Schneider Electric TM241CE24T Logic Controller: Specs, Pricing, Comparison, and Buying Guide

Controls engineers and OEM machine builders searching for the Schneider Electric TM241CE24T are typically at one of two decision points: confirming whether this compact Modicon M241 logic controller covers their I/O count and motion control requirements, or validating whether the embedded CANopen fieldbus eliminates the need for additional communication modules. This article answers both questions with specifics drawn directly from manufacturer documentation — 24 I/O points, 24V DC supply, transistor PNP outputs, integrated Ethernet, and on-board CANopen for up to 63 networked devices, all in a 150 x 95 x 90 mm DIN-rail form factor weighing 0.53 kg.

If you have already confirmed this is the correct part for your application, check current pricing and availability for the TM241CE24T at LeadTime.ca — ships worldwide.

Who Should Specify the TM241CE24T — and Who Should Not

The TM241CE24T is the right controller for applications where 24V DC power is available, digital I/O is sufficient, and motion control plus embedded fieldbus are baseline requirements rather than optional upgrades. Specify this model when your project meets all of the following criteria:

  • Supply voltage is 24V DC — no 120V or 230V AC power availability on this model
  • I/O demand fits within 14 discrete inputs, 8 rapid inputs, 10 transistor outputs, and 4 fast outputs (22 total inputs, 14 total outputs)
  • All output loads are compatible with PNP (source logic) — NPN and relay outputs are not available on this model
  • Ethernet connectivity is a requirement, with or without CANopen fieldbus coordination across up to 63 devices
  • Program and data storage requirements are within 8 MB program memory, 64 MB RAM, 128 MB flash, and 16 GB SD card capacity
  • DIN rail mounting on a 35 mm rail fits your enclosure layout

If your application requires analog I/O, NPN outputs, or more than 22 inputs or 14 outputs, select a different variant within the Modicon M241 family before placing an order. The wrong-part checklist later in this article covers the full verification sequence.

On this page:

What the TM241CE24T Does in a Control System

The TM241CE24T is the central logic processor in a compact machine control system. It handles discrete sequencing, speed and position motion control, data acquisition, and fieldbus coordination from a single base unit — without requiring separate motion control cards or external fieldbus modules. Schneider Electric's official product documentation describes the Modicon M241 series as designed for high-performance compact machines incorporating speed and position control functions, and the TM241CE24T is the 24 I/O variant of that platform.

In practice, this controller sits between the operator interface or supervisory system above it and the sensors, drives, and actuators below. The 8 rapid inputs handle high-speed encoder or proximity signals that standard discrete inputs would miss. The 4 fast outputs drive time-critical loads such as servo drives or high-speed solenoid valves. The 10 transistor outputs handle standard loads — conveyors, pumps, indicator lights, relay coils — at up to 0.5 A per point. The embedded CANopen port expands the I/O universe without additional hardware, supporting up to 63 networked devices on a single controller.

Memory headroom is generous for the footprint: 8 MB of program memory, 64 MB of system RAM for runtime execution, 128 MB of flash for non-volatile backup, and a 16 GB SD card slot for program transfer, data logging, and firmware updates. For an OEM machine builder or retrofit integrator, this means the controller is unlikely to become a bottleneck on application complexity within its I/O class.

Typical System Architecture for the TM241CE24T

The TM241CE24T occupies the controller tier between a supervisory system or HMI and the field devices it commands. A typical deployment chain looks like this:

  • SCADA system or HMI communicates with the TM241CE24T over Ethernet (RJ45) for data acquisition, alarm management, and operator input
  • TM241CE24T executes the machine program, managing sequencing, motion control, and fieldbus coordination from a single DIN-rail-mounted unit
  • Up to 63 CANopen devices — I/O modules, drives, sensors — connect to the on-board CANopen port without external gateways
  • Discrete inputs (14 standard, 8 rapid) receive signals from proximity sensors, encoders, limit switches, and safety contacts
  • Transistor and fast PNP outputs drive motor contactors, solenoid valves, servo drives, and status indicators at the machine level

Typical Applications and Deployment Scenarios

Packaging machinery is the highest-frequency application for the TM241CE24T. Position-based product handling on form-fill-seal lines and horizontal wrappers maps directly to the built-in motion control functions. The compact footprint fits inside the machine enclosure without requiring a separate control cabinet, and the 24V DC supply is standard in packaging OEM designs.

