Schneider Electric XENG1191 Harmony XAC spring-return front-mount 2NO-1NC contact block for K KX SK pendant operators

Schneider Electric XENG1191 Harmony XAC Pendant Station Contact Block, Spring Return, Front Mounting, 2-Speed Single Spring Return — Complete Specifications, Compatibility and Selection Guide

Controls engineers specifying pendant-based 2-speed motor soft-start circuits frequently reach this decision point: the Harmony XAC pendant is already in place, the operator type is confirmed, and the only remaining question is whether the XENG1191 contact block matches the control circuit topology. The Schneider Electric XENG1191 is a front-mount, spring-return contact block rated 10 A at 600 V AC delivering a 2NO-1NC contact configuration, designed exclusively for Type K, KX, and SK Harmony pushbutton operators at the 22 mm standard. Its 1,000,000-cycle mechanical durability and -25°C to +70°C operating range make it a reliable choice for both heavy industrial and outdoor pendant applications — provided the operator type and contact configuration are confirmed before the order is placed.

If you have already confirmed compatibility and are ready to order, check current pricing and availability for the XENG1191 at LeadTime.ca — ships worldwide.

Who Should Buy the XENG1191 — and Who Shouldn't

The XENG1191 is the right contact block if your application checks all of the following criteria:

  • Your control circuit requires exactly 2 normally open and 1 normally closed (slow-break) contacts — the 2NO-1NC configuration is fixed and cannot be field-reconfigured
  • Spring-return (momentary) action is required — this is not a maintained or latching block
  • Your control load falls within 10 A at 600 V AC maximum continuous rating
  • Your push button operator is confirmed as Type K, KX, or SK at 22 mm Harmony standard — no other operator type is mechanically compatible
  • Your project demands long service intervals — the 1,000,000-cycle rated durability reduces replacement frequency on high-cycle production lines
  • Wide temperature tolerance matters — operating range of -25°C to +70°C and storage to -40°C supports outdoor crane pendants, freezer environments, and unheated spare parts inventory

If your circuit requires a different contact arrangement, the XENG1190 (2NO), XENG1192 (2NC), or XENG1193 (1NO-1NC) are the correct alternatives. If maintained action is required, a different contact block family applies entirely.

On this page:

What the XENG1191 Does in a Pendant Control System

The XENG1191 is a modular contact block accessory — it does not function as a standalone device. It adds electrical switching capability to an existing Harmony XAC pendant station push button operator, converting a mechanical press action into two independent normally-open switching paths and one normally-closed slow-break contact. Without a contact block fitted, the push button operator itself has no electrical output.

The snap-fit front-mount attachment connects to the pushbutton operator body using a single-screw tightening mechanism, making the contact block field-replaceable without removing the pendant head or rewiring the enclosure. When the operator is pressed, the spring-return mechanism simultaneously closes both NO contacts and opens the NC contact. When released, the spring restores all three contacts to their initial state. The slow-break NC contact is specifically rated for control circuit applications where a deliberate, sequenced break is required — matching the typical 2-speed AC motor soft-start topology where the NC contact provides an interlocking hold on the secondary speed circuit.

The contact resistance across terminals is rated at 25 mΩ maximum, and the impulse withstand voltage is 6 kV per IEC 60947-1, providing measurable resilience against voltage transients generated by variable frequency drives, relay kickback, or lightning-induced surge on pendant control wiring.

Typical System Architecture for Pendant Motor Control

The XENG1191 sits at the operator interface layer of the control chain — between the Harmony pendant head and the motor starter or relay logic that controls the driven equipment. Here is where it fits in a typical 2-speed pendant control deployment:

  • Motor starter or VFD receives switching signals and controls the motor at speed 1 or speed 2
  • Control relay or PLC input card receives discrete contact signals from the pendant station
  • External 10 A Type gG cartridge fuse provides upstream short-circuit protection on the control circuit supply line (mandatory per IEC 60947-1)
  • Harmony XAC pendant head (XACA or XACA9) houses the Type K, KX, or SK pushbutton operator at 22 mm standard
  • XENG1191 contact block mounts to the front of the operator, delivering the 2NO-1NC contact outputs to the control wiring terminated at the screw clamp terminals

Industries and Applications Where the XENG1191 Fits

The most common deployment for the XENG1191 is 2-speed AC motor soft-start control via pendant station. The 2NO contact pair handles the forward and stop logic independently, while the NC contact provides the interlocking input that prevents simultaneous energization of both motor windings during speed transition. This circuit topology appears consistently in manufacturing lines where operators control conveyor speed, press cycle rate, or pump output from a mobile pendant.

