Schneider Electric LADN40 — 4NO Auxiliary Contact Block Review

By Abdullah Zahid
14 min read
Schneider Electric LADN40 TeSys Deca 4NO auxiliary contact block front clip-on mount for LC1D contactor panel installation

Schneider Electric LADN40 TeSys Deca Auxiliary Contact Block, 4 NO, Top Mount, Screw Clamp Terminals — Specs, Price and Compatibility Guide

When a controls engineer or panel builder searches for the Schneider LADN40 by model number, the decision is usually already narrowed down to one question: does this part fit my contactor and does it give me the four normally open contacts I need? The LADN40 is a front-mount auxiliary contact block that snaps directly onto TeSys D and TeSys Deca LC1D contactors from frame size 09 through 150, delivering four independent normally open circuits rated at 10A and 690V AC without adding external relay hardware to the panel. If you are already in the Schneider TeSys platform and need exactly four NO contacts, this is the component — but the compatibility check before ordering is not optional.

If you have already confirmed this is the right part, check current pricing and availability at LeadTime.ca — ships worldwide.

Who Should Buy the LADN40 — and Who Should Not

The LADN40 is the correct choice for panel builders and control systems engineers deploying or expanding TeSys D or TeSys Deca contactor assemblies. It is right for your application if all of the following are true:

  • Your contactor is an LC1D or LP1D model within the 09 to 150 frame size range — or a CAD32 to CAD50 control relay
  • You need exactly four normally open contacts — no normally closed or mixed-contact logic is required
  • Each auxiliary circuit load does not exceed 10A at 690V AC continuous
  • Your installation environment stays within -5 to +60°C ambient operating range
  • Front clip-on mounting with screw clamp terminals fits your panel layout and wiring practice
  • Only one auxiliary contact block is required per contactor — the LADN40 is a single-block-per-contactor design

If you need normally closed contacts, a mixed NO/NC configuration, or only two auxiliary circuits, the LADN40 is the wrong variant. For those requirements, the LADC22 (2 NO + 2 NC), LADC41 (4 NC), or LADN11 (2 NO) are the correct selections within the same LAD family.

On this page:

What the LADN40 Actually Does in a Control System

An auxiliary contact block extends the switching capacity of a contactor beyond its main poles without requiring external relay hardware. The Schneider Electric LADN40 clips directly to the front face of an LC1D or LP1D contactor and adds four independent normally open circuits, each rated at 10A and 690V AC, that open and close in sync with the contactor coil. Those four contacts can drive pilot lamps, PLC input cards, interlock relay coils, audible signals, or secondary equipment in coordinated startup sequences — all from a single snap-on block that adds no significant footprint to the control panel.

The 30 million electrical cycle mechanical durability rating means the LADN40 is built to survive the same service life as the contactor it mounts to, including demanding duty cycles up to 3600 cycles per hour. The screw clamp terminals are finger-safe and IP20 rated, which matters in panels where multiple tradesperson access is expected. Because the block integrates into the TeSys platform rather than sitting alongside it, the installation is cleaner and the wiring shorter than adding discrete relay modules to achieve the same result.

UL listing (File E164862), CSA listing (File LR43364, Class 3211), CE marking, and RoHS compliance are all confirmed on the LADN40, which means the same part number clears compliance review for projects in North America and Europe without substitution. The IEC 60947-5-1 rating with short-circuit protection via a gG fuse at 10A and insulation resistance greater than 10 MΩ at 500V DC gives system designers the data they need to complete protection coordination without guesswork.

Where the LADN40 Sits in a Typical Control Panel Architecture

The LADN40 occupies the auxiliary switching layer between the main contactor and the downstream control or monitoring devices. It receives its mechanical actuation directly from the LC1D contactor body and passes contact state to external circuits.

  • PLC or control relay coil output energizes the LC1D contactor coil
  • LC1D main contacts switch the motor or load circuit
  • LADN40 block, mounted at the front of the LC1D, closes all four NO contacts simultaneously with the main contactor
  • Each LADN40 contact independently feeds a downstream device — PLC digital input, pilot lamp, interlock relay coil, or sequential start relay
  • All four circuits remain isolated from each other and from the main power circuit, allowing mixed-voltage signaling on a single block

Typical Applications and Deployment Scenarios

In multi-motor production lines, the LADN40 provides the running or stopped status contacts that feed PLC input cards for remote monitoring without any additional relay hardware in the panel. A single LC1D contactor with an LADN40 attached can simultaneously indicate status to the HMI, enable a downstream conveyor interlock, trigger a pilot lamp, and feed a data acquisition system — four independent circuits, one snap-on block.

HVAC control panels for air handling units and chiller systems regularly use the LADN40 to tie fan contactor status into building automation system inputs. The 10A rating at 690V AC is more than adequate for the low-current signaling loads typical in BAS wiring, and the -5 to +60°C operating range accommodates mechanical room environments without derating.