Conveyor systems with synchronized speed control are a natural fit. The rapid inputs handle encoder feedback for speed regulation, the fast outputs drive variable-frequency drives, and the CANopen fieldbus connects distributed I/O modules along the conveyor line without discrete wiring runs back to the panel.

Retrofit applications are a significant use case. When an aging compact PLC reaches end-of-life and the machine wiring is already 24V DC digital, the TM241CE24T provides a migration path that preserves the field wiring and control cabinet while replacing the logic platform. The EcoStruxure Machine Expert software supports program import workflows that reduce rewrite time.

Food and beverage production environments benefit from the marine and industrial certifications — LR, ABS, DNV, GL, CE, UL 508, and CSA — and the IP20 rating with screw-terminal and RJ45 connections that tolerate washdown-adjacent environments. The DIN rail mount allows fast swap-out during maintenance windows.

Application Typical Deployment
Packaging machinery (form-fill-seal, wrappers) Single TM241CE24T as machine controller; fast outputs to servo drives; CANopen to distributed I/O
Conveyor speed synchronization Rapid inputs from encoders; transistor outputs to VFDs; CANopen to belt section I/O modules
Multi-head labeling or filling machine Position control via fast outputs; CANopen coordinates head-by-head I/O; Ethernet reports to SCADA
OEM retrofit (aging PLC replacement) Drop-in DIN rail replacement; field wiring reused; EcoStruxure Machine Expert for program migration
Food and beverage production line DIN rail in wash-adjacent panel; marine-certified for harsh environments; CANopen to distributed sensors
Small assembly or test equipment Compact enclosure controller; USB mini-B for on-site programming; SD card for program backup and transfer

Purchase-Decision Specifications at a Glance

Parameter Value Notes
Supply Voltage 24V DC External supply required; no AC input option
Total Inputs 22 (14 discrete + 8 rapid) Rapid inputs handle high-speed encoder/proximity signals
Total Outputs 14 (10 transistor + 4 fast) All PNP source logic; NPN not available on this model
Transistor Output Current 0.5 A per point PNP; 10 points total
Fast Output Current 0.1 A per point PNP; 4 points total
Program Memory 8 MB User program storage
System RAM / Flash / SD 64 MB / 128 MB / 16 GB Runtime, backup, external storage
Fieldbus CANopen (up to 63 devices) Embedded; no external module required
Connectivity Ports Ethernet RJ45, USB mini-B, Serial RJ45, Serial screw terminal RS232/RS485 on serial ports
Dimensions / Weight 150 x 95 x 90 mm / 0.53 kg 35 mm DIN rail mount, horizontal orientation

Full technical specifications are available on the product page at LeadTime.ca.

TM241CE24T vs. Other M241 Variants and Competing Controllers

Within the Modicon M241 family, the TM241CE24T occupies the 24 I/O position with digital-only I/O. If the I/O count is too small or analog capability is needed, the correct move is to a higher-count M241 SKU or an analog-capable M241 variant — not to a different platform. The table below covers both in-family options and the most commonly evaluated competing controllers.

