Siemens 6AV2123-2DB03-0AX0 SIMATIC HMI KTP400 Basic 4-inch touchscreen operator panel for industrial cabinet installation

Siemens 6AV2123-2DB03-0AX0 SIMATIC HMI KTP400 Basic Basic Panel — Compact 4-Inch HMI Specifications, Pricing, and Alternatives

If you are sourcing a compact touchscreen operator panel for a space-constrained cabinet or a retrofit upgrade on an existing Siemens PLC network, the Siemens 6AV2123-2DB03-0AX0 is likely already on your shortlist. This is the SIMATIC HMI KTP400 Basic Basic Panel — a 4-inch widescreen TFT display running at 480x272 pixels, powered by 24 V DC, and communicating over a single PROFINET interface. The question is not whether it is a capable entry-tier HMI; it is whether this specific variant fits your mounting footprint, fieldbus topology, and engineering platform before you commit to the order.

If you have already confirmed this is the right part, check current pricing and availability at LeadTime.ca — ships worldwide.

Does the Siemens 6AV2123-2DB03-0AX0 Fit Your Project Requirements?

This panel is the right choice for engineers and integrators who meet all of the following criteria:

  • Your mounting cutout is 124 x 100 mm and overall cabinet depth allows 34.9 mm rear projection
  • Your plant infrastructure runs PROFINET — this model provides one Industrial Ethernet PROFINET interface with no RS485, RS422, or RS232 alternatives
  • Your control cabinet supplies stable 24 V DC within the 19.2 to 28.8 V permissible range
  • Your engineering platform is WinCC Basic V13 or later within the STEP 7 TIA Portal environment
  • Your application requires basic visualization and operator input — not SD card data logging or advanced graphics rendering
  • Your installation environment demands at minimum IP65 front-face ingress protection and NEMA Type 4/4x rating

If your application needs a display larger than 4 inches, removable media data logging, or mobile portable supervision, the KTP700 Mobile is the correct alternative to evaluate instead of the 6AV2123-2DB03-0AX0.

On this page:

What the Siemens 6AV2123-2DB03-0AX0 Actually Does on the Shop Floor

The SIMATIC HMI KTP400 Basic Basic Panel functions as the direct interface between a Siemens PLC or PROFINET gateway and the operator standing at a machine. It displays real-time process variables — temperatures, cycle counts, alarm states, production totals — and accepts operator commands through a 4-inch analog-resistive touchscreen, 4 physical function keys, and an onscreen keyboard that supports both numeric and alphanumeric input. The ARM processor and 10 MB of user flash memory handle up to 300 text lists with 100 entries each, which is sufficient for most small-cell visualization applications without any external memory expansion.

What distinguishes this panel from a generic display terminal is its tight integration with the SIMATIC ecosystem. Projects are configured in WinCC Basic V13 or later inside TIA Portal, downloaded via USB or PROFINET, and retained in flash memory through power cycles. A hardware real-time clock with approximately 6 weeks of battery backup keeps timestamps accurate even during planned shutdowns. The built-in buzzer provides audible alarm notification without requiring an external sounder. At 3 W active power draw, the panel imposes a minimal load on 24 V DC control power budgets.

Typical System Architecture for the KTP400 Basic

The 6AV2123-2DB03-0AX0 sits at the operator interface layer, sitting between the PLC or communication gateway and the operator — it is a visualization and input node, not a controller.

  • Siemens S7-1200 or S7-1500 PLC executes control logic and hosts the PROFINET network
  • Industrial Ethernet switch or direct PROFINET connection links the PLC to the KTP400 Basic panel via shielded CAT5e or better cabling
  • The 6AV2123-2DB03-0AX0 displays PLC data addresses and accepts operator inputs that write back to PLC memory
  • 24 V DC control power supply feeds the panel independently through its rear terminal block
  • Engineering PC connects via Mini USB Type-B for initial project download and firmware updates — disconnected during normal production operation

Where Engineers Deploy the KTP400 Basic: Industries and Use Cases

Plastic injection molding clusters are among the most common deployments for the 6AV2123-2DB03-0AX0. A 4-inch panel mounted at each press within a 5-unit molding cluster provides press status, temperature setpoints, and cycle diagnostics without requiring a larger cabinet redesign. The 34.9 mm mounting depth and 124 x 100 mm cutout allow flush-mount installation in existing enclosure doors.