In pump stations and compressed air systems, the LADN40 auxiliary contacts drive secondary pump or compressor start logic through timing relays or PLC sequencing programs, coordinating staggered startup to reduce inrush current. For safety-critical machinery, the LADN40 contacts feed audible or visual alarms that confirm contactor state independently of the PLC — a hardware-level status check with no software dependency.

Application Typical Deployment
Motor control center (MCC) status monitoring LADN40 contacts feed PLC digital input cards for running/stopped indication across multiple motor starters
HVAC air handling unit control Fan contactor LADN40 contacts interface to BAS system inputs and enable downstream damper control interlocks
Conveyor system interlock logic Upstream conveyor contactor LADN40 contacts prevent downstream belt start until upstream is confirmed running
Compressed air and pump sequential start LADN40 contacts trigger timing relays to stagger compressor or pump startup and reduce inrush
Packaging and assembly machinery LADN40 contacts drive pilot lamps and audible alarms confirming actuator contactor state at operator station
Water treatment pump stations LADN40 contacts provide SCADA system with hardwired contactor status independent of PLC program state

Electrical and Mechanical Specifications for Purchase Decisions

Parameter Value Notes
Contact Configuration 4 NO Normally open only; no NC option on LADN40
Voltage Rating 690V AC maximum Do not exceed; applies to each contact
Current Rating 10A continuous Per contact; derate for inductive loads and hot environments
Frequency Range 25 to 400 Hz Compatible with standard 50 and 60 Hz industrial power
Operating Temperature -5 to +60°C Ambient environment; verify for outdoor or high-temp enclosures
Mechanical Durability 30 million cycles Rated at up to 3600 cycles per hour
Insulation Resistance Greater than 10 MΩ Tested at 500V DC
Mounting Type Front clip-on snap No external fasteners; one block per contactor only
Terminal Type Screw clamp Finger-safe, IP20 rated per IEC 60529
Certifications UL (E164862), CSA (LR43364), CE, RoHS IEC 60947-5-1 compliant; gG fuse 10A short-circuit protection

Full technical specifications are available on the product page at LeadTime.ca.

LADN40 vs LADN11 vs LADC22 vs LADC41 — Which Variant Do You Actually Need?

Model Contact Configuration Rated Current Best Use Case Cost Indicator
LADN40 4 NO 10A / 690V AC Four independent NO signaling or interlock circuits from one block Base reference
LADN11 2 NO 10A / 690V AC Two-circuit signaling; lower cost where only two contacts needed Lower cost
LADN20 2 NO 10A / 690V AC Two NO contacts with alternative mounting orientation Similar to LADN11
LADC22 2 NO + 2 NC 10A / 690V AC Mixed logic: normally open and normally closed circuits required Slightly higher
LADC41 4 NC 10A / 690V AC All normally closed logic; de-energize-to-signal applications Similar to LADN40

If your control design calls for any NC contacts or a mix of NO and NC logic, the LADN40 is the wrong part — the LADC22 or LADC41 are the correct selections. Check current availability for the LADN40 and the full LAD family at LeadTime.ca to confirm you are ordering the right variant before your build schedule locks in.

Expert Verdict: Is the LADN40 the Right Part for Your Build?

The LADN40 is the default auxiliary contact block for control systems engineers and panel builders who are already committed to the Schneider TeSys platform and need exactly four normally open switching circuits from a single compact block. Its 30 million cycle mechanical durability rating, 10A at 690V AC contact rating, and direct snap-on compatibility with the full LC1D09 through LC1D150 contactor range make it a low-risk, low-labor addition to any TeSys D or TeSys Deca assembly. The UL listing (File E164862) and CSA listing (File LR43364) mean compliance documentation is straightforward for both North American and European projects. If those four conditions match your project — TeSys platform, four NO contacts, 10A or below, LC1D contactor — then the LADN40 is the correct call and there is no reason to look further.

Where the LADN40 has real limits: it provides no normally closed contacts, it is a single-block-per-contactor design, and it is mechanically specific to the Schneider LC1D and LP1D contactor range. If your application needs mixed NO/NC logic, the LADC22 is the correct variant. If you only need two auxiliary circuits, the LADN11 reduces cost and preserves space. If your contactors are from a different platform entirely — Siemens 3RT2, ABB A-Line, Eaton DILM — the LADN40 will not physically mount and a platform-matched auxiliary block is required. Do not assume a 4NO 10A block is interchangeable across manufacturers; the mechanical clip interface is platform-specific.