Dual-output pendant control is another well-matched application — one NO contact triggers a hydraulic clamp, the second NO contact triggers an eject cylinder, and the NC contact provides a safety interlock that disables an upstream circuit when the button is held. A single push button with XENG1191 replaces what would otherwise require two separate push buttons and additional wiring runs.

Maintenance and guard station pendants represent a growing application. Facilities that run mobile maintenance pendants during equipment service or troubleshooting benefit from the modular design: a worn contact block can be swapped in the field without returning the pendant to a service center. The 1,000,000-cycle rating supports long intervals between replacements even at moderate-frequency use.

Outdoor and environmentally demanding installations — crane and hoist pendants, marine deck control stations, construction equipment — benefit from the -25°C to +70°C operating range and -40°C storage temperature, which accommodates unheated spare parts storage in cold climate facilities.

Application Typical Deployment
2-speed AC motor soft-start Pendant station on manufacturing conveyor or pump system; XENG1191 provides NO contacts for speed 1/speed 2 and NC interlock
Dual-output hydraulic control Single push button controls clamp and eject circuits independently via 2NO outputs; NC disables upstream circuit on button hold
Mobile maintenance pendant Field-replaceable contact block on Harmony XACA pendant; technician swaps worn block without pendant head removal
Crane and hoist pendant Outdoor pendant duty in -25°C environments; wide temperature range and 1M cycle rating supports high-frequency hoist commands
Guard station control Safety interlock pendant at machine guard; NC contact provides hold-to-run interlock in safety-rated control circuit
Redundant motor start circuit Two XENG1191 blocks configured in parallel on critical motor start-up circuit for hot-standby control redundancy

Purchase-Decision Specifications and Variant Comparison

Parameter Value Notes
Contact Configuration 2NO-1NC (slow-break) Fixed — cannot be field-reconfigured
Contact Rating (AC Resistive) 10 A at 600 V AC Maximum continuous; control circuit only
Contact Rating (DC) 0.27 A at 250 V DC Per manufacturer datasheet
Impulse Withstand Voltage 6 kV (IEC 60947-1) Transient protection on pendant wiring
Short-Circuit Protection 10 A cartridge fuse, type gG External — required by IEC 60947-1
Mechanical Durability 1,000,000 cycles Tested per IEC 60947-5-1
Operating Temperature -25°C to +70°C Standard industrial and outdoor range
Storage Temperature -40°C to +70°C Supports cold climate spare parts storage
Terminal Capacity (without glands) 1 × 0.5 to 1 × 2.5 mm² Screw clamp; verify cable gauge before ordering
Compatible Operators Type K, KX, SK — 22 mm Harmony standard only XACA and XACA9 heads confirmed compatible

Full technical specifications are available on the product page at LeadTime.ca.

Model Contact Configuration Contact Rating Operator Action
XENG1190 2NO 10 A @ 600 V AC Spring return
XENG1191 2NO-1NC 10 A @ 600 V AC Spring return (this model)
XENG1192 2NC 10 A @ 600 V AC Spring return
XENG1193 1NO-1NC 10 A @ 600 V AC Spring return
Maintained variants Varies Varies Maintained/latching

All XENG variants mount to Type K, KX, and SK 22 mm pushbuttons. Choose the configuration that matches your control circuit design — never order based on availability alone. If your circuit requires both an interlock NC contact and two independent NO switching paths, only the XENG1191 covers that requirement within this spring-return family. Check current XENG1191 availability at LeadTime.ca — or contact the team if you need help confirming which variant fits your schematic.

Expert Verdict: When to Order and When to Choose a Different Block

The XENG1191 earns its place as the default contact block specification for 2-speed pendant control in manufacturing, material handling, and food and beverage environments — not because it is the most feature-rich option available, but because its 2NO-1NC configuration precisely matches the most common pendant-based motor control topology without requiring additional relay logic to compensate for a missing contact. The 1,000,000-cycle mechanical durability tested per IEC 60947-5-1 means that for maintenance pendants or low-cycle applications, a single block will outlast the equipment it controls. For controls engineers and integrators working within existing Harmony XAC infrastructure, the snap-fit modular design delivers fast field replacement and low downtime risk — measurable advantages when a production line pendant fails mid-shift.

The limits are equally clear. If your application calls for maintained contact action — a latching button that holds a circuit energized without continuous operator pressure — the XENG1191 is the wrong part regardless of its contact rating. If your load exceeds 10 A at 600 V AC, this contact block does not cover the rating and a separate product family applies. Buyers whose push button operators are not confirmed as Type K, KX, or SK at 22 mm should not order this block until the operator type is physically verified — the XENG1191 will not mechanically fit Type L, K1, or K2 operators or any non-Harmony platform. In those cases, the XENG1190, XENG1192, or XENG1193 may cover the contact configuration need if the operator type is compatible, but cross-platform sourcing requires a different product family entirely.

