 24V DC bus; provides active diode-based failover so that a failure of one supply does not interrupt output to the control circuit
  • SITOP UPS Module — integrates on the 24V DC output side to provide battery-backed ride-through during momentary AC interruptions; relevant for continuous-process or safety-system applications where even brief 24V loss triggers a controlled shutdown sequence
  • SITOP Monitoring Card — adds diagnostic signaling (output voltage status, overload pre-warning) to the control system; connects to PLC input modules for predictive maintenance monitoring of the supply unit itself

Wrong-Part Prevention Checklist Before You Order

Before placing an order for the Siemens 6EP1436-2BA10, work through this checklist in full — each item corresponds to a common ordering error that results in a return, a delay, or an installation that does not pass commissioning:

  1. Verify facility has three-phase 400-500V AC available; single-phase sites need PSU100U not PSU300S
  2. Confirm 20A @ 24V DC is sufficient for total control load (count all solenoids, safety relays, PLC modules, indicator lights)
  3. Check that load voltage tolerance accepts 24-28V DC adjustment range; some safety devices are fixed 24V only
  4. Ensure panel has DIN rail space; PSU300S is rail-mounted only, no panel-mount standoffs available
  5. Verify operating environment stays within 0-70°C; outdoor or high-temp process areas may require thermal derating
  6. Confirm no redundancy mandate in specification; single-unit design offers no active failover

If any item on this checklist does not clear, contact the LeadTime.ca team before ordering — we can confirm the correct variant or alternative model for your application and check current availability worldwide.

Frequently Asked Questions

Can the 6EP1436-2BA10 be used on a 480V AC three-phase system common in North American facilities?

Yes. The 6EP1436-2BA10 has a wide input range of 340–550V AC, which covers standard 480V AC three-phase North American industrial service as well as 400V AC European service. No range switching or external transformer is required — the unit adjusts automatically within this window.

How do I know if 20A is enough for my control panel load?

Sum the rated current draw of every device on the 24V DC bus: PLC CPU, each I/O module, every safety relay, each solenoid valve coil, all indicator lights, and any auxiliary devices. Use worst-case simultaneous draw. If the total exceeds 18A, the 6EP1436-2BA10 is operating at or near its ceiling — plan for the PSU300U or PSU400U series instead. A 10–15% safety margin below rated capacity is standard practice for continuous industrial loads.

Is the 6EP1436-2BA10 compatible with a SITOP redundancy module for failover protection?

Yes, but redundancy requires adding an external SITOP redundancy module to the 24V DC bus — it is not built into the PSU300S unit itself. Two PSU300S units connect through the redundancy module, which provides active diode-based output combining and isolates a failed supply without interrupting the DC bus. This must be planned into the panel design from the start; it cannot be field-added without additional rail space and wiring.

What does the output voltage adjustment range of 24–28V DC mean for safety relay compatibility?

The 24–28V DC range means the unit's output can be trimmed upward from the 24V nominal. Most safety relays and PLC modules operate correctly across 20.4–28.8V DC (per IEC 61131-2), so the adjustment range is safe for the majority of standard control devices. However, some specific safety relay firmware or resolver signal conditioners are factory-calibrated for exactly 24V DC — verify the operating voltage window of each sensitive device before trimming above 24V nominal.

What is the typical lead time for the 6EP1436-2BA10 and should I keep a spare on hand?

Typical lead time from factory stock is 4–8 weeks. Expedited orders typically carry a 15–25% cost premium. For panels in continuous production or safety-critical roles, maintaining at least one spare unit on-site is strongly recommended — a 4–8 week wait for a replacement during an unplanned outage is a significant operational cost in most manufacturing environments.

Does the 6EP1436-2BA10 provide branch circuit protection?

No. The built-in overload and short-circuit protection in the 6EP1436-2BA10 protects the supply unit itself — it is not a branch circuit protector. An external DC-side fuse or miniature circuit breaker rated for 20A must be installed in series on the positive 24V output per local electrical code (NFPA 79, CEC, or applicable standard). This is a mandatory installation requirement, not optional.

Why Order the 6EP1436-2BA10 from LeadTime.ca

  • Ships worldwide — no regional sourcing restrictions; customers across North America, Europe, Asia-Pacific, and beyond order through LeadTime.ca
  • Direct access to current stock status and lead time confirmation before you commit to a build schedule — critical for a part with 4–8 week typical factory lead times
  • Volume pricing available at 5-unit quantities and above — relevant for OEMs and panel builders running standardized cabinet designs across multiple machine builds
  • Technical team available to confirm correct variant selection, cross-reference alternatives, and flag potential wrong-part issues before the order ships

At-a-Glance Summary

  • Model: Siemens 6EP1436-2BA10 — SITOP PSU300S 20A Stabilized Power Supply
  • Input: 400–500V AC three-phase, 50/60Hz; wide range 340–550V AC auto-adjusting
  • Output: 24V DC at 20A continuous, 480W total; adjustable 24–28V DC via front-panel potentiometer
  • Mounting: 35mm DIN rail only — 1.6 kg, no fan, natural convection cooling
  • Operating temperature: 0°C to 70°C; storage –25°C to +85°C
  • Protection: Built-in overload and short-circuit protection; external DC-side fuse required per code
  • Compliance: CE, FCC Part 15, UL (North America)
  • Typical lead time: 4–8 weeks; expedited at 15–25% premium
  • Not suitable for: single-phase sites, loads above 20A, redundancy mandates without added SITOP module, ambient temperatures above 70°C
  • Ecosystem: Fully compatible with SITOP redundancy modules, UPS modules, and monitoring cards