From a procurement standpoint, the LADN40 is normally stocked in major distribution, with in-stock lead times of 1 to 3 days and backorder timelines of 2 to 4 weeks in typical market conditions. Pricing varies across distribution channels, and volume orders of 10 or more units typically qualify for negotiated discounts — contact your distributor directly to confirm. Ordering through a specialist industrial automation distributor rather than a generic channel matters here because the right distributor can confirm compatibility with your specific contactor model and coil voltage before the order ships, eliminating the risk of receiving the correct part number for the wrong application. Check current stock status and pricing for the LADN40 at LeadTime.ca — worldwide shipping available.

For volume pricing, project-quantity lead time confirmation, or help verifying the correct LAD variant for your contactor model, contact the LeadTime.ca team directly — we ship worldwide.

What Engineers Need to Know Before Ordering the LADN40

Community discussion of the LADN40 specifically in public automation forums is limited. The block is treated as a mature, standardized IEC component within larger TeSys contactor assemblies rather than a subject of independent technical debate. Most compatibility and installation questions are resolved directly through distributor technical support or Schneider field engineering before the order is placed — which is the correct workflow for a part where a wrong-variant order means field rework rather than a simple return.

What does surface consistently in distributor technical intake is a cluster of ordering mistakes that experienced engineers rarely make but that trip up buyers who are newer to the IEC auxiliary contact ecosystem. The most common: ordering LADN40 for a non-LC1D contactor platform because the 4NO 10A 690V specification appears to match a different manufacturer's auxiliary block spec. It does not fit. The mechanical clip interface is Schneider TeSys-specific, and no amount of physical persuasion will seat it correctly on a Siemens, ABB, or Eaton contactor. The second most common error is specifying LADN40 when the control design actually requires normally closed contacts for de-energize-to-signal safety logic — a detail that is sometimes not caught until wiring begins on the panel floor. A third recurring issue is the assumption that two LADN40 blocks can be stacked on one contactor for eight contacts. They cannot. The clip design accommodates one block per contactor only, and attempting to force a second block results in unreliable contact engagement or a block that physically disengages under vibration.

When community data is sparse on a component, the right move is to resolve technical questions with a specialist who handles this part family daily. LeadTime.ca carries the LADN40 and the full LAD variant family and can confirm compatibility with your specific contactor model number, coil voltage, and application requirements before the order ships — not after it arrives on the dock. That pre-order conversation is worth more than any forum thread for a mature IEC component where the wrong-part failure mode is quiet and shows up at commissioning.

Installation and Wiring Overview

  • De-energize and lock out the contactor fully before attempting to mount the LADN40 — verify zero voltage on both coil terminals with a multimeter before handling the block
  • Align the LADN40 clip with the mounting slot on the front face of the LC1D contactor and press firmly until you hear or feel a distinct snap; if the block does not seat with moderate pressure, stop and verify the contactor model number before proceeding
  • Verify the block is flush against the contactor face with no visible gap before wiring — a partially seated block will produce intermittent contact operation under vibration
  • Wire each screw clamp terminal using the wire gauge and circuit assignments from your control schematic; each terminal accepts a single wire, and screw torque should be firm without over-tightening — stripped terminal screws are a common cause of poor contact continuity
  • After wiring, verify continuity on each contact pair with a multimeter before energizing the circuit — confirm open state with contactor de-energized and closed state after energization; refer to Schneider Electric installation documentation for full terminal numbering and wiring diagrams

Compatible Contactors and System Expansion

The LADN40 is compatible with the following Schneider Electric contactor and control relay models. Verify your specific contactor nameplate before ordering.

  • LC1D09 to LC1D150 — TeSys D and TeSys Deca 3-pole and 4-pole IEC contactors; the primary compatible range
  • LP1D09 to LP1D150 — European designation magnetic contactors; mechanically equivalent mounting to LC1D series
  • CAD32 to CAD50 — TeSys D control relays; LADN40 auxiliary block is compatible with these relay coil switching applications

The LADN40 is not compatible with LP1M contactors, older TeSys D generations outside the D09-D150 frame range, or contactors from other manufacturers. Only one LADN40 may be installed per contactor — do not attempt to stack blocks.

Wrong-Part Prevention Checklist

Before submitting your order for the LADN40, verify each of the following eight points against your application and contactor documentation:

  1. Confirm contactor model range: LADN40 fits LC1D09 to LC1D150. Do NOT use with LP1D, CAD16-25, or contactors outside this range without verifying compatibility.
  2. Verify contact count required: LADN40 provides 4 NO only. If you need NC or mixed contacts, select LADC or LADN variant instead.
  3. Check voltage/current rating: 10A at 690V AC is maximum. If your circuit requires higher continuous current or voltage exceeds 690V AC, this block is not suitable.
  4. Confirm mounting location: LADN40 is front clip-on only. Side-mount or top-mount auxiliary blocks require different part numbers.
  5. Terminal type confirmation: Screw clamp terminals are standard. If DIN rail or different terminal style required, order alternate part.
  6. Operating temperature: Verify your environment range falls within -5 to +60°C. Outdoor or extreme-temperature applications may need different auxiliary.
  7. Installation quantity per contactor: Only ONE LADN40 can be used per single contactor. Do NOT stack multiple LADN40 blocks on one contactor.
  8. Regional standards compliance: Confirm your market accepts CE, UL, CSA, and RoHS markings. Some applications require specific certifications.