Small conveyor sorting lines benefit from the KTP400 Basic where SKU selection and bottleneck diagnostics need to be accessible at the line frame itself. The onscreen numeric keyboard and 4 function keys allow operators to enter sort parameters without navigating complex menus on an oversized display.

Retrofit upgrades on legacy PLC cabinets represent a strong value case. The 34.9 mm depth allows flush mounting without cabinet redesign, and PROFINET connectivity replaces older parallel I/O wiring runs. Food and beverage processing lines, pharmaceutical production equipment, HVAC packaged units, and textile machinery all appear regularly as deployment environments where compact operator panels with IP65 front-face protection are a base requirement.

Decentralized production cell architectures — where multiple KTP400 panels are linked via PROFINET to a central gateway for cross-cell sequencing and alarm management — represent a natural scaling path. Each sub-line gets its own local operator interface without the cost of a larger panel PC at every station.

Application Typical Deployment
Plastic injection molding One KTP400 Basic per press in a multi-unit cluster; temperature setpoints and cycle diagnostics
Conveyor sorting line Frame-mounted panel for SKU selection and bottleneck diagnostics; numeric keypad entry
Legacy PLC cabinet retrofit Flush-mount replacement for pushbutton arrays; PROFINET replaces parallel I/O wiring
Decentralized production cell Multiple panels per production floor linked to central PROFINET gateway for alarm and sequencing oversight
Packaging and material handling Compact operator station for recipe selection and fault acknowledgment at line entry points
Spare parts bin-picking automation Small control point where screen real estate is secondary and form factor is the primary constraint

Purchase-Decision Specifications for the 6AV2123-2DB03-0AX0

Specification Value
Display Type TFT widescreen, LED backlighting, 65536 colors
Resolution 480 x 272 pixels
Input Method Analog-resistive touch + 4 physical function keys + onscreen numeric and alphanumeric keyboard
Supply Voltage 24 V DC rated; 19.2 to 28.8 V DC permissible range
Rated Current Consumption 125 mA; 3 W active power input (typical)
Communication Interface 1 x Industrial Ethernet (PROFINET); 1 x USB Mini Type-B (up to 16 GB device support)
User Memory (Flash) 10 MB; supports up to 300 text lists, 100 entries each
Mounting Cutout 124 mm x 100 mm; front panel 140 mm x 116 mm; overall depth 34.9 mm
Ingress Protection IP65 front, IP20 rear; NEMA Type 4 and 4x (front)
Operating Temperature 0 to 50°C (vertical); 0 to 40°C at maximum 35-degree tilt; storage -20 to +60°C

Full technical specifications are available on the product page at LeadTime.ca.

KTP400 Basic vs. KTP400F vs. KTP700 Mobile: Which One Do You Actually Need?

Feature KTP400 Basic (6AV2123-2DB03-0AX0) KTP400F KTP700 Mobile
Display Size 4 inches 4 inches 7 inches
Resolution 480 x 272 480 x 272 800 x 480
PROFINET Interface Yes Yes Yes
Form Factor Fixed-mount panel Fixed-mount panel Portable with battery
User Data Memory 10 MB Higher capacity Significantly larger
SD Card Slot No No Yes
IP Rating IP65 front, IP20 rear IP65 front, IP20 rear Full IP65 (portable)
Cost Tier Entry / Budget Mid-tier Premium
Ideal Use Case Compact cabinet retrofit, PROFINET plant Feature-rich small footprint, larger project scope Mobile supervision or detailed process visualization

If your architecture requires fixed-mount PROFINET visualization in a space-constrained cabinet and 10 MB of user memory is sufficient for your screen count, the 6AV2123-2DB03-0AX0 is the correct choice — check current availability at LeadTime.ca.