From a procurement standpoint, the XENG1191 is a generally available part across major industrial distribution channels with typical lead times of one to five business days from stock. The risk in procurement is not availability — it is specification error. Ordering the wrong XENG variant or ordering for an incompatible operator type creates a return, a reorder delay, and a project slip that a brief compatibility check prevents entirely. Buying through a specialist industrial distributor gives you access to a technical team that can cross-reference your existing pendant model number and confirm the correct contact block before the order ships. View current XENG1191 pricing and stock status at LeadTime.ca — we ship worldwide and can confirm compatibility before your order is placed.

For volume pricing or to confirm lead time before committing to a build schedule, contact the LeadTime.ca team directly — we ship worldwide and can source across multiple stocking locations.

What Engineers Need to Know Before Ordering the XENG1191

The XENG1191 sits in a product category where public forum discussion is essentially absent — no threads on r/PLC, r/automation, PLCTalk, PLCS.net, MrPLC, or manufacturer forums have surfaced for this model or the broader XENG family. That silence is not a red flag; modular contact blocks are workhorse components that go in, do their job for years, and are replaced without drama. Engineers who know the Harmony platform order them without hesitation. The challenge arises for buyers who are new to the Harmony XAC ecosystem or who are specifying pendant control for the first time and do not yet have an intuition for where the compatibility boundaries sit.

In the absence of community-sourced field data, the most actionable intelligence comes from the specification and procurement patterns that experienced distributor teams observe repeatedly. The dominant pre-order failure mode is contact configuration mismatch — specifically, buyers who know they need a 2-speed contact block but order the XENG1190 (2NO only) because it appears first in a catalog search, then discover on installation that their circuit schematic requires the NC interlock contact that only the XENG1191 provides. The second most common issue is operator type confusion: the XENG1191 is not compatible with Type L, K1, or K2 pushbutton operators, and buyers with older or mixed-vintage Harmony pendants sometimes assume compatibility across the entire Harmony family. Physical measurement of the push button body diameter (must be 22 mm) and visual confirmation of the type label resolves this before any money changes hands.

A third consideration that does not appear in catalog listings but matters at installation: the XENG1191 requires external short-circuit protection upstream — a 10 A Type gG cartridge fuse or equivalent circuit breaker is mandated by IEC 60947-1. The contact block carries no internal overcurrent protection. Panel builders who omit this step are creating a code non-compliance issue that may not surface until an inspection or an actual fault event. When sourcing through a specialist distributor, these installation realities are part of the conversation — not an afterthought discovered during commissioning.

Wiring and Installation Overview

  • Verify the push button operator is de-energized and confirmed as Type K, KX, or SK before attempting contact block installation — XENG1191 uses a snap-fit front-mount attachment with single-screw tightening that is mechanically specific to 22 mm Harmony operators
  • Strip wire insulation to match screw clamp terminal depth; terminal capacity without cable glands accepts 1 × 0.5 to 1 × 2.5 mm², with cable glands the range is 1 × 0.5 to 2 × 1.5 mm² — do not exceed the rated capacity
  • Consult the manufacturer wiring diagram for NO and NC terminal assignments before connecting; the slow-break NC contact has a specific terminal position that differs from the NO pair
  • Install a 10 A Type gG cartridge fuse upstream in the control circuit supply line — this is a mandatory external protection requirement per IEC 60947-1 and is not built into the contact block
  • After installation, verify spring-return function: press the operator and confirm both NO contacts close and the NC contact opens; release and confirm full spring restoration before energizing the circuit

Wrong-Part Prevention Checklist

Before submitting a purchase order for the XENG1191, work through each item below. This checklist covers the eight verification points that prevent the most common specification and installation errors with this contact block.

  1. Verify push button operator is Type K, KX, or SK model — XENG1191 is not compatible with other Harmony head models
  2. Confirm 2NO-1NC contact configuration matches circuit design (not 2NO or 2NC variants)
  3. Check that 10 A at 600 V AC rating is sufficient for control load — do not use for main circuit switching
  4. Verify push button is 22 mm size (Harmony standard) — contact block mounts only to standard Harmony head
  5. Confirm spring-return action is required (not latching/maintained operation)
  6. Check that front mounting (not top/side mounting) fits panel layout
  7. Verify screw clamp terminal capacity: 1 x 0.5–1 x 2.5 mm² without cable glands, or 1 x 0.5–2 x 1.5 mm² with glands
  8. Confirm UL 508, EN/IEC 60947-5-1, and RoHS compliance meet project requirements

If any item on this checklist raises a question about your specific installation, contact the LeadTime.ca technical team before ordering — we can cross-reference your pendant model and confirm the correct contact block variant before the order ships worldwide.