If any of the above checks raises a compatibility question, contact the LeadTime.ca technical team before ordering — resolving a compatibility question before shipment costs minutes; resolving it after installation costs hours.

Frequently Asked Questions

Can I mount two LADN40 blocks on one LC1D contactor to get eight NO contacts?

No. The LAD series mechanical clip design allows only one auxiliary block per contactor. Attempting to mount a second LADN40 on the same contactor will result in improper seating on one or both blocks, producing unreliable contact operation or physical disengagement under vibration. If you need more than four auxiliary contacts, use external relay modules or a different system architecture — contact your distributor for configuration guidance.

Does the LADN40 work with both TeSys D and TeSys Deca contactors, or only one generation?

The LADN40 is compatible with both TeSys D and TeSys Deca. Both product generations use the same LC1D contactor frame and the same LAD auxiliary series mounting interface. Do not confuse TeSys Deca with the older LP1M series or non-IEC platforms — those are not compatible. If you are unsure which TeSys generation is installed in your panel, check the contactor nameplate for the LC1D or LP1D model designation.

What happens if a control circuit load exceeds the 10A contact rating on one of the LADN40 contacts?

Exceeding the 10A continuous rating, particularly on inductive loads with high inrush current, causes internal arc erosion on the contact surfaces. The result is a contact that either fails to close reliably, chatters, or fuses open internally — often within days or weeks of the overload condition beginning. If any individual LADN40 circuit load approaches or exceeds 10A, interpose an isolation relay with a coil current well below 10A and switch the high-current load through the relay. The LADN40 contact then drives only the relay coil, extending block service life significantly.

Is the LADN40 a direct replacement for the older LADN40 variants, or are there mechanical differences between generations?

The LADN40 is the current catalog number for the TeSys Deca auxiliary contact block in the 4 NO configuration, and it is compatible with the same LC1D09 to LC1D150 contactor range that earlier TeSys D accessories supported. For equipment older than approximately 2010 or contactors outside the confirmed LC1D and LP1D range, verify compatibility with your distributor before assuming a direct drop-in fit — nameplate confirmation is the only reliable check.

What certifications does the LADN40 carry, and are they sufficient for projects requiring UL and CSA compliance?

The LADN40 carries UL listing under File E164862, CSA listing under File LR43364 Class 3211, CE marking, RoHS compliance, and conformance to IEC 60947-5-1. These certifications cover North American (UL, CSA) and European (CE, IEC) compliance requirements for industrial control panel applications. For projects with specific contract requirements such as the Buy American Act, the LADN40 is noted as compliant where applicable — verify with your compliance team for project-specific documentation requirements.

Why Order the LADN40 from LeadTime.ca

  • LeadTime.ca stocks the LADN40 and the full Schneider Electric LAD auxiliary contact family, with worldwide shipping to project sites, panel shops, and distribution centers globally
  • Pre-order compatibility verification available — confirm your LC1D contactor model and required contact configuration with a specialist before the order ships, not after it arrives
  • Volume and project-quantity pricing available on request; contact the team directly for orders of 10 or more units or for ongoing panel build programs
  • Hard-to-find or short-lead-time variants sourced through specialist channels when standard distribution is on backorder

At-a-Glance Summary

  • The Schneider Electric LADN40 provides 4 normally open contacts rated at 10A and 690V AC — no normally closed option exists in this variant
  • Compatible with LC1D09 through LC1D150 (TeSys D and TeSys Deca) and LP1D09 through LP1D150 contactors, plus CAD32 to CAD50 control relays
  • Mechanical durability rated at 30 million electrical cycles at up to 3600 cycles per hour
  • Front clip-on mounting with screw clamp terminals; finger-safe IP20 rated; one block per contactor maximum
  • Operating temperature range: -5 to +60°C ambient
  • Insulation resistance greater than 10 MΩ at 500V DC test; gG fuse 10A short-circuit protection per IEC 60947-5-1
  • Certifications: UL File E164862, CSA File LR43364 Class 3211, CE marked, RoHS compliant
  • Alternatives within the LAD family: LADN11 (2 NO), LADN20 (2 NO alternate mount), LADC22 (2 NO + 2 NC), LADC41 (4 NC)
  • Only one LADN40 may be installed per contactor — stacking is not mechanically possible and is not supported
  • Pricing and lead time available on the product page; worldwide shipping from LeadTime.ca