Model I/O Count Supply Voltage Fieldbus Motion Control Key Difference vs. TM241CE24T
TM241CE24T (this model) 22 in / 14 out 24V DC CANopen (63 devices), Ethernet Built-in speed + position Reference model
M241 — 16 I/O variant Smaller I/O count 24V DC CANopen, Ethernet Built-in Fewer I/O points; choose when count is sufficient
M241 — 32 I/O variant Larger I/O count 24V DC CANopen, Ethernet Built-in More I/O points; choose when 22 inputs or 14 outputs are insufficient
M241 — Analog I/O variant 24 I/O + analog 24V DC CANopen, Ethernet Built-in Adds analog input/output capability; required for sensor calibration or variable speed without CANopen drive
Siemens S7-1200 16–24 24V DC PROFINET, CANopen CPU-built-in Wider software ecosystem and more I/O variant depth; typically higher cost
Rockwell CompactLogix 16–32 24V DC EtherNet/IP Add-on module Stronger North American OEM channel support; higher cost entry point
Beckhoff CX9020 Modular (Ethernet-based) 24V DC EtherCAT, CANopen Yes (modular) Industrial PC capability with TwinCAT engineering; higher cost

If your application requires more than 14 outputs or analog process signals, the correct path is an M241 analog variant or a larger I/O SKU — contact LeadTime.ca to confirm the right part number before ordering.

Expert Verdict: Is the TM241CE24T the Right Controller for Your Project?

The TM241CE24T is the correct choice for OEM machine builders and retrofit integrators who need integrated motion control and embedded CANopen fieldbus in a compact, cost-effective controller — without stacking additional modules to achieve those capabilities. The combination of 14 discrete inputs, 8 rapid inputs, 10 transistor outputs, and 4 fast outputs covers the majority of small to mid-range machine automation applications. At 150 x 95 x 90 mm and 0.53 kg, it fits in space-constrained control panels that would not accommodate a modular rack-based system. Packaging machinery integrators, conveyor builders, and multi-head filling machine OEMs represent the most direct match for this controller's capability profile. The marine certifications — LR, ABS, DNV, GL — extend that fit to offshore and harsh environment installations without requiring upgraded enclosures.

Where this model reaches its real limits is on analog I/O, output logic type, and raw I/O count. The TM241CE24T is strictly digital and strictly PNP. There is no relay output option, no NPN variant, and no integrated analog channel. If your application includes temperature sensing via analog thermocouple modules, pressure transducer feedback, or any NPN-logic field device, this model is not the right controller — and ordering it in error costs time, not just money. Facilities standardized on Siemens TIA Portal or Rockwell Studio 5000 face significant software retraining costs that often outweigh any hardware savings, making the S7-1200 or CompactLogix the more practical choice in those environments despite the higher unit cost.

From a procurement standpoint, the TM241CE24T is a stable, normally stocked part through authorized distributors worldwide, with typical lead times of one to two days across North America. That said, for time-sensitive projects, verifying available inventory before committing to a build schedule is always the right move. Buying through a specialist industrial distributor rather than a generic online channel matters here: pre-sales verification of the output logic type, confirmation that the CANopen device count fits your topology, and technical consultation on EcoStruxure Machine Expert setup are services that prevent the costly ordering mistakes documented in this article. Review current pricing and availability for the TM241CE24T at LeadTime.ca — and if your application sits at the edge of this model's capability, reach out before the order goes in.

For volume pricing or to confirm lead time before committing to a build, contact the LeadTime.ca team directly — we ship worldwide.

What Engineers Need to Know Before Ordering the TM241CE24T

Community forum data for the TM241CE24T specifically is sparse — this is a model that does not generate frequent public troubleshooting threads, which typically reflects either broad reliability or a relatively contained user base that resolves issues through direct distributor or manufacturer support channels. In the absence of crowdsourced field experience, the most useful pre-order intelligence comes from the three ordering mistakes that appear repeatedly in field experience with this class of controller, and from the specifications that trip up engineers who are moving from a different platform or upgrading from an older Schneider compact PLC.