Frequently Asked Questions

Can I install the XENG1191 on any Harmony push button, or only specific operator types?

Only Type K, KX, and SK operators at 22 mm Harmony standard are mechanically compatible with the XENG1191. Older Type L, K1, and K2 operators use a different snap-fit geometry and will not accept the XENG1191 contact block. Confirm your operator type label and measure the push button body diameter before ordering — 22 mm is the required standard.

My control circuit schematic calls for 2NO-1NC — is there any risk the XENG1191 NC contact is not slow-break?

The NC contact in the XENG1191 is specifically rated as slow-break operation, which is the correct behavior for control circuit interlocking in 2-speed motor applications. Slow-break means the contact opens with a deliberate, controlled separation rather than a snap action — this characteristic is confirmed by the EN/IEC 60947-5-1 compliance marking. If your schematic requires a snap-action NC contact for a different control function, consult the manufacturer's contact block catalog for the appropriate alternative.

Does the XENG1191 include its own overcurrent or short-circuit protection?

No — the XENG1191 carries no internal overcurrent protection. IEC 60947-1 requires external short-circuit protection on the control circuit, specified as a 10 A Type gG cartridge fuse upstream of the contact block. The contact block is rated 10 A at 600 V AC maximum continuous; the external fuse protects against fault currents that exceed this rating. Omitting the upstream fuse creates a code non-compliance condition and a real fault risk.

Is the XENG1191 a direct mechanical swap for an existing worn contact block on an older Harmony pendant?

If the existing pendant uses a Type K, KX, or SK operator at 22 mm standard and the original contact block is a spring-return 2NO-1NC configuration, the XENG1191 is a direct snap-fit replacement. If the original block is a different XENG variant (2NO, 2NC, or 1NO-1NC), the XENG1191 will physically fit but the contact configuration will not match the original circuit — verify the schematic before replacement. If the pendant is older and uses Type K1 or K2 operators, the XENG1191 will not fit without an operator upgrade.

What do I do if the spring-return function feels stiff or the contacts do not restore fully after installation?

A stiff or incomplete spring return after snap-fit installation typically indicates the contact block is not fully seated in the operator cavity. Remove the block, inspect the snap-fit tabs for damage, reseat firmly, and tighten the single securing screw. If the spring-return issue persists after correct installation, the contact block should be replaced — do not continue operating a pendant where the spring function is compromised, as a stuck NO contact will leave a motor circuit energized without operator input.

Can two XENG1191 blocks be stacked or paralleled on a single push button for redundancy?

The XENG1191 is designed as a single front-mount contact block per operator. Stacking multiple contact blocks on a single Harmony operator is not confirmed as a supported configuration in the available manufacturer documentation for this model. For redundant control circuit requirements, consult the full Harmony XAC accessories catalog or contact a technical specialist to identify the correct multi-block or series architecture for your application.

Why Order the XENG1191 from LeadTime.ca

  • Ships worldwide — no geographic restriction on orders; international buyers can confirm lead time and freight options directly with the team
  • Technical pre-order support — the LeadTime team can cross-reference your existing Harmony pendant model and confirm correct contact block variant before shipment, preventing costly specification errors
  • Access to hard-to-find industrial parts — specialist sourcing capability for Harmony XAC accessories that may not be stocked by general electronics retailers
  • Volume pricing available — contact for current pricing on multi-unit orders for panel builders and systems integrators

XENG1191 At-a-Glance Summary

  • Contact configuration: 2NO-1NC with slow-break NC — fixed, not field-adjustable
  • Contact rating: 10 A at 600 V AC maximum continuous; 0.27 A at 250 V DC
  • Impulse withstand: 6 kV per IEC 60947-1 — supports use near VFDs and relay switching
  • Mechanical durability: 1,000,000 cycles tested per IEC 60947-5-1
  • Operating temperature: -25°C to +70°C; storage to -40°C
  • Compatible operators: Type K, KX, SK at 22 mm Harmony standard only — XACA and XACA9 heads confirmed
  • Terminal capacity: 1 × 0.5 to 1 × 2.5 mm² without glands; 1 × 0.5 to 2 × 1.5 mm² with glands
  • External protection required: 10 A Type gG cartridge fuse upstream per IEC 60947-1
  • Standards compliance: EN/IEC 60947-5-1, UL 508, RoHS, CE marked
  • Spring-return action only — maintained/latching variants are separate models within the XENG family
  • Closest variants: XENG1190 (2NO), XENG1192 (2NC), XENG1193 (1NO-1NC) — all spring return, same operator compatibility