Expert Verdict: Honest Assessment of the KTP400 Basic for Controls Engineers

The Siemens 6AV2123-2DB03-0AX0 delivers exactly what it promises: a compact, reliable, entry-cost SIMATIC HMI panel that integrates into Siemens PLC ecosystems without requiring gateway hardware, additional drivers, or platform migration effort. For controls engineers working in Siemens shops — automotive, food and beverage, packaging, injection molding — the KTP400 Basic removes integration uncertainty. The 34.9 mm mounting depth, 124 x 100 mm cutout, IP65 front face, and direct PROFINET connectivity mean the panel can be dropped into a retrofit or new-build cabinet with minimal engineering overhead. Backlight MTBF of 20,000 hours and a hardware real-time clock with approximately 6 weeks of battery backup reflect a panel specified for real production environments, not lab demonstrations.

Where the KTP400 Basic reaches its limits is worth stating plainly. There is no SD card slot — if your application requires data logging to removable media, you will need to move up to the KTP700 series. The 10 MB user flash memory is workable for simple visualization projects but will constrain applications with large graphic libraries or deep screen hierarchies. The panel has no built-in safety functions and carries no SIL rating, so it cannot replace a safety-rated HMI in any safety-instrumented system. And at 4 inches with 480 x 272 pixel resolution, it is not the right tool for operators who need to read detailed process trends, multi-variable dashboards, or high-density alarm lists from more than arm's reach.

On the procurement side, the KTP400 Basic is widely stocked across industrial distributors globally, with typical lead times of 2 to 4 weeks from authorized channels. During component shortage periods or seasonal demand peaks, lead times can extend to 6 to 12 weeks — worth confirming before locking in a machine build schedule. Refurbished units are available in the market at 20 to 40 percent discount, but warranty terms vary significantly and should be verified against your project risk tolerance. If your build requires confirmed stock and a lead time guarantee, view current stock and pricing at LeadTime.ca before issuing your purchase order.

For volume pricing or to confirm lead time before committing to a build, contact the LeadTime.ca team directly — we ship worldwide.

Wiring and Installation Overview

  • Prepare the panel cutout to exactly 124 mm width x 100 mm height; the front panel envelope is 140 x 116 mm and overall depth is 34.9 mm — verify rear clearance for cable routing before cutting
  • Connect 24 V DC supply to the rear terminal block (positive to +24V, negative to GND); install an external circuit breaker or fuse in series with the supply; do not reverse polarity
  • Connect PROFINET using shielded CAT5e cable or better via the single Industrial Ethernet interface; route cables away from AC motor drives and high-power switching equipment to minimize EMI exposure
  • Use the Mini USB Type-B port only for initial project download and firmware updates — disconnect the USB cable during normal production operation
  • Verify supply voltage at the terminal block reads within the 19.2 to 28.8 V DC permissible range on first power-up; panel will display a startup screen within approximately 5 to 10 seconds if supply and connections are correct

What Engineers Get Wrong When Ordering the 6AV2123-2DB03-0AX0

Before submitting your RFQ or purchase order, work through this checklist verbatim. Each item addresses a real ordering error that results in a non-usable panel or a rework cost on the cabinet.

  1. Verify PROFINET is the correct fieldbus protocol; do not confuse with KTP400F (which includes Ethernet without PROFINET) or RS485 variants
  2. Check 24 V DC supply is available; this model does not accept 110/220 V AC single-phase
  3. Confirm mounting cutout space is 124 x 100 mm; physical envelope is 140 x 116 x 34.9 mm
  4. Verify WinCC Basic V13 or later is your engineering platform; older WinCC versions may have compatibility issues
  5. Check that maximum panel tilt angle of 35 degrees suits your installation orientation (portrait or landscape both supported)
  6. Confirm no SD card or external memory card is needed; KTP400 Basic has no SD card slot (use KTP700 if data logging to removable media is required)
  7. Verify USB interface is used only for offline updates; this is not a data acquisition device and supports USB only for engineering connection (up to 16 GB devices supported)
  8. Check that 10 MB user memory is sufficient for your application graphics and screen count (max 300 text lists, 100 entries each)

If any item on this list raises a flag for your project, contact the LeadTime.ca team to confirm the correct variant before ordering — or review the full product page for additional specification details.