The single most common avoidable mistake with the TM241CE24T is output logic type mismatch. The controller is PNP-only across all 14 output points — both the 10 transistor outputs and the 4 fast outputs source from 24V. If your wiring design or your connected devices expect NPN (sinking to common ground), the outputs will not energize the loads correctly regardless of how the program is written. This is not a firmware issue or a configuration option — it is a hardware characteristic of this specific model. Engineers moving from platforms that offer both PNP and NPN variants on the same SKU family sometimes assume the same flexibility exists here. It does not. Verify your wiring diagram against PNP source logic before the order is placed, not after delivery.

The second area that requires explicit pre-order verification is power supply sizing. The controller itself draws approximately 0.5 A at 24V DC, but that figure covers the controller core only. With 10 transistor outputs at 0.5 A per point and 4 fast outputs at 0.1 A per point, simultaneous full-load activation demands significantly more current from the external supply. External protection — a fused disconnect or circuit breaker — is also required, as the TM241CE24T has no integrated circuit protection. The third issue involves the CANopen device limit of 63 nodes: networks designed with more devices than this limit will fault during commissioning, not during design, making this a specification that must be confirmed against the fieldbus architecture before hardware is ordered. LeadTime.ca's technical team can help validate all three of these parameters before your purchase order is confirmed.

Wiring and Installation Overview

The TM241CE24T mounts horizontally on a standard 35 mm DIN rail. Installation and wiring involves the following key requirements and verifications:

  • External 24V DC power supply connected to the screw-terminal power block; supply must be sized for controller core current plus all simultaneous output loads — no integrated circuit protection is present, so an external fused disconnect or circuit breaker is required
  • Ethernet connectivity via RJ45 port; IP address assignment and CANopen device addressing configured through EcoStruxure Machine Expert software (USB mini-B or Ethernet connection to programming laptop required)
  • Serial Port 1 uses an RJ45 connector for RS232/RS485 communications; Serial Port 2 uses screw terminals for RS485 and is non-isolated — external isolation should be considered when connecting to remote or external systems
  • All output wiring must be verified against PNP source logic before connection; devices expecting NPN signals will not operate correctly and the output type cannot be changed in firmware
  • Firmware updates and program transfer are supported via the 16 GB SD card slot or over Ethernet; SD card use for initial program load is a practical option for commissioning multiple identical machines

For full wiring diagrams, terminal torque specifications, and step-by-step commissioning procedures, refer to the official Schneider Electric installation guide and EcoStruxure Machine Expert documentation available from the manufacturer.

Wrong-Part Prevention Checklist

Before placing your order for the TM241CE24T, verify each of the following items against your project documentation and wiring design:

  1. Confirm supply voltage is 24V DC in your installation (no 120V or 230V AC versions available)
  2. Verify I/O count is sufficient: 14 discrete inputs, 8 rapid inputs, 10 transistor outputs, 4 fast outputs total
  3. Check output type: all outputs are transistor PNP — if NPN or relay outputs required, select a different model
  4. Confirm connector types match your panel layout (RJ45 for Ethernet, mini-B USB, RJ45 and screw terminals for serial)
  5. Verify motion control functions (speed, position) are required for your application
  6. Check that embedded CANopen (up to 63 devices) addresses your fieldbus topology need
  7. Confirm DIN rail mounting is compatible with your panel

If any item on this checklist cannot be confirmed, contact the LeadTime.ca team before ordering — our technical team can cross-reference the correct M241 variant or recommend an alternative controller that fits your verified requirements.

Frequently Asked Questions

Does the TM241CE24T have built-in motion control, or does it require a separate motion module?

Motion control for speed and position functions is built into the Modicon M241 platform — no separate motion module is required on the TM241CE24T. Schneider Electric's official documentation confirms the M241 series is designed for machines incorporating speed and position control functions as native controller capability. Function blocks for motion control are available within EcoStruxure Machine Expert.

Can I connect more than 63 devices to the CANopen fieldbus on a single TM241CE24T?

No. The embedded CANopen port supports a maximum of 63 networked devices. Attempting to commission more than 63 nodes on a single controller will result in devices beyond that limit failing to respond. If your fieldbus topology requires more than 63 devices, the correct approach is to partition the network across two or more TM241CE24T controllers, or to implement fieldbus segmentation through switches or gateways. Document your CANopen node address map before ordering hardware.

What size external 24V DC power supply do I need for the TM241CE24T with all outputs loaded?

The controller core draws approximately 0.5 A at 24V DC. Adding full simultaneous output load — 10 transistor outputs at 0.5 A each and 4 fast outputs at 0.1 A each — results in a total combined output current of 5.4 A. Including the controller core, the minimum supply capacity required for full simultaneous output loading is approximately 5.9 A. Select a supply rated at 8 to 10 A to maintain a safety margin and accommodate inrush current. External fused protection is required; the TM241CE24T has no integrated circuit breaker.

Is there an NPN output version of the TM241CE24T?

No. All 14 output points on the TM241CE24T are transistor PNP (source logic). There is no NPN output variant of this specific model. If your application requires NPN (sink logic) outputs, you must select a different model within the Modicon M241 family or from an alternate product line. This is the most common ordering mistake associated with this controller — confirm output logic type against your wiring design before placing the order.

Can the TM241CE24T accept analog inputs or outputs, or is it digital-only?

The TM241CE24T is digital-only. All 22 inputs and all 14 outputs are discrete digital signals. There are no integrated analog input or output channels on this model. If your application requires analog signal processing — for example, a 4–20 mA pressure transducer or a 0–10V speed reference — you must select an analog-capable M241 variant or add an analog expansion module via CANopen. Verify this constraint against your sensor and actuator list before specifying this controller.

What software is required to program the TM241CE24T, and what programming languages are supported?

Programming is performed using EcoStruxure Machine Expert software from Schneider Electric. The TM241CE24T connects to the programming laptop via USB mini-B or Ethernet. The platform supports IEC 61131-2007 compliant programming languages, which includes Ladder Diagram, Structured Text, Function Block Diagram, Instruction List, and Sequential Function Chart. Firmware updates can be applied via SD card or over Ethernet.

Why Order Through LeadTime.ca

  • Global shipping — the TM241CE24T and compatible Modicon M241 accessories ship worldwide from LeadTime.ca, not just within a single region
  • Pre-sales technical verification — output logic type, I/O count, and fieldbus architecture questions answered before the order is placed, not after delivery
  • Hard-to-find and time-sensitive parts — specialist sourcing for industrial automation components with current stock visibility and lead time confirmation
  • Volume pricing — contact for project quantity pricing on M241 controllers and accessories for OEM panel builders and integrators
  • Procurement support — part number cross-reference, alternative model identification, and order documentation for engineering approval workflows

At-a-Glance Summary

  • Official product name: Logic controller, Modicon M241, 24 IO, transistor, PNP, Ethernet
  • Supply voltage: 24V DC external supply required — no AC input option exists on this model
  • Total I/O: 22 inputs (14 discrete + 8 rapid) and 14 outputs (10 transistor PNP at 0.5 A + 4 fast PNP at 0.1 A)
  • Output logic: PNP source logic only — NPN and relay output types are not available on TM241CE24T
  • Memory: 8 MB program, 64 MB RAM, 128 MB flash, 16 GB SD card slot
  • Fieldbus: Embedded CANopen for up to 63 networked devices — no external fieldbus module required
  • Motion control: Speed and position control built in — no separate motion module required
  • Form factor: 150 x 95 x 90 mm, 0.53 kg, 35 mm DIN rail mount
  • Certifications: CE, UL 508, UL 1604, CSA, CULus, RCM, marine (LR, ABS, DNV, GL), ANSI/ISA 12-12-01, EN/IEC 61131-2007
  • Programming software: EcoStruxure Machine Expert via USB mini-B or Ethernet
  • Availability: Normally in stock at authorized distributors worldwide; typical lead time 1–2 days