Frequently Asked Questions

Can the Siemens 6AV2123-2DB03-0AX0 operate as a standalone controller without a PLC?

No. The KTP400 Basic does not support standalone operation. It must be connected to a PLC or communication module — typically a Siemens S7-1200 or S7-1500 — via its PROFINET interface to display process variables and accept operator inputs. Without a live PLC connection, the panel will display a no-project or communication error state.

What happens to the real-time clock if the panel loses power for an extended period?

The hardware real-time clock is backed by an internal battery that maintains timekeeping for approximately 6 weeks without external power. If the panel is offline longer than that, the clock will reset and will need to be manually resynchronized or configured to synchronize automatically via network time when PROFINET connectivity is restored.

Is the 6AV2123-2DB03-0AX0 compatible with non-Siemens PLCs?

The panel communicates via PROFINET, which is an open Industrial Ethernet standard. Compatibility with non-Siemens controllers depends on whether those controllers support PROFINET IO and whether WinCC Basic can create variable links to those devices. In practice, the KTP400 Basic is optimized for Siemens S7-1200 and S7-1500 ecosystems — integrators using non-Siemens PLCs should verify communication driver support in WinCC Basic V13 before committing to this panel.

What is the correct engineering software for programming the KTP400 Basic, and is a license required?

The panel is configured using WinCC Basic V13 or later, which is included within the STEP 7 TIA Portal Basic package. A valid TIA Portal license is required for project development and download. Siemens offers a trial version of WinCC Basic for offline screen design and simulation, which allows engineers to validate screen layouts before purchasing a full license or before hardware arrives on site.

Does the KTP400 Basic support data logging or recipe management to external storage?

The 6AV2123-2DB03-0AX0 has no SD card slot and does not support data logging to removable media. The 10 MB user flash memory is available for project data, text lists up to 300 entries of 100 items each, and screen graphics, but it is not designed for continuous data recording. If your application requires onboard data logging or recipe export to removable media, evaluate the KTP700 series instead.

What certifications does the 6AV2123-2DB03-0AX0 carry, and is it suitable for use in North America and Australia?

The panel carries CE, cULus, and RCM (formerly C-TICK) certifications, covering European, North American, and Australian regulatory requirements. The front face is rated NEMA Type 4 and 4x, which aligns with North American enclosure standards for industrial washdown and general shop floor environments. Always verify that your specific application and installation jurisdiction accept these certifications before finalizing the panel selection.

Why Order From LeadTime.ca

At-a-Glance Summary

  • Model: Siemens 6AV2123-2DB03-0AX0 — SIMATIC HMI KTP400 Basic Basic Panel
  • Display: 4-inch TFT widescreen, 480 x 272 pixels, 65536 colors, LED backlit, 20,000-hour backlight MTBF at 25°C
  • Input: Analog-resistive touch, 4 physical function keys, onscreen numeric and alphanumeric keyboard
  • Supply: 24 V DC rated; permissible range 19.2 to 28.8 V DC; 125 mA rated current; 3 W active power
  • Communication: 1 x PROFINET Industrial Ethernet interface; 1 x Mini USB Type-B (up to 16 GB device support)
  • Memory: 10 MB user flash; supports up to 300 text lists with 100 entries each
  • Mounting: 124 x 100 mm cutout; 140 x 116 mm front panel; 34.9 mm depth; 360 g without packaging
  • Environment: IP65 front, IP20 rear; NEMA Type 4/4x; 0 to 50°C operating (vertical); up to 35-degree tilt at 0 to 40°C
  • Real-time clock battery backup: approximately 6 weeks
  • Engineering platform: WinCC Basic V13 or later; STEP 7 TIA Portal
  • Certifications: CE, cULus, RCM
  • No SD card slot; no RS485/RS422/RS232; USB for engineering connection only
